table of zones

The zone number is the number of LED flashes used by the
system to identify that input. The standard input assignments
are listed below, along with spaces to write in any optional
sensors or switches you have had installed.
Zone - Number
of LED Flashes
1
2
3
4
5
➜

interpreting zone diagnostics

Warn Away responses are not reported by arming or disarming
diagnostics. If you receive a Bypass notification when arming or
a Tamper Alert notification when disarming, look at the LED.
Active or triggered zones will be indicated by a pattern of blinks
by the LED.
Example
If zone 3 was active or triggered, the LED will blink three times
with a two-second pause. Then it will blink three times again,
and repeat until the ignition is turned on.
16
Description
Instant trigger - often used
for hood/trunk pinswitches
Instant trigger - a heavier impact
detected by the shock sensor
Door switch trigger
Instant trigger - for optional sensors
Ignition trigger
© 2005 directed electronics—all rights reser ved
Dealer-Installed
Options
