OSD Menu_Exposure

LENS
1
Manual: Manual mode supports the fixed board lens or the manual iris
lens. Auto: AUTO mode sets the camera's iris automatically.
EXPOSURE
EXPO
LENS
1
2-MOTOR
2
BRIGHTNESS
SHUTTER
BACKLIGHT
STARLIGHT
AGC
3D DNR
RETURN
2-MOTOR
2
Enter the 2-Motor Lens sub-menu.
AF MODE
- ONESHOT: Set the camera's focus automatically based on the camera's current field of
view (FoV).
- MANUAL: Adjust the camera's focus and zoom manually.
D&N FILTER
Set the camera's focus to adjust automatically
when the camera switches between day and
night model.
INITIAL
Initiate the two motor lens.
AUTO 2-MOTOR
AF MODE
10
D&N FILTER
AUTO
INITIAL
OFF
RETURN
X4
10
HIGH
18
ONESHOT
SYNC OFF
ON
