Backyard Discovery Weston 65113 Owner's Manual & Assembly Instructions
  1. Manuals
  2. Brands
  3. Backyard Discovery Manuals
  4. Play Sets & Playground Equipment
  5. Weston 65113
  6. Owner's manual & assembly instructions

Backyard Discovery Weston 65113 Owner's Manual & Assembly Instructions

Wooden swing set
Hide thumbs

Advertisement

Quick Links

Download this manual
Weston
MANUFACTURED BY:
Wooden Swing Set
Backyard Discovery
3305 Airport Drive
Pittsburg, KS 66762
Model # 65113
Owner's Manual & Assembly Instructions
800-856-4445
average 2 person assembly time
assembly time may vary based on skill level
For the most up to date assembly manual,
to register your set, or to order replacement parts please visit
www.backyarddiscovery.com
SAVE THIS ASSEMBLY MANUAL FOR FUTURE REFERENCE IN THE EVENT THAT
YOU NEED TO ORDER REPLACEMENT PARTS.
Made in China | INS-65113-B-WESTON-ENG 4-29-19

Advertisement

loading
Need help?

Need help?

Do you have a question about the Weston 65113 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Backyard Discovery Weston 65113

Summary of Contents for Backyard Discovery Weston 65113

  • Page 1 Weston MANUFACTURED BY: Wooden Swing Set Backyard Discovery 3305 Airport Drive Pittsburg, KS 66762 Model # 65113 Owner's Manual & Assembly Instructions 800-856-4445 average 2 person assembly time assembly time may vary based on skill level For the most up to date assembly manual, to register your set, or to order replacement parts please visit www.backyarddiscovery.com...
  • Page 2 INSTALLATION SERVICES AVAILABLE! Need a helping hand? Let our team of professionals handle the installation for you! *Installation services are only available to U.S. customers. With Go Configure, we bring you 18 years of experience right to your doorstep. We service a wide array of indoor and outdoor recreation products that most consumers don’t have the time or ability to deliver &...
  • Page 3 Owner’s Manual Please Read This Before Starting Assembly MISSING A PART? CALL US BEFORE GOING BACK TO THE STORE Th e store where you made your purchase does not stock parts for this item. If you have assembly questions or you are missing or have damaged parts, please call 1-800-856-4445 you can also visit www.backyarddiscovery.com...
  • Page 4 Botanical, Adventure Playsets, and Leisure Time Products. Backyard Discovery warrants that this product is free from defect in materials and workmanship for a period of one (1) year from the original date of purchase. Th is one (1) year warranty covers all parts including wood, hardware, and accessories. All wood carries a fi ve (5) year pro-rated warranty against rot and decay. Refer to the schedule below for charges associated with replacement of parts under this Limited Warranty.
