IPC1601&2602&5602&5603
V100R001C03SPC600
User Guide
Issue
12
Date
2014-06-12
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPC1601 and is the answer not in the manual?

Questions and answers

Related Manuals for Huawei IPC1601

Summary of Contents for Huawei IPC1601

  • Page 1 IPC1601&2602&5602&5603 V100R001C03SPC600 User Guide Issue Date 2014-06-12 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope.

  • Page 3: About This Document

    This document is a user manual for IP box cameras, including the product features, hardware installation, network access, network configuration, daily maintenance, and troubleshooting. This document applies to IPC5602, IPC1601, IPC5603, and IPC2602. Intended Audience This document is intended for: ...
  • Page 4 Modified the privacy masking page. 6.1 Setting Local Network Parameters Modified the local network page and description of parameters. Deleted 9.3.1 Configuring a Permission Group Deleted the permission group parameters table. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 5 7.3 Setting Motion Detection Alarm Linkage Parameters Modified Setting Motion Detection Alarm Linkage Parameters 7.4.1 Configuring the Alarm Reporting Interval Modified the motion detection alarm latch. 9.2 Querying Device Logs Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 6 This issue is the fifth official release, compared to issue 04: Modified About This Document Modified special notices. 2.2 Features Modified description about the security features. 3.1 Preparing Installation Tools Modified preparing installation tools. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 7 Added description about lightening protection measures and working high above the ground. 2.2 Features Added description about the security features. 6.3.2 Setting Security Authentication Added description about security authentication. Modified 9.4 Upgrading Devices Modified description about device upgrade. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 8 The device may be upgraded without prior notice. To download the latest program and supplementaty documentation, visit http://support.huawei.com/enterprise Product Support > Unified Communications and Collaboration > Video Surveillance > Cameras > Specialty Cameras > IPE Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 9: Table Of Contents

    5.9 Configuring the Privacy Mask Function ........................34 5.10 Configuring the SD Card ............................35 6 Network Configuration ......................37 6.1 Setting Local Network Parameters ..........................37 Issue 12 (2014-06-12) Huawei Proprietary and Confidential viii Copyright © Huawei Technologies Co., Ltd.
  • Page 10 9.6 Restarting a Device ..............................73 9.7 Restoring a Device to Factory Settings ........................74 9.8 Collecting Logs................................75 10 Troubleshooting ........................77 11 Technical Specifications ......................79 Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 11: Safety Precautions

    The actual device governs, and this document is only for reference.  The device may be upgraded without prior notice.  For the latest programs and supplementary documentation, contact Huawei customer service center.  If any problems occur during use, contact the supplier or customer service center.
  • Page 12 Deploy surge protection devices if the device is installed outside.  When working high above the ground, take security measures, such as wearing helmets and safety belts and choosing secure elevating apparatus. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 13 IPC1601&2602&5602&5603 User Guide 1 Safety Precautions Personnel Precautions The device-related installation and maintenance can only be performed by professional technical engineers or specific installation personnel. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 14: Overview

    Figure 2-2 shows the ports on the body of an IP box camera. Table 2-1 describes the ports. Figure 2-2 Ports on the body of an IP box camera Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 15 Status indicator Indicates the running status of the camera. The status is described as follows:  On: The camera is powered on.  Blinking: The camera is restarting. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 16: Features

    Network Features  Supports the complete TCP/IP protocol suite. Support video, audio, and alarm data. Provides a built-in web browser and supports access using Microsoft Internet Explorer. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 17 Software packages and upgrade packages have been scanned by anti-virus softwares (such as Symantec, Trend officeScan, Mcafee, Avira AntiVir, Kaspersky, etc.), and the scanning results are provided in the version description document. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 18: Hardware Installation

    Table 3-1 lists installation tools that you must prepare. Table 3-1 Installation tools Tool Description Phillips screwdriver Claw hammer Hammer drill Level ruler 3.2 Installing a Lens Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 19: Installing An Auto Aperture And Manual Focus Lens

    Step 3 Install the C/CS mount adapter to the camera. Step 4 Attach the lens to the camera body and turn the lens clockwise until it locks into place. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 20: Uninstalling A Lens

    3.3 Connecting Other Devices to the Camera Through the Ports on the Rear Panel Figure 3-2 shows how to connect other devices to the camera through the ports on the rear panel. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 21 IPC1601&2602&5602&5603 User Guide 3 Hardware Installation Figure 3-2 Device connections Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 22: Quick Access

