Summary of Contents for Motorline professional MC61PL
- Page 1 MC61PL MC61PL INSTALLER AND USER’S MANUAL v5.1 REV. 08/2019...
-
Page 2: Table Of Contents
00. CONTENT 01. SAFETY INSTRUCTIONS INDEX ATTENTION: 01. SAFETY INSTRUCTIONS This product is certified in accordance with European Community (EC) safety standards. 02. CONNECTIONS SCHEME COMPONENTS CONNECTION TO THE CONTROL BOARD This product complies with Directive 2011/65/EU of the 03. CONTROL BOARD European Parliament and of the Council, of 8 June 2011, on TECHNICAL SPECIFICATIONS the restriction of the use of certain hazardous substances in... -
Page 3: Safety Instructions
01. SAFETY INSTRUCTIONS GENERAL WARNINGS the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. WARNINGS FOR TECHNICIANS very important. Read all instructions carefully before beginning the installation/usage procedures and keep this manual in a safe place •... - Page 4 01. SAFETY INSTRUCTIONS RESPONSABILITY • Attach the permanent label for the manual release as close as possible to the release mechanism. • Supplier disclaims any liability if: • Disconnect means, such as a switch or circuit breaker on the electrical •...
-
Page 5: Connections Scheme
02. CONNECTIONS SCHEME COMPONENTS CONNECTION TO THE CONTROL BOARD LED tape The MSC50 is a crespuscular sensor, the input when it is active, the leds of the Pylon will work. When it is flush with the sensor, the LEDs do not work during the day and work at night. -
Page 6: Control Board
05. FUNCTIONS • Accepted codestype Rolling Code • Central dimensions 99x104,5 mm FUNCTION’S BOARD • Fuse The control board MC61PL has a menu that allows access to all automatic configurations. 04. REMOTE CONTROLS MÁX. MIN. FACTORY MENU FUNCTION STATE PAGE... -
Page 7: Automation Sensibility Programming 6A
05. FUNCTIONS 05. FUNCTIONS AUTOMATION SENSIBILITY PROGRAMMING OPENING AND CLOSING COURSE PROGRAMMING This menu allows to set the level of sensibility that you want in the motor operation. To make the opening and closing course programmation, the mechanical limit switches Maximum sensibility - 1 | Minimum sensibility - 9 must always be in tune. -
Page 8: Enable/Disable Safety Photocells 7A
05. FUNCTIONS 05. FUNCTIONS ENABLE/DISABLE SAFETY PHOTOCELLS PROGRAMMING AUTOMATIC CLOSING When photocells enabled, if any obstacle interrupt them (if the door is closing), the door will Option 0 disables the automatic closing, and the gate will close only if it receives an order reverse the direction. -
Page 9: Enable/Disable Condominium Function 8A
05. FUNCTIONS 05. FUNCTIONS ENABLE/DISABLE CONDOMINIUM FUNCTION ENABLE/DISABLE STOP 0-Disabled • When this function is activated, the control board will only work if STOP contact is closed. If • If you send an order to the gate completely open, it will close. the barrier is open, the control board reject any opening or closing order. -
Page 10: Increase Or Decrease Deceleration 9A
05. FUNCTIONS 05. FUNCTIONS INCREASE OR DECREASE DECELERATION ENABLE/DISABLE FOLLOW ME The deceleration reduce the motor speed in the final part of the course (opening or closing). With the “Follow Me” function activated, whenever the photocells detect the passage of a Without deceleration - select the value 0 user/obstacle, the control board triggers the closing maneuver 3 seconds later. -
Page 11: Troubleshooting
06. TROUBLESHOOTING INSTRUCTIONS FOR FINAL CONSUMERS/TECHNICIANS Anomaly Procedure Behavior Procedure II Discovering the origin of the problem 1 • Open the control board box; 2 • Measure the 24V output of the transformer to detect the fault location; • Make sure you A) Has 24V: have 230V power 1 •...