  • Page 5 Owner’s Manual Operating Instructions and Safety Warnings WARNING: BURN HAZARD • Pay special attention to plastic and metal surfaces as they may be hot enough to cause burns. • Always check the temperature of the product before NOTE: letting your children play on it. •...
  • Page 6 Owner’s Manual Please Read This Before Starting Assembly Positioning Your Playcenter Suggested Playground Surfacing • Th e playcenter is designed to be installed on a level • Do not install home playground equipment over surface by an adult with an adult helper. Place concrete, asphalt, packed earth, grass, carpet, or any in a fl at area of your yard to minimize ground other hard surface.
  • Page 7 Owner’s Manual Please Read This Before Starting Assembly APPENDIX A The following information is from the United States X3.1.3.2 Do not install loose-fi ll surfacing over hard surfaces such as concrete or asphalt. Consumer Product Safety Commission’s Information X3.1.4 Poured-In-Place Surfaces or Pre-Manufactured Sheet for playground surfacing material;...
  • Page 8 Check all moving parts including swing seats, third party person or service to assemble this product. ropes, cables, and chains for wear, rust, or other Backyard Discovery assumes no responsibility or deterioration. Replace as needed. liability for any charge incurred by the Customer for any assembly services’...
  • Page 9 About Our Wood Backyard Discovery uses 100% Cedar (C. Lanceolata) wood. Although we take great care in selecting the best quality lumber available, wood is still a product of nature and susceptible to weathering which can change the appearance of your set.
  • Page 10 Owner’s Manual Assembly Tips Protrusion Hazard Incorrect Correct If you see exposed threads and your bolt protrudes beyond the T-Nut you may have over tightened the bolt or used incorrect hardware. If you’ve overtightened, remove the bolt and add washers to eliminate the protrusion.
  • Page 11 Owner’s Manual Assembly Tips ASSEMBLY TIP: Keep an eye out for these boxes which will contain helpful pictures and information making the assembly process as quick and painless as possible. Sorting Wood When removing the wood from the boxes we recommend arranging them by part number before you begin assembly.
  • Page 12 Tools Required for Installation: (These are the tools that are generally required for assembly of our outdoor products. These tools are not included with the outdoor product purchase.) (Square) (Level 24") (Tape Measure) (Phillips Screw Driver) (Open End Wrenches 1/2") (Drill Attachments: (1/8", 5/16"...
