kd frames Charleston Plus Queen Assembly Instructions page 3

4
Use 2-1/2" Bolts (H-21) and
Cross Dowels (H-3) to attach
Bed Rails (A-80) to the Headboard
and Footboard. The pockets in the
Bed Rails should be facing in and
open to the top of the Rails.
Leave all bolts loose until
everything is attached. Then
tighten all bolts.
5
Insert Connector Slats (A-28-C) into the
pockets that have holes. Secure using
2 - 1/2" Bolts (H-21) and Cross Dowels
(H-3). Leave these loose at this time.
NOTE:
Rail pockets must
face the inside.
H-21
H-3
Place the best looking rail
on the outside to make
your frame look its best.
H-3
H-21
NOTE:
