Page 1 Generation III LED Baseball Scoreboards BA-2000 Series Display Manual ED-13788 Rev 7 – 24 October 2006 Models* BA-2001 BA-2002 BA-2008 BA-2009 BA-2018 *All models include a suffix of -11 or -21, indicating power and digit style.
Page 2 – without written permission of the publisher. ® ® All Sport and PanaView are trademarks of Daktronics, Inc. All other trademarks used in this manual are the property of their respective owners.
Page 3: Table Of Contents
LED Drivers ....................5-6 Segmentation and Digit Designation ............5-6 Lightning Protection .................. 5-7 Troubleshooting..................5-7 Replacement Parts ..................5-8 Daktronics Exchange and Repair and Return Programs......5-9 Exchange Program ................5-9 Repair and Return Program .............. 5-10 Table of Contents...
Page 4 Section 6: TNMC Maintenance for BA-2001, 2002, 2008 and 2009 ... 6-1 Team Name Message Center System Overview........6-1 Maintenance and Troubleshooting Overview ..........6-2 Signal Summary..................6-2 Power Summary..................6-3 Service and Diagnostics................6-3 TNMC Controller ................6-4 Modules and Drivers ................ 6-10 Power Supplies .................
Page 5 Figure 1: Daktronics Drawing Label..................1-1 Figure 2: Scoreboard ID Label....................1-2 Figure 3: Beam Spacing, ....................... 3-2 Figure 4: Beam Spacing, BA-2002 and BA-2009..............3-2 Figure 5: Beam Spacing, BA-2018 ..................3-3 Figure 6: Lifting the Display....................3-3 Figure 7: Mounting Display to Tubing ................. 3-6 Figure 8: Scoreboard Mounting, Clamping Method .............
Page 7: Introduction
2018 both with and without Team Name Message Centers (TNMCs). If you have any questions regarding the safety, installation, operation, or service of these systems, contact the Daktronics Customer Service helpdesk at the telephone numbers listed in Section 5.9 of this manual.
Page 8: Daktronics Nomenclature
For example, this manual would be referred to as ED-13788. The serial and model numbers of a Daktronics scoreboard can be found on the ID label on the display. The label will be similar to the one shown in Figure 2. When calling Daktronics Customer Service, please have this information available to ensure quick service.
Page 9: Manual Overview
• ‘‘P _ _’’ denotes a power or signal plug for the opposite jack. Finally, Daktronics part numbers are commonly found on drawings. Those part numbers can be used when requesting replacement parts from Daktronics Customer Service. Take note of the following part number formats. (Not all possible formats are listed here.) •...
Page 10: Product Overview
G3 ............Drawing A-222092 Component Locations; BA-2018-11/-21 ...... Drawing A-222578 Daktronics LED baseball scoreboards are part of a family of scoring and timing displays designed to offer easy installation, readability and reliability. Microprocessor control assures consistent operation and accuracy.
Page 11: Model Names
The BA-2001 and BA-2008 are available with an 8x32-matrix TNMC, while BA-2002, BA-2009 and BA-2018 may be equipped with a larger, 8x48 message center. Section 6 offers step-by-step information on TNMC maintenance and troubleshooting.
Page 13: Specifications
The models are listed in the tables in alphanumeric order. Note: Signal wires must be a minimum of 24 AWG (shielded 2-conductor). Daktronics recommends using W-1234. Displays require 120 V A C, 15 A circuit. Displays with a 230 V A C power requirement are also available.
Page 14 Number of Dimensions Weight Digit Size Maximum Power Amps Driver Model Sections (Height, Width, Uncrated Wattage per Line Number Depth) Digit Color (Single- and Address (Crated) Phase) BA-2002 2 Total H9'-4", W36'-0", D8" 1116 lb 900 W 120/240 7.5 A Top Section: •...
Page 15 Number of Dimensions Weight Digit Size Maximum Power Amps Driver Model Sections (Height, Width, Uncrated Wattage per Line Number Depth) Digit Color (Single- and Address (Crated) Phase) Bottom H5'-4", W36'-0", D8" 788 lb (1626 mm, 10973 mm, -11: red (357 kg) 203 mm) -21: amber 1497 lb...
Page 16 (Height, Width, Uncrated Wattage per Line Number Depth) Digit Color (Single- and Address (Crated) Phase) BA-2009 2 Total H9'-4", W36'-0", D8" 1176 lb Top Section: 1200 W* 120 V AC 10 A • (2845 mm, 10973 mm, (533 kg) At Bat, Ball, Strike,...
Page 17 Number of Dimensions Weight Digit Size Maximum Power Amps Driver Model Sections (Height, Width, Uncrated Wattage per Line Number Depth) Digit Color (Single- and Address (Crated) Phase) Bottom H5'-4", W36'-0", D8" 878 lb (1626 mm, 10973 mm, -11: red (357 kg) 203 mm) -21: amber 1668 lb...
Page 18 Model Number Dimensions Weight Digit Size Maximum Power Amps Driver (Height, Width, Uncrated Wattage per Line Number Sections Depth) Digit Color (Single- and Address (Crated) Phase) 4 Total BA-2018 H13'-0", W42'-0", D8" 2730 lb 1400 W 120 V AC 12 A Top Section: •...
Page 19: Mechanical Installation
Note: Some users install devices to protect the scoreboard from projectiles. Scoreboard protection devices not provided by Daktronics must be approved by Daktronics prior to installation. Failure to follow this approval procedure will void the scoreboard warranty. Footings and Beams Reference Drawings: Shop Drawing;...
Page 20: Horizontal Beams
Figure 4, below, shows the spacing of the horizontal beams for the BA-2002 and BA-2009. The horizontal beams themselves must have a vertical dimension (height) of 4". The bottom of the first horizontal beam is level with the bottom of the scoreboard and is considered the zero mark for measuring the other two horizontal beams.
Page 21: Model Ba-2018
The eyebolts are located along the top of the cabinet for each scoreboard or scoreboard section. Note: Daktronics strongly recommends using a spreader bar, or lifting bar, to lift the display. Using a spreader bar ensures that the force on the eyebolts is straight up, minimizing lifting stress.
Page 22: Scoreboard Mounting
Eyebolts are intended for lifting only. Do not attempt to permanently support the display by the eyebolts. In typical multi-section installations, as with BA-2002, BA-2009 and BA-2018 the lower scoreboard section is installed first and secured to the support beams, and then the upper section is placed atop or above the lower section and attached to the beams.
Page 23: Welding To Horizontals
Welding to Horizontals Drawing A-83301 illustrates the mounting of the display to horizontal beams. Steel clip angles are bolted to the back of each scoreboard section. These clip angles are welded on three sides to the horizontal beam structure Review the illustrations of the mounting hardware in Drawing A-83301, and then use the following procedure for each section.
Page 24: Figure 7: Mounting Display To Tubing
Figure 7: Mounting Display to Tubing Mechanical Installation...
Page 25: Clamping To Verticals
Clamping to Verticals Figure 8, below, illustrates a no-weld, clamping method for the baseball scoreboards. For additional mounting details, refer to Drawing A-89234. Mount the scoreboard as follows: Determine where to drill the holes in the rear flanges of the scoreboard perimeter extrusion.
Page 27: Electrical Installation
Schematic; BA-2018 ............ Drawing B-221946 Power specifications for the baseball scoreboard are listed in Section 2. Daktronics outdoor LED scoreboards have been designed for easy access to the components, and the power and control signal hookup has been simplified. Front panels are removable to allow access to the digits, cabling, and other electronic components.
Page 28: Grounding
Note: Displays MUST be grounded according to the provisions outlined in Article 250 of the National Electrical Code and according to the specifications in this manual. Daktronics recommends a resistance-to-ground of 10 ohms or less. The contractor performing the electrical installation can verify ground resistance.
Page 29: Power And Signal Connection
All power and signal wiring terminates at the driver enclosure. Drawing A-178197 illustrates the 16-column driver used in Daktronics outdoor LED scoreboards. To gain access to the driver enclosure, open the access door or digit panel and remove the cover from the enclosure.
Page 30: Figure 9: Power Terminal Block
Figure 10 illustrates the signal surge arrestor card and connections. Figure 10: Signal Surge Arrestor Card For signal cable, Daktronics recommends, as a minimum, single-pair, shielded cable, 22 AWG (Daktronics part number W-1077). Two-pair shielded cable (Daktronics Scoreboard Maintenance...
Page 31: Multiple Driver Connections
part W-1234) is preferred. For additional information on signal connection, refer to the All Sport 5000 Series or All Sport 3000 series control console operation manuals, ED-11976 and ED-12126. Multiple Driver Connections BA-2000 series baseball scoreboards require multiple drivers, and those models have been configured to operate with a master/slave driver system.
Page 32: Scoreboard Maintenance And Troubleshooting
Section 6 or the service manual that accompanies those units. Cabinet Specifications Cabinets for Daktronics outdoor LED scoreboards are constructed of heavy-gauge aluminum. Dimensions and weights for each model are listed in the chart in Section 2. Removable panels for digits and indicators and for component access are detailed in each model’s component locations drawing, listed in Section 5.2 below...
Page 33: Replacing A Digit
3. The digits are secured to the inside of the panel with fixed machine screws, spacers and push nuts. 4. Remove the nuts and lift the digit off the standoff screws. (The push nuts can be removed in several ways, but Daktronics recommends using a " nut driver.)
Page 34: Replacing A Digit Segment
5. Position a new digit over the screws and tighten the nuts. 6. Reconnect the power/signal connector. Note: This is a keyed connector B it will attach in one way only. Do not attempt to force the connection. 7. Close and secure the digit panel and test the scoreboard. Replacing a Digit Segment Reference Drawing: Digit Assemblies;...
Page 35: Replacing A Driver
Replacing a Driver Drivers are typically mounted inside the scoreboard and immediately behind a digit, but location and mounting varies with the model of the scoreboard. Refer to the component locations drawings in Section 5.2 for the location of the scoreboard driver.
Page 36: Schematic
Schematic; BA-2018............ Drawing B-221946 Drawings A-177931, A-179541, A-179593, and A-180688 are the schematic diagrams for the Daktronics BA-2000 Series scoreboards and the 16-column driver used in them. The schematics include power and signal inputs and all wiring for the models described in this manual.
Page 38: Led Drivers
Digit Designation; BA-2002-11 ........Drawing A-158496 Digit Designation; BA-2001-11 w/LED TNMC ............Drawing A-159621 Digit Designation; BA-2002-11/-21 w/LED TNMC ............Drawing A-159666 Component Locations; BA-2009-11/-21 w/TNMC, G3 ............Drawing A-185787 Component Locations; BA-2008-11/-21, G3 ....Drawing A-185855 Digit Designation, BA-2018 ......... Drawing B-221953 Scoreboard Maintenance...
Page 39: Lightning Protection
In each digit, certain LEDs always go on and off together. These groupings of LEDs are referred to as segments. Drawing A-38532 illustrates digit segmentation. It also details which connector pin is wired to each digit segment and the wiring color code used throughout the display.
Page 40: Replacement Parts
Replacement Parts Refer to the following table for Daktronics scoreboard replacement parts. (Refer to Section 6 or to the appropriate manual for a listing of parts required for the service of optional message centers.)
Page 41: Daktronics Exchange And Repair And Return Programs
Exchange Program Daktronics unique Exchange Program is a quick, economical service for replacing key parts in need of repair. If a part requires repair or replacement, Daktronics sends the customer a replacement, and the customer sends the problem part to Daktronics.
Page 42: Repair And Return Program
This bill, which represents the exchange price, is due when you receive it. 4. You must send the problem part to Daktronics within 30 days. If you do not ship it to Daktronics within 30 working days from the invoice date, Daktronics assumes you are purchasing the replacement part outright with no exchange.
Page 43 RMA number a clear description of symptoms How to reach us Mail: Customer Service, Daktronics Inc. PO Box 5128 331 32 Brookings, SD 57006 Phone: Daktronics Customer Call Center: 877-605-1115 (toll-free) or 605-697-4036 Fax: 605-697-4444 Scoreboard Maintenance 5-11 and Troubleshooting...
Page 45: Tnmc Maintenance For Ba-2001, 2002, 2008 And 2009
Section 6: TNMC Maintenance for BA-2001, 2002, 2008 and 2009 IMPORTANT NOTES: 1. Disconnect power before doing any repair or maintenance work on the message centers. 2. Permit only qualified service personnel to access the internal electronics of the display. Disconnect power when the scoreboard is not in use.