  • Page 13 Basic Setup Dimensions Place the set on level ground, not less than 6 ft [2 m] from any structure or obstruction such as a fence, garage, house, overhanging branches, laundry lines, or electrical wires. 13'-1 9/16" [4 m] 10'-10 3/16" [3.3 m] 6'-0"...
  • Page 14 Parts Identification Wood Components (NOT TO SCALE) E1 - UPRIGHT - W103800 1 3/8"x3 3/8"x81 3/4" (36x86x2076) E2 - UPRIGHT - W103807 1 3/8"x3 3/8"x81 3/4" (36x86x2076) E3 - UPRIGHT - W103809 1 3/8"x3 3/8"x81 3/4" (36x86x2076) E4 - UPRIGHT - W103808 1 3/8"x3 3/8"x81 3/4"...
  • Page 15 Parts Identification Wood Components (NOT TO SCALE) H9 - HORIZONTAL TARP SUPPORT - W103818 1"x3 3/8"x54 3/4" (24x86x1392) H10 - SHELF SUPPORT - W103961 1"x3 3/8"x3 3/8" (24x86x86) H73 - ROCK WALL RAIL - W100024 24"x86"x1238" (24x86x1238) H79 - END SUPPORT - W100992 1"x3 1/2"x42"...
  • Page 16 Parts Identification Wood Components (NOT TO SCALE) M2 - BENCH SEAT - W104043 5/8"x3 3/8"x24 3/8" (16x86x618) M3 - FLOOR BOARD - W103824 5/8"x3 3/8"x17 5/8" (16x86x448) M4 - FLOOR BOARD - W103823 5/8"x3 3/8"x22 3/8" (16x86x568) M5 - FLOOR RAIL - W103805 5/8"x3 3/8"x30"...
  • Page 17 Parts Identification Wood Components (NOT TO SCALE) M102 - ATTACHMENT BOARD - W103690 5/8"x3 3/8"x20 1/4" (16x86x514) N1 - WINDOW BOARD - W103828 5/8"x2 3/8"x21 1/2" (16x60x546) SB74 - SWING BEAM EXTENDED - W102419 2"x5 1/4"x89 1/2" (50x134x2274) W71 - SWING BEAM SUPPORT - W102420 2"x3 3/8"x49 5/8"...
  • Page 18 Parts Identification Hardware (95) BR - SCREW PFH 8x1-1/8 - H100088 (84) BP - SCREW PFH 8x1-1/2 - H100086 (26) BS - SCREW PFH 8x1-3/4 - H100089 - T-40 Torx Bit - A100042 (13) CK - SCREW PFH 8x2 - H100111 BT - SCREW PFH 8x2-1/2 - H100090 (26) BW - SCREW PFH 8x3 - H100092...
  • Page 19 Parts Identification Hardware (13) B - NUT BARREL WH 5/16x5/8 - H100004 (11) CM - BOLT WH 5/16x1/2 - H100115 F - BOLT WH 5/16x1 - H100008 (60) D - NUT BARREL WH 5/16x7/8 - H100005 (25) H - BOLT WH 5/16x1-1/2 - H100010 C - NUT BARREL WH 5/16x1-1/2 - H100006 J - BOLT WH 5/16x1-3/4 - H100011 (28)
  • Page 20 Parts Identification Hardware AN - BOLT HEX 5/16x2-3/4 - H100047 AJ - BOLT HEX 5/16x1 1/4 - H100042 A - BOLT FA 3/8x1 1/2 - H100001 (16) CY - SCREW PWH 8x5/8 - H100128 BF - T-NUT 3/8 - H100073 BG - T-NUT 5/16 - H100074 CJ - NUT LOCK 5/16 - H100110...
  • Page 21 Parts Identification Accessories (NOT TO SCALE) FB - SWING SEAT YELLOW - A100070 FA - QUICK LINK - A100069 ES - L BRACKET GREEN 32x51 - A100061 HC - BYD ID TAG (LARGE) 2011 WITH AGES - A100164 GD - L BRACKET 66x66x127 - A100140 TC - SWING BEAM EXTENSION BRACKET-RIGHT - A100326 TB - SWING BEAM EXTENSION BRACKET-LEFT - A100325 EM - SLIDE BED 8' YELLOW - A100056...
  • Page 22 Parts Identification Accessories (NOT TO SCALE) EA - HAND GRIP YELLOW PLASTIC - A100043 ER - CLIMBING ROCK GREEN SMALL - A100060 - TRAPEZE - A6P00034 WT - TARP .4x752x2309 - A100398 KN - CHAIN GREEN 31" - A100177 EZ - CHAIN GREEN 51.25" - A100068 SR - "B"...
  • Page 23 SB74 - SWING BEAM EXTENDED - W102419 2"x5 1/4"x89 1/2" (50x134x2274) GD - L BRACKET 66x66x127 - A100140 TC - SWING BEAM EXTENSION BRACKET-RIGHT - A100326 TB - SWING BEAM EXTENSION BRACKET-LEFT - A100325 4 FT GREEN EXTENDED SWING BEAM WITH TRAPEZE BOLT WH 5/16x1-3/4...
  • Page 24 E77 - ANGLE BRACE - W100991 W71 - SWING BEAM SUPPORT - W102420 1 3/8"x3 3/8"x74 3/8" (36x86x1890) 2"x3 3/8"x49 5/8" (50x86x1260) H79 - END SUPPORT - W100992 H80 - GROUND BOARD - W100990 1"x3 1/2"x42" (24x86x1072) 1"x3 3/8"x87 3/8" (24x86x2218) STEP 2 ATTACH H80 GROUND BOARD TO (2) E77 ANGLED SUPPORT BOARDS USING 2"...
  • Page 25 STEP 3 INSERT W71 BOARD INTO TB AND TC BRACKET OPENING AND SECURE USING 1-3/4" BOLTS AND 7/8" BARREL NUTS, AS BOLT WH SHOWN. 5/16x1-3/4 BOLT WH 5/16x2-1/2 INSERT 2-1/2" BOLTS, LOCK WASHERS AND 1-1/2" BARREL NUTS INTO THE EDGE OF W71 BOARD, AS SHOWN.
  • Page 26 STEP 4 INSERT (6) SWING HANGER QUICK LINK INTO SB74 SWING BEAM USING SAFETY NUT LOCK 5/16 WASHERS, FLAT WASHERS AND 5/16" LOCK NUTS, AS SHOWN. WASHER FLAT 8x27 SB74 WASHER SAFETY 17x30 SWING HANGER QUICK LINK SB74...
  • Page 27 M72 - ROCK WALL SLAT - W100023 H73 - ROCK WALL RAIL - W100024 M71 - ROCK BOARD - W100022 5/8"x3 3/8"x20 1/4" (16x86x514) 24"x86"x1238" (24x86x1238) 5/8"x3 3/8"x20 1/4" (16x86x514) 4' Rock Ladder Phase 1 Phase Notes • Assemble slats to rails as shown. •...
  • Page 28 ER - CLIMBING ROCK GREEN SMALL - A100060 4' Rock Ladder Phase 2 & 3 Phase Notes • Oreint top edge of rocks with top edge of slats. BOLT FA • Fasten rocks as shown. 3/8x1 1/2 SCREW PFH 8x1 1/8 T-NUT 3/8 BOLT FA 3/8x1 1/2 (6 PLCS)
  • Page 29 8 FOOT SLIDE ASSEMBLY PHASE 1 STEP 1 PLACE SLIDE BRACE CENTERED ON THE BOTTOM 1/4" FROM THE EDGE. TRANSFER HOLES ON THE BOARD THROUGH THE SLIDE BED AS SHOWN BELOW. USE A 3/8" DRILL BIT. ATTACH SLIDE BRACE TO SLIDE USING HARDWARE SHOWN. DESCRIPTION SLIDE BRACE BOLT WH 5/16x1/2...
  • Page 30 8 FOOT SLIDE ASSEMBLY PHASE 2 STEP 2 PLACE 1 SLIDE RAIL ON A FLAT SURFACE AND BEGIN INSERTING SLIDE BED AT THE BOTTOM OF THE SLIDE RAIL (FIG. 1). PUT SLIDE SUPPORT BOTTOM INTO THE SUPPORT POCKET AT THE BOTTOM OF THE RAIL AND HAVE A HELPER BEND THE SLIDE BED TOWARDS THE TOP OF THE SLIDE AND INSERT THE BED INTO THE SLIDE CAVITY.
