ITC­100 Tally Input ­ Pin Cross Reference
If you are using the ITC­100 with a Datavideo RMC­140, RMC­90 or SE­500 you do
not need to worry about tally information, as it is automatically sent to the ITC­100.
If you are using the ITC­100 with other equipment the following tables explain the
pin configurations of Tally A and Tally B.
Contact closure between the relevant Pin number and ground will illuminate the
LED. For example on Tally A, if Pin 1 is connected to Pin 4 the RED LED will light
up on Channel 1; if Pin 13 is connected to Pin 4 the AMBER LED will light up on
Channel 3
Tally A Input
The Tally A Input will send Tally Information to Channels 1 ~ 4. The following table
shows the pin numbers for each channel:
Video
Channel
1
2
3
4
Pins 4, 9 and 14 can be used as ground.
Tally B Input
The Tally B Input will send Tally Information to Channels 5 ~ 8. The following table
shows the pin numbers for each channel:
Video
Channel
5
6
7
8
Pins 4, 9 and 14 can be used as ground.
Red LED
LIVE
(On Air)
Pin 1
Pin 6
Pin 11
Pin 5
Red LED
LIVE
(On Air)
Pin 1
Pin 6
Pin 11
Pin 5
12
Amber LED
CUED
(Next)
Pin 3
Pin 8
Pin 13
Pin 15
Amber LED
CUED
(Next)
Pin 3
Pin 8
Pin 13
Pin 15
