STEP 4
Attach TV
to Mount
C A U T I O N
Do not damage or scratch the rods of the
Gas Springs while performing these steps!
W A R N I N G
Do not put hands into Lifting Arm without the
Safety Bolt and Safety Nut installed. The force of
the Lifting Arm can cause bodily injury!
14 MM540 Installation Instructions
4.1

Insert the Safety Bolt and Safety Nut.

Use your body weight to firmly pull down the TV Brace
{33} until the Lifting Arm {35} is horizontal to the floor.
Continue holding onto the TV Brace.
A second person must insert the Safety Bolt {20}
through the Safety Hole in the base of the
Lifting Arm and install the Safety Nut {27}.
Slowly release the TV Brace until the Lifting Arm gently
comes to rest against the Safety Bolt. The Lifting Arm
should remain in a horizontal position during installation.
You will later remove the Safety Bolt in STEP 5.4.
{33}
PERSON 1
{35}
PERSON 2
{20}