Page 46: Maintenance And Troubleshooting Overview
Maintenance and Troubleshooting Overview Standard Daktronics outdoor LED scoreboards typically are front-accessible, but some models may be ordered with rear service access. For that reason, Daktronics team name message centers have been designed so that they may be accessed from both the front and rear for easy maintenance and repair of internal components.
Page 47: Power Summary
2. The signal then travels through the driver/power enclosure to the J1 connector on the current loop interface card. 3. Data exits at J42 via current loop harness, and connects with P43 at the TNMC controller assembly. An interconnect harness carries the signal to the first module, and the signal relays from module to module, in daisy-chain style, until it reaches the last module on the message center.
Page 48: Tnmc Controller
• TNMC Controller • Modules and Drivers • Power Supplies The subsections also address diagnostic LEDs and signal/power connectors found on the TNMC controller. Note: Disconnect power before servicing internal components! TNMC Controller Reference Drawings: 4 Column MASC LED Driver Specifications....Drawing A-166216 Component Locations;...
Page 49 Diagnostic LEDs Reference Drawing: 4 Column MASC LED Driver Specifications ....Drawing A-166216 There are seven diagnostic LEDs located on the TNMC controller, six indicating when the controller is receiving signal, and the seventh indicating power status. Four of the LEDs, those indicating CAN and RS-232 signal functions, are not used with the TNMC controller.
Page 50 Color Function Operation Summary CL signal Steady on DS1 will be on or blinking when the or blinking driver is receiving signal and off when there is no signal with CL (current loop). Green CL signal Steady on DS2 will be on or blinking when the or blinking driver is receiving signal and off when there is no signal with CL...
Page 51: Figure 17: Tnmc Internal Components (Modules Removed)
Removing/Changing the Controller Reference Drawings: Component Locations; 832/842 Red/Amb LED TNMC, G3 ........Drawing A-187987 Exploded Front View; Single Panel Module....Drawing B-126111 Exploded Rear View; Single Panel Module ....Drawing B-126112 Use this reference after 11/29/05 Component Locations; 832/848 Red/Amb LED TNMC, G4 ........Drawing A-257029 Drawing A-187987 (or A-257029 for GEN IV) indicates the location of the TNMC controller for each of the TNMC models.
Page 52: Modules And Drivers
above, remove the appropriate rear-access panel from the TNMC by loosening all four of the screws. Slide the access panel sideways to the larger part of the keyhole and carefully lift it off the TNMC. Take care not to drop the panel and remember that the module controller is attached to the panel.Disconnect power from J17.
Page 53: Power Supplies
Drawings B-126111 and B-126112 illustrate the various module components. Individual components such as louvers can be removed for service, but Daktronics recommends that the module be kept intact and that the entire assembly be sent in for repair or replacement.
Page 54: Display Maintenance
the entire display and around each module. It is important that the weatherstripping is attached properly at all times, or water may leak into the display and damage the components. Display Maintenance Complete a yearly inspection to maintain safe and dependable display operation. This inspection should address the following issues: Loose Hardware •...
Page 55: Initialization Information At Startup
Symptom/Condition Possible Cause/Remedy Replace the power supply assembly on the first module that is not working. Replace the ribbon cable. One row of modules does not work Replace the first module. or is garbled. Replace the controller. A group of modules that share the Replace the power supply assembly.
Page 56 Red LED TNMC, 8x48 0A-1192-2552 To prevent theft, Daktronics recommends purchasing a lockable cabinet to store manuals and replacement and spare parts. Refer to Section 5.9 for information on the Daktronics Exchange and Repair and Return programs. 6-14 TNMC Maintenance...
Page 57: Tnmc Maintenance For Ba-2018
Maintenance and Troubleshooting Overview Standard Daktronics outdoor LED scoreboards typically are front-accessible, but some models may be ordered with rear service access. For that reason, Daktronics team name message centers have been designed so that they may be accessed from the front and rear for easy maintenance and repair of internal components.
Page 58: Signal Summary
• Service and Diagnostics: provides instructions for removing various display components and explains the functions of circuit board connectors and the meanings of any diagnostic LEDs. • Maintenance: lists a number of steps to take to keep this Team Name Message Centers in safe, working order. •...
Page 59: Service And Diagnostics
Power routing for the display can be summarized as follows: 1. Incoming power terminates at the terminal block in the scoreboard driver enclosure. Using the same harness and J42-P43 connections as signal, power is then routed to the TNMC controller where it then travels to both the power supply assembly and to a transformer on the controller tray.
