Summary of Contents for Acuva Arrow 5
- Page 1 Acuva Arrow 5 UV-LED Water Purifier O W N E R ’ S P R O D U C T M A N U A L Acuva Technologies Inc. Unit 1 - 3771 North Fraser Way, Burnaby, BC. Canada V5J 5G5 Telephone: 1.604.431.9241 | Email: info@acuvatech.com...
-
Page 2: Table Of Contents
O W N E R ’ S P R O D U C T M A N U A L Summary This document is the product manual for the Arrow 5 UV-LED Water Purifier, including safety, product specification, installation and maintenance information. -
Page 3: Product Overview
The Arrow 5 water purification system is powered by 12V DC – either directly or via 110V to 240V AC (using a power adapter). The Arrow 5 operates on-demand, meaning its internal flow sensor will activate UV-LEDs only when water is flowing through the system, improving energy efficiency and extending the life-time of the system. -
Page 4: Safety Information And Warnings
Installation or operation of the device in a manner contrary to this manual may result in property damage or personal injury. Acuva recommends that the device be installed by a qualified technician and shall comply with applicable state and local regulations. -
Page 5: Product Information
Maximum Working Pressure 100 PSI Minimum Working Pressure 40 PSI LED Life-time 3,000 hr (on demand) Maximum Ambient Relative Humidity Overview of Your Arrow 5 Water Purifier Power Connection Audio Jack (Optional Smart Faucet) Inlet Outlet Indicator LED Advanced UV-LED Water Purification | acuvatech.com... -
Page 6: Installation Guide
O W N E R ’ S P R O D U C T M A N U A L Installation Guide Acuva systems are designed for ease of installation. Two different installation scenarios are shown below: when the Arrow 5 is connected to a dedicated smart faucet or when it’s connected to the main faucet... -
Page 7: Installation Instructions
Snap the pre-filter into its wall- mounted clips. 6. To install the Arrow 5 (item no. 6), mount it to the DIN-rail as seen in the “Mounting the Unit” figure. 7. Cut a length of 3/8” tubing that will connect the pre-filter to the Arrow 5’s inlet and push both ends of the tubing into place. -
Page 8: Mounting The Unit
Do not use a wrench or pliers to tighten the plug or power jack as this may cause damage to the device. 3. If there is no water flow on powering up, the Acuva logo should glow green for 30 seconds. -
Page 9: Indicator Light
5 should be consulted Maintenance The Arrow 5 is designed to give years of trouble-free use. Acuva products use state-of-the-art UV-LEDs, meaning there are no mercury bulbs to replace. However, there are some simple tasks that should be performed to ensure continued operation. -
Page 10: Troubleshooting
Acuva for support. Standard Terms and Conditions The sale and use of all Acuva products is governed by the Acuva Technologies Inc. Standard Terms and Conditions of Sale and Use (the “Agreement”), a copy of which is available at www.acuvatech.com. -
Page 11: Warranty
Limited Warranty. Where you purchased the Product from Acuva’s Site or other online vendors the date of purchase is the date of the purchase invoice issued to you by Acuva or such online vendors by email. Where you purchased the Product from an authorized reseller at a physical location, the date of purchase is the date of the invoice issued to you at the physical location. -
Page 12: Appendix A: Faucet Installation Instructions
The limited warranty does not apply: 1. To normal wear and tear; 2. If the Product was not purchased from Acuva or its authorized retailers; 3. To damage caused by misuse, corrosion, moisture or liquids, proximity or exposure to heat or external environment, accident, abuse, misuse, neglect, improper installation or misapplication;...
