OSD Menu_Exposure

Lens
1 1
Manual: Manual mode supports the fixed board lens or the manual iris lens.
Auto: AUTO mode sets the camera's iris automatically.
EXPOSURE
EXPO
1 LENS
EDGE DET
2
3 BRIGHTNESS
SHUTTER
BACK-LIGHT
STARLIGHT
AGC
3D DNR
RETURN
Under the lens sub-menu, you can adjust the following settings:
Level
Change the camera's iris value manually. If auto is selected, this option is disabled.
Edge DET
2
Adjust the camera's focus according to the camera's view.
- Level:
- Color:
B rightness
3
0 ~ 20: The higher the number, the brighter the image will appear.
Shutter
Set the shutter speed to auto, manual or flicker mode.
- Auto: If selected, adjust the following options :
- Normal: Set when the camera is installed in an indoor environment.
- De-blur: Set when the camera is installed in an outdoor environment.
- Flicker: Select when the camera is experiencing flickering in the image. The shutter
speed will be set automatically to 1/100.
- Manual: If selected, set the shutter speed from the options: 1/30 ~ 1/30000.
AUTO
LEVEL
ON
RETURN
10
AUTO
OFF
X4
10
HIGH
Set the focus range.
Set the color to be displayed in the focus range from yellow, cyan,
green, magenta, red, blue, black or white.
LENS EDGE DET
20
LEVEL
COLOR
RETURN
18
5
YEL