    Step 1 Open Internet Explorer, enter the IP address of the IP camera (default value: 192.168.0.120) in the address box, and press Enter. The login page is displayed, as shown in Figure 4-1. Figure 4-1 Login page Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 23: Main

    Figure 4-2 shows the main page layout. Table 4-1 describes the elements on the main page. Figure 4-2 Main page layout Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 24 This function is available only to High speed network dome  and a camera connected to an external PTZ. Sign Out You can click this button to return to the login page. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 25: Browsing Videos

    Step 1 Open Internet Explorer. Choose Tools > Internet Options > Security > Trusted sites > Sites. In the displayed dialog box, click Add, as shown in Figure 4-3. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 26 ActiveX controls and plug-ins to Enable, as shown in Figure 4-4. Figure 4-4 Configuring ActiveX controls and plug-ins Step 3 Download and install the player control as prompted. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 27 You can right-click in the video area. A shortcut menu is displayed and allows you to enter the full-screen mode, set sensor parameters, zoom in or out, and return to the default view. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 28: Controlling And Configuring The Ptz

    Table 4-2 PTZ control buttons Button Description Zoom Click to zoom the lens in or out. Focus Click to adjust the focal length. Iris Click to adjust the auto aperture. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 29 The 3D positioning function quickly rotates the PTZ and changes the focal length in specific scenarios. You can also change the focus by drawing rectangle frames.  Set the direction to due north. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 30 Step 2 Invoke a track. Select a track from the Track drop-down list box to invoke the track. A maximum of six tracks can be configured. ----End Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 31: Device Configuration

    When the device is upgraded, the device information is updated automatically. Procedure Step 1 Click Device Info. The Device Info page is displayed, as shown in Figure 5-1. Figure 5-1 Device Info page Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 32: Setting Video And Audio Stream Parameters

    For details, see 9.3.1 Configuring a Permission Group. ----End 5.2 Setting Video and Audio Stream Parameters Procedure Step 1 Click Stream Configuration. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 33 Experts Group (MJPEG) codec.  The maximum resolution can be set for streams 1 and 3.  Only a low resolution can be set for stream 2. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 34  G.711_ALAW: mainly used in Europe and other areas.  RAW_PCM: codec of uncompressed audio data. This codec is often used for platform data. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 35 The bit rate changes according to the image complexity. The encoding efficiency is high and the definition of motion images can be ensured. Step 3 Click OK. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 36: Setting The Channel Name, Video System, And Source Resolution

    Select a value from the drop-down list box. [Default value] Channel name within the length of 0 Channel Name [Setting method] to 32 bytes. Enter a value manually. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 37: Setting Osd Parameters

    When the resolution is D1 and CIF, the OSD customed in web interface can show at most 32 words normally.  The OSD support simplified Chinese, English and digital only. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 38 Step 3 Set the parameters according to Table 5-4. The size of characters that can be displayed in a row or column varies according to the resolution. When the OSD font is auto: Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 39 0 to 32 window. characters in Custom OSD. Row where the information starts to [Setting method] display. Enter a value manually. [Default value] 0 (original point) Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 40: Configuring The Microphone

    Procedure Step 1 Choose Device Configuration > Microphone. The Microphone page is displayed, as shown in Figure 5-5. Table 5-5 describes the parameters. Figure 5-5 Microphone page Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 41: Configuring The Dome Ptz Address

    This function is available to a PTZ camera. Procedure Step 1 Choose Device Configuration > Dome PTZ. The Dome PTZ page is displayed, as shown in Figure 5-6. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 42: Enabling The Analog Output Function

    VIDEO OUT port. Procedure Step 1 Choose Device Configuration > BNC Output. The BNC Output page is displayed, as shown in Figure 5-7. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 43: Configuring The System Language And Web Mode

    The System Configuration page is displayed, as shown in Figure 5-8. Figure 5-8 System Language page Step 2 Select a language from the language drop-down list box. Step 3 Click Set. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 44: Configuring The Privacy Mask Function

    Step 1 Click Blind Area. The Privacy Masking page is displayed, as shown in Figure 5-9. Figure 5-9 Privacy Masking page Step 2 Select Enable Privacy Masking. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 45: Configuring The Sd Card

    Figure 5-10 SD card information page If the disk status is not OK when insert the SD card, please restart the IPC, Set the parameters according to Table 5-6. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 46 ----End Result After finishing format, the message of “Disk format is successful” is displayed. Click OK. Disk capability will display the maximum disk storage capacity. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 47: Network Configuration

