Operating instruction
Temperature calibrator TP 18 850 E
List of contents
1
Description of the temperature calibrator TP 18 850 E.............................................................. 2
2
Safety instructions ...................................................................................................................... 2
3
Operation of the calibrator.......................................................................................................... 4
3.1 Adjustment of the handle............................................................................................................ 4
3.2 Operating position ...................................................................................................................... 4
3.3 Adapter sleeves.......................................................................................................................... 4
3.4 Control of temperature sensors.................................................................................................. 4
3.5 Front panel description............................................................................................................... 5
3.6 Switching on of the calibrator ..................................................................................................... 5
3.7 Indication of the block temperature and set temperature........................................................... 6
3.8 Adjustment of the block temperature ......................................................................................... 6
3.9 Programming of the set point ..................................................................................................... 6
4
Cooling down the heating block .................................................................................................. 7
5
Recalibration ............................................................................................................................... 7
6
Error signalling ............................................................................................................................ 7
7
Cleaning ...................................................................................................................................... 7
8
Disposal....................................................................................................................................... 7
9
Guarantee and repairs ................................................................................................................ 8
10 Technical Data ............................................................................................................................ 8
Page
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SIKA TP 18 850 E
Summary of Contents for SIKA TP 18 850 E
-
Page 1: Table Of Contents
Operating instruction Temperature calibrator TP 18 850 E List of contents Page Description of the temperature calibrator TP 18 850 E.............. 2 Safety instructions ........................2 Operation of the calibrator......................4 3.1 Adjustment of the handle......................4 3.2 Operating position ........................4 3.3 Adapter sleeves.......................... -
Page 2: Description Of The Temperature Calibrator Tp 18 850 E
1 Description of the temperature calibrator TP 18 850 E TP 18 850 E 1 Description of the temperature calibrator TP 18 850 E The test instrument TP 18 850 E consists of two single enclosures, front size 192 x 192 mm and depth 410 mm or 510 mm. - Page 3 2 Safety instructions TP 18 850 E • Before exchanging the fuse, the equipment is to be seperated from the mains supply by pulling the cable from the mains plug. • Make this manual always availabe in a legible and complete form in situ of the equipment.
-
Page 4: Operation Of The Calibrator
3 Operation of the calibrator TP 18 850 E 3 Operation of the calibrator The test instrument TP 18 850 E is a portable unit for service purposes, as well as for operating and laboratory tasks. 3.1 Adjustment of the handle The handle can be adjusted into any required position from vertical to horizontal by pressing the lateral stop buttons. -
Page 5: Front Panel Description
3 Operation of the calibrator TP 18 850 E 3.5 Front panel description 1 - Key P This is used to access set point of the heating block and to confirm the selection. 2 - Key DOWN This is used to decrease the values of the heating block... -
Page 6: Indication Of The Block Temperature And Set Temperature
3 Operation of the calibrator TP 18 850 E The lower display (SV) indicates the actual set value of the heating block The installed electrical heating cartridge heats the brass block up from ambient temperature to the adjusted set point value. -
Page 7: Cooling Down The Heating Block
8 Disposal Company SIKA Dr Siebert & Kühn GmbH and Co.KG provides for an adequate disposal of used temperature calibrators. For that purpose please send calibrators of series TP 18 850 E back to us freightfree. ba_tp18850e_e.doc Version 0.1... -
Page 8: Guarantee And Repairs
The faulty product must be shipped to SIKA with a detailed description of the faults found, without any fees or charge for SIKA, except in the event of alternative agreements. - Page 9 10 Technical Data TP 18 850 E Indication of sensor break - - - Sampling rate: 130 msec. Outputs 1 x relay SPDT (8 A-AC1, 3 A-AC3 / 250 VAC) temperature fuse, 100.000 switches 1 x SSR drive (8mA/ 8VDC) control output...
