ITC-100 KF1000
8 Channel Intercom / Talkback
System for SE-1000
Instruction Manual
http:// www.datavideo-tek.com
Rev: 280807

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ITC-100 KF1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Datavideo ITC-100 KF1000

Summary of Contents for Datavideo ITC-100 KF1000

  • Page 1 ITC-100 KF1000 8 Channel Intercom / Talkback System for SE-1000 Instruction Manual http:// www.datavideo-tek.com Rev: 280807...

  • Page 2: Warranty

    7. This product should only be operated from the type of power source indicated on the marking label of the AC adapter. If you are not sure of the type of power available, consult your Datavideo dealer or your local power company.

  • Page 3: Introduction

    Datavideo warrants that the equipment it manufactures shall be free from defects in material and workmanship for a period of 12 months from the date of product purchased. If equipment fails due to such defects, Datavideo will, at its option, repair or provide a replacement for the defective part or product.

  • Page 4: Table Of Contents

    Contents WARNINGS AND PRECAUTIONS WARRANTY INTRODUCTION PACKING LIST FRONT PANEL CONNECTIONS REAR PANEL CONNECTIONS ITC-100SL SLAVE UNIT USING THE ITC-100 WITH THE SE-1000 / TB-10 ITC-100 TALLY INPUT PIN CROSS REFERENCE SPECIFICATIONS SERVICE AND SUPPORT Packing List 1. ITC-100 KF 1000 Main Unit 2.

  • Page 5: Front Panel Connections

    Front Panel: On / Off Switch Powers the ITC-100 On / Off. Red LED indicates that unit is switched on. XLR Microphone Socket Combined XLR / ¼” (6.3mm) Jack Microphone Input for either a Condenser or Dynamic Gooseneck Microphone. XLR supports Condenser Microphones ¼”...
  • Page 6 Channel Buttons 1~6 + AUX 1 / 2 Opens communication with individual channels. More than 1 channel can be active at any given time, active channels are illuminated red. All active channels will hear any communication from the operator or from any other active channel.

  • Page 7: Rear Panel Connections

    Tally Inputs A & B Tally Inputs A & B are configured for direct connection to the Datavideo SE-1000 via the TB-10. They supply tally information to the ITC-100SL; RED indicates Live. Tally A will feed information to channels 1 ~ 3 and Tally B will feed information to channels 4 ~ 6 DC In 12V 2.5A...

  • Page 8: Itc-100Sl Slave Unit

    ITC-100SL Slave Unit : XLR Connection Connects the ITC-100SL to the ITC-100 Base Station. Power, tally and bi-directional audio are all carried through the same cable. Call Button Sends a paging message to the ITC-100 Base Station. The channel button will flash orange and there will be an audible tone, each time the button is pressed.
  • Page 9 Mic / Headphone Socket The ITC-100SL has both a 3.5mm and 2.5mm Mic / Headset socket. A standard 3.5mm Mic / Headset can be used, or a Motorola type 2.5mm Mic / headset could be used if preferred. External Tally LED Socket An external tally display (TD-1) can be connected to the ITC-100SL.
  • Page 10 Using the ITC-100 KF1000 with the SE-1000 / TB10: The ITC-100 KF1000 is an ideal accessory for the Datavideo SE-1000 Vision Mixer. The SE-1000 has five HD / SDI channels, so in the diagram below we have five camera crew, each with an ITC-100SL. The sixth ITC-100SL could be for communicating with the graphics operator or other members of the crew.

  • Page 11: Itc-100 Tally Input Pin Cross Reference

    ITC-100 Tally Input - Pin Cross Reference If you are using the ITC-100KF1000 with a Datavideo SE-1000 via a TB-10 you do not need to worry about tally information, as it is automatically sent to the ITC-100 KF1000. If you are using the ITC-100 with other equipment the following tables explain the pin configurations of Tally A and Tally B.

  • Page 12: Specifications

    Specification: ITC-100 Base Station Specification POWER 12V 2.5A TALLY 2 x 15 Pin SubD Sockets for Tally A and Tally B MIC / HEADSET 3.5mm Stereo Jack Socket for combination Headphone / Microphone Headset Impedance 8~600 ohms 100mW(min) INPUTS / HEADPHONE ¼”...

  • Page 13: Itc-100Sl Slave Unit

    ITC-100SL SLAVE Unit Specification 5 Pin XLR Connector INPUT MIC / HEADSET SOCKET 3.5mm Stereo Jack Socket for combination Headphone / Microphone Headset Impedance 8~600 ohms 100mW(min) Microphone Level -67dB 2.5mm Stereo Jack Socket, for Motorola Mobile Phone type headset / microphone TALLY OUT SOCKET 3.5mm Jack Socket to connect to TD-1 Tally Indicator...
  • Page 14 It is our goal to make your products ownership a satisfying experience. Our supporting staff is available to assist you in setting up and operating your system. Please refer to our web site www.datavideo-tek.com for answers to common questions, support requests or contact your local office below.