  • Page 31 K6 - DECORATIVE WALL BOARD - W103829 E1 - UPRIGHT - W103800 5/8"x5 1/4"x30 3/4" (16x134x780) 1 3/8"x3 3/8"x81 3/4" (36x86x2076) E3 - UPRIGHT - W103809 K5 - WINDOW ARCH BOARD - W103811 K3 - GROUND BOARD - W103801 1 3/8"x3 3/8"x81 3/4" (36x86x2076) 5/8"x5 1/4"x30 3/4"...
  • Page 32 E2 - UPRIGHT - W103807 H9 - HORIZONTAL TARP SUPPORT - W103818 1 3/8"x3 3/8"x81 3/4" (36x86x2076) 1"x3 3/8"x54 3/4" (24x86x1392) E4 - UPRIGHT - W103808 M8 - WALL RAIL - W103813 K4 - WALL RAIL - W103810 5/8"x3 3/8"x30 3/4" (16x86x780) 1 3/8"x3 3/8"x81 3/4"...
  • Page 33 K1 - GROUND BOARD - W103803 5/8"x5 1/4"x30" (16x134x762) STEP 3 LAG SCREW WH 5/16x2 WASHER LOCK EXT 8x19 WASHER LOCK EXT 8x19 (4 PLCS) LAG SCREW WH 5/16x2 LAG SCREW WH 5/16x2 (4 PLCS) (4 PLCS) WASHER LOCK EXT 8x19 (4 PLCS)
  • Page 34 M5 - FLOOR RAIL - W103805 K2 - ARCH BOARD - W103812 5/8"x3 3/8"x30" (16x86x762) 5/8"x5 1/4"x30" (16x134x762) STEP 4 LAG SCREW WH 5/16x2 WASHER LOCK EXT 8x19 LAG SCREW WH 5/16x2 (4 PLCS) WASHER LOCK EXT 8x19 (4 PLCS) LAG SCREW WH 5/16x2 (2 PLCS) WASHER LOCK EXT 8x19...
  • Page 35 M6 - FLOOR RAIL - W103806 K2 - ARCH BOARD - W103812 5/8"x3 3/8"x30" (16x86x762) 5/8"x5 1/4"x30" (16x134x762) STEP 5 T-NUT 5/16 (2 PLCS) LAG SCREW WH 5/16x2 WASHER LOCK EXT 8x19 T-NUT 5/16 LAG SCREW WH 5/16x2 (4 PLCS) WASHER LOCK EXT 8x19 (4 PLCS) LAG SCREW WH 5/16x2...
  • Page 36 F71 - STANDARD ANGLE BRACE - W100689 1 3/8"x2 3/8"x13" (36x60x330) STEP 6 BOLT WH 5/16x1-1/2 LAG SCREW WH 5/16x2 WASHER LOCK EXT 12x19 WASHER LOCK EXT 8x19 NUT BARREL WH 5/16x7/8 NUT BARREL WH 5/16x7/8 (2 PLCS) WASHER LOCK EXT 12x19 (2 PLCS) WASHER LOCK EXT 8x19 (2 PLCS)
  • Page 37 F71 - STANDARD ANGLE BRACE - W100689 1 3/8"x2 3/8"x13" (36x60x330) STEP 7 BOLT WH 5/16x2 LAG SCREW WH 5/16x2 WASHER LOCK EXT 8x19 BOLT WH 5/16x2 (2 PLCS) WASHER LOCK EXT 8x19 (2 PLCS) WASHER LOCK EXT 8x19 (2 PLCS) LAG SCREW WH 5/16x2 (2 PLCS)
  • Page 38 M9 - FLOOR BOARD - W103822 5/8"x3 3/8"x31 1/4" (16x86x794) (2) FP1 - FLOOR PANEL - W103821 STEP 8 SCREW PFH (36) 8x1-1/2 SCREW PFH 8x1-1/2 (36 PLCS)
  • Page 39 M3 - FLOOR BOARD - W103824 5/8"x3 3/8"x17 5/8" (16x86x448) STEP 9 SCREW PFH (28) 8x1-1/8 INSIDE VIEW SCREW PFH 8x1-1/8 (14 PLCS) SCREW PFH 8x1-1/8 (14 PLCS) OUTSIDE VIEW USING A 1/8" DRILL BIT, DRILL DESIGNATED HOLES THROUGH 'M3' BOARDS. REFERENCE VIEW...
  • Page 40 H10 - SHELF SUPPORT - W103961 K7 - LEMONADE SHELF - W103825 1"x3 3/8"x3 3/8" (24x86x86) 5/8"x5 1/4"x27 7/8" (16x134x708) STEP 10 SCREW PFH 8x1-1/2 SCREW PFH 8x2-1/2 SCREW PFH 8x2-1/2 (2 PLCS) SCREW PFH 8x1-1/2 (5 PLCS)