    Preferred Domain Name System (DNS) server  Alternate DNS server  Procedure Step 1 Choose Device Configuration > Local Network. The Local Network page is displayed, as shown in Figure 6-1. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 48 IP address that the DHCP server assigned to the device. IP Address Device IP address that can be set as [Setting method] required. Enter a value manually. [Default value] 192.168.0.120 Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 49: Configuring Device Ports

    6.2 Configuring Device Ports Description You must configure the HTTP port, control port, and Real Time Streaming Protocol (RTSP) port for device route mapping in a LAN. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 50 HTTP port, and RSTP port, see the Communication Matrix. Step 3 Click OK.  If the Device Port dialog box is displayed, click OK. The system automatically saves the settings. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 51: Setting Platform Parameters

    When an ONVIF-compliant device connects to the platform, you must authenticate the user name and password to ensure the connection security. Procedure Step 1 Choose Protocol > Security. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 52: Setting Protocol Parameters

    Choose Protocol > CMS Register Info. The CMS Register Info page shown in Figure 6-5 is displayed. Table 6-5 describes the parameters on the CMS Register Info page. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 53 Enter a value manually. Device Register ID Unique device identifier used by Enter a value manually. the platform. NOTE Set this parameter based on the platform requirements. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 54: Viewing The Adsl Network Parameters

    If the device uses PPPoE to connect to the Internet, the current IP address is displayed in IP Address.  If the device connects to the Internet in other modes, the currently IP address is not displayed in IP Address. ----End Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 55: Setting Pppoe Parameters

     If the message "PPPoE Parameter Updated" is displayed, click OK. The system automatically saves the settings.  If other information is displayed, set the parameters correctly. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 56: Setting Ddns Parameters

    Select the check box. [Default value] Deselected Provider DDNS service provider. Currently, only [Default value] 3322 and DynDns are supported. 3322 NOTE Set this parameter based on the site requirements. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 57 If the message "DDNS Parameter Updated" is displayed, click OK. The system automatically saves the settings.  If other information is displayed, set the parameters correctly. ----End Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 58: Alarm Configuration

    Step 1 Choose Alarm Configuration > Alarm I/O. The Alarm I/O page is displayed, as shown in Figure 7-1. Figure 7-1 Alarm I/O page Step 2 Set the parameters according to Table 7-1. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 59 If the pulse mode is used, the alarm  frequency of the external alarm device can be configured. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 60: Setting I/O Alarm Linkage Parameters

    On the I/O Alarm Linkage page, you can perform the following operations:  Enable the I/O alarm function.  Configure the I/O alarm schedule.  Configure the alarm output channel.  Configure the PTZ linkage policy. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 61 Configure time segments as required. Click OK. The system automatically saves the settings. Step 4 Configure the PTZ linkage policy. Set the Camera ID, Type, and Name parameters. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 62: Setting Motion Detection Alarm Linkage Parameters

    Step 1 Choose Alarm Configuration > Motion Alarm. The Motion Alarm page is displayed, as shown in Figure 7-4. Table 7-2 describes the motion detection alarm parameters. Figure 7-4 Motion Alarm page Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 63 Select a value from the drop- objects are easier to be detected. Set this down list box. parameter based on the site [Default value] requirements. Step 2 Select Enable. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 64 For details, see 7.2 Step 4 Configure the PTZ linkage policy. Step 6 Click OK. The message "Motion Alarm Updated" is displayed. Step 7 Click OK. The system automatically saves the settings. ----End Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 65: Processing Alarms

    The system automatically saves the settings. ----End 7.4.2 Configuring the Alarm Center Procedure Step 1 Choose Service Center > Alarm Center. The Alarm Center page is displayed, as shown in Figure 7-7. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 66: Setting Smtp Parameters

    JPG images and alarm information to specified email addresses when an alarm is generated. Procedure Step 1 Choose Service Center > SMTP. The SMTP page is displayed, as shown in Figure 7-8. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 67 Port number of the SMTP [Setting method] server. Enter a value manually. [Default value] User Name User name of the mailbox for [Setting method] sending emails. Enter a value manually. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 68 If the message "SMTP Service Parameter Updated" is displayed, click OK. The system automatically saves the settings.  If other information is displayed, set the parameters correctly. ----End Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 69: External Device Configuration

    PTZ; otherwise, the external PTZ cannot be used. Procedure Step 1 Choose External Device > PTZ. The PTZ page is displayed, as shown in Figure 8-1. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 70 4 to 8. Generally, the value the settings on the is 8. external PTZ. Stop Bits Parity Verification Step 3 Click OK. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 71: Setting External Ptz Keyboard Parameters