Page 60: Diagnostic Leds
Diagnostic LEDs Reference Drawing: 4 Column MASC LED Driver Specifications .... Drawing A-166216 There are seven diagnostic LEDs located in the TNMC controller, six indicating when the controller is receiving signal, and the seventh indicating power status. Four of the LEDs, those indicating CAN and RS-232 signal functions, are not used with the TNMC controller.
Page 61: Removing/Changing The Controller
Removing/Changing the Controller Reference Drawings: Face Panel Assy, 2.5” LED TNMC ......Drawing B-164446 F. Assy, 8x48-2.5” LED TNMC ........Drawing B-164514 F. Assy, 8x48-2.5" LED TNMC, Amber, G3....Drawing B-177822 Face Panel Assy; 8x8-2.25" Amber TNMC....Drawing B-177836 The drawings listed above indicate the location of the TNMC controller for each of the TNMC models.
Page 62: Modules And Drivers
Modules and Drivers Reference Drawings: Face Panel Assy, 2.5” LED TNMC......Drawing B-164446 F. Assy, 8x48-2.5” LED TNMC......... Drawing B-164514 F. Assy, 8x48-2.5" LED TNMC, Amber, G3 ..... Drawing B-177822 Face Panel Assy; 8x8-2.25" Amber TNMC....Drawing B-177836 The module and driver board are a single, functional unit. To remove a module, complete the following steps: 1.
Page 63: Tnmc Display Maintenance
Disconnect all the wires connected to the power supply. Remove the hardware holding the power supply in place to free the unit. 4. Follow these steps in reverse order to install a new power supply. TNMC Display Maintenance Complete a yearly inspection to maintain safe and dependable display operation. This inspection should address the following issues: Loose Hardware •...
Page 64: Initialization Information At Startup
Cable assy; 20-pos ribbon, 30" (TNMC controller to first module) 0A-1000-0017 Electrical contact cleaner/lubricant (CaiLube) CH-1019 Assembly Part Number Amber LED TNMC, 8x48 0A-1192-2576 Red LED TNMC, 8x48 0A-1192-2575 To prevent theft, Daktronics recommends purchasing a lockable cabinet to store manuals and replacement and spare parts. TNMC Maintenance...
Page 65 Refer to Section 5.9 for information on the Daktronics Exchange and Repair and Return programs. TNMC Maintenance...
Page 67: Appendix A: Reference Drawings
Component Locations; BA-2001-11/-21, G3 ........Drawing A-180359 Component Locations; BA-2002-11/-21, G3 ........Drawing A-180360 Component Locations; BA-2001-11/-21 w/TNMC, G3 ....Drawing A-180361 Component Locations; BA-2009-11/-21 w/TNMC, G3 ....Drawing A-185787 Component Locations; BA-2008-11/-21 w/TNMC, G3 ....Drawing A-185855 Schematic; Red LED TNMC, GEN III..........Drawing A-187661 Schematic;...
Page 68 Schematic Baseball w/ S.O.P., Gen III, Optional TNMC....Drawing B-204264 Schematic BA-2018 ................ Drawing B-221946 Digit Designation; BA-2018............. Drawing B-221953 Shop Drawing; BA-2018, Horiz Tubes ..........Drawing B-222672 Clip DWG; BA-2018-11/21, G3 ............Drawing B-238121 Shop Drawing, 2-Pole, BA-2001/2008-11 or –21 ......Drawing B-257893 TNMC Maintenance...
Page 117: Appendix B: Eyebolts
Appendix B: Eyebolts Eyebolts ......................ED-7244 Eyebolts...
Page 119 Eyebolts Almost every display that leaves Daktronics is equipped with eyebolts for lifting the display. There are two standard sizes of eyebolts: ½″ and A″. Load Increase Factor: The load increases as the lift angle (θ) decreases. The allowable load on the eyebolts also decreases with the lift angle due the bending stress on the eyebolts.
Page 120 F. Eyebolts should never be painted or otherwise coated when used for lifting. Such coatings may cover potential flaws in the eyebolt. G. To attain the safe working loads listed for regular eyebolts, 90% of the thread length must be engaged. Copyright 1996-2001 ED-7244 Daktronics, Inc. Rev. 4 – 14 March 2001...