    PTZ keyboard cannot be used. Procedure Step 1 Choose External Device > PTZ Keyboard. The PTZ Keyboard page is displayed, as shown in Figure 8-2. Figure 8-2 PTZ Keyboard page Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 72 PTZ keyboard. Step 3 Click OK. The message "Setting PTZ keyboard Updated" is displayed. Step 4 Click OK. The system automatically saves the settings. ----End Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 73: Daily Maintenance

    Network Time Protocol (NTP) server Procedure Step 1 Choose Device Configuration > Date&Time. The Date&Time page is displayed, as shown in Figure 9-1. Table 9-1 describes the parameters. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 74 Since March 27, 2011, Russia has started to use permanent DST. Device Time Device display time. [Setting method]  Synchronize the time from the PC.  Enter a value manually.. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 75 Enter the IP address or domain name of the NTP server and the port number. Step 6 Click OK. The message "Parameter Updated" is displayed. Step 7 Click OK. The system automatically saves the settings. ----End Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 76: Querying Device Logs

    Step 3 Click Query. The operation logs related to the specified user are displayed. Step 4 Download the operation logs. Set the start time, end time and log type. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 77: Querying Alarm Logs

    The Alarm Log page is displayed, as shown in Figure 9-3. Figure 9-3 Alarm Log page Step 2 Set the query start time and end time. Click the Begin Time and End Time text boxes respectively. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 78: Configuring User Permissions

    Only the users with the Privilege Manage permission can access the Group and User pages. Procedure Step 1 Choose Privilege Manager > Group. The Group page is displayed, as shown in Figure 9-4. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 79 The group is modified successfully. The Group page is displayed. Delete Select the group from the Group drop- Delete a group. down list box. Click Delete, then the Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 80: Configuring A User

    Figure 9-5 User page Table 9-3 User parameters Parameter Description Setting User User name for logging in to the camera [Setting method] Select a value from the drop-down list box. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 81 A password cannot be the  same as the user name or the reverse of the user Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 82: Upgrading Devices

    The only open interface provided the device is the SSH interface for logging in to the device during the system upgrade and maintenance. To upgrade the device, you must use a Huawei- provided upgrade tool to connect to the device. If you use other tools, the device may be damaged.

  • Page 83: Restarting A Device

    The device parameters are set incorrectly, and the device cannot work properly.  A user needs to reset device parameters and make the setting to take effect.  A device needs to be restarted remotely. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 84: Restoring A Device To Factory Settings

    Use this function carefully. Procedure Step 1 Choose Maintenance > Default Settings. The Default Settings page is displayed, as shown in Figure 9-8. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 85: Collecting Logs

    Log Reference. Procedure Step 1 Choose Maintenance > Collect Log. The Collect Log page is displayed, as shown in Figure 9-9. Figure 9-9 Collect Log page Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 86 Click Collect Log. The log link and the message "Please download log by ‘save as’ in the right key" are displayed. Right-click the link and save the logs. ----End Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 87: Troubleshooting

    Check the IP address, subnet mask, and the PC and IP gateway settings on the IP camera, and camera are on change the settings as required. different networks. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 88  Verify that the network cable is properly connected. The upgrade Obtain the correct upgrade package and package is upgrade the IP camera again. incorrect. Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.

  • Page 89: Technical Specifications

    11 Technical Specifications Technical Specifications This document applies to IPC5602, IPC1601, IPC5603, and IPC2602. These models have the same appearance and structure and different sensors. Table 11-1 lists the technical specifications for specific sensors. For details about other technical specifications, see the product documentation.
  • Page 90 1280 x 720@25 fps megapixel 1/3" 1.3-  B/W: 0.01 640 x 360@25 fps megapixel Lux@F1.2 CMOS) progressive  NTSC: scan CMOS 1280 x 720@30 fps 640 x 360@30 fps Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 91 International Standard Organized Internet Protocol Identity Internet Protocol Camera MJPEG Motion Joint Photographic Experts Group Media Access Control Network Time Protocol NTSC National Television Standards Committee On Screen Display Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
  • Page 92 PPPoE Point-to-Point Protocol over Ethernet Pan Tilt Zoom Service Control Center SMTP Simple Mail Transfer Protocol Variable Bit Rate ADSL Asymmetric Digital Subscriber Line Constant Bit Rate Issue 12 (2014-06-12) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