  • Page 41 M11 - ANGLE BRACE - W103826 M8 - WALL RAIL - W103813 5/8"x3 3/8"x56 3/8" (16x86x1431) 5/8"x3 3/8"x30 3/4" (16x86x780) STEP 11 BOLT WH 5/16x1 BOLT WH 5/16x2-1/4 WASHER LOCK EXT 8x19 WASHER LOCK EXT 12x19 NUT BARREL WH 5/16x7/8 (2 PLCS) WASHER LOCK EXT 12x19 NUT BARREL...
  • Page 42 M4 - FLOOR BOARD - W103823 5/8"x3 3/8"x22 3/8" (16x86x568) STEP 12 SCREW PFH (28) SCREW PFH 8x1-1/8 8x1-1/8 (14 PLCS) SCREW PFH 8x1-1/8 (14 PLCS) 1 13/16" REFERENCE VIEW...
  • Page 43 M8 - WALL RAIL - W103813 5/8"x3 3/8"x30 3/4" (16x86x780) STEP 13 WASHER LOCK EXT 8x19 BOLT WH 5/16x1-1/2 NUT BARREL WH 5/16x7/8 WASHER LOCK EXT 12x19 NUT BARREL WH 5/16x7/8 (2 PLCS) WASHER LOCK EXT 12x19 (2 PLCS) WASHER LOCK EXT 8x19 (2 PLCS) BOLT WH 5/16x1-1/2 (2 PLCS)
  • Page 44 M4 - FLOOR BOARD - W103823 5/8"x3 3/8"x22 3/8" (16x86x568) STEP 14 SCREW PFH 8x1-1/8 SCREW PFH 8x1-1/8 SCREW PFH 8x1-1/8 (4 PLCS) (4 PLCS) REFERENCE VIEW...
  • Page 45 M1 - WALL BOARD - W103827 5/8"x3 3/8"x13" (16x86x330) STEP 15 SCREW PFH (10) 8x1 1/8 SCREW PFH 8x1 1/8 (10 PLCS) 1 13/16" REFERENCE VIEW...
  • Page 46 N1 - WINDOW BOARD - W103828 5/8"x2 3/8"x21 1/2" (16x60x546) STEP 16 SCREW PFH 8x1-1/8 FLUSH SCREW PFH 8x1-1/8 (7 PLCS) REFERENCE VIEW...
  • Page 47 M10 - END TARP SUPPORT - W103817 5/8"x3 3/8"x31 7/8" (16x86x810) STEP 17 SCREW PFH 8x2 SCREW PFH (4 PLCS) SCREW PFH 8x2 (4 PLCS)
  • Page 48 H7 - VERTICAL TARP SUPPORT - W103819 1"x3 3/8"x35 7/8" (24x86x910) STEP 18 BOLT WH 5/16x1 BOLT WH 5/16x2 WASHER LOCK EXT 12x19 WASHER LOCK EXT 8x19 WASHER LOCK EXT 8x19 NUT BARREL (1 PLC) WH 5/16x7/8 BOLT WH 5/16x2 (1 PLC) WASHER LOCK EXT 8x19 (1 PLC)
  • Page 49 H7 - VERTICAL TARP SUPPORT - W103819 1"x3 3/8"x35 7/8" (24x86x910) STEP 19 WASHER LOCK EXT 12x19 BOLT WH 5/16x1 (1 PLC) BOLT WH 5/16x1-1/2 NUT BARREL WH 5/16x7/8 (1 PLC) WASHER LOCK EXT 12x19 WASHER LOCK EXT 8x19 NUT BARREL WH 5/16x7/8 WASHER LOCK EXT 8x19 (1 PLC)
  • Page 50 M7 - TOP TARP SUPPORT - W103820 5/8"x3 3/8"x30" (16x86x762) STEP 20 SCREW PFH 8x2 (4 PLCS) SCREW PFH...
  • Page 51 WT - TARP .4x752x2309 - A100398 1/64"x29 5/8"x90 7/8" (.4x752x2309) STEP 21 SCREW PWH 8x5/8 SCREW PWH (3 PLCS) 8x5/8 SCREW PWH 8x5/8 (3 PLCS) SCREW PWH 8x5/8 (3 PLCS)
  • Page 52 EA - HAND GRIP YELLOW PLASTIC - A100043 SR - "B" REVISION TAG - A100315 STEP 22 SCREW PWH 8x5/8 LAG SCREW WH 1/4x1-1/2 WASHER LOCK EXT 6x15 WASHER LOCK EXT 6x15 (4 PLCS) LAG SCREW WH 1/4x1-1/2 (4 PLCS) SCREW PWH 8x5/8 (2 PLCS)
  • Page 53 M102 - ATTACHMENT BOARD - W103690 5/8"x3 3/8"x20 1/4" (16x86x514) (1) 4 FT ROCK LADDER STEP 23 WASHER LOCK EXT 12x19 SCREW PFH 8x1-1/2 M102 (2 PLCS) BOLT WH NUT BARREL WH 5/16x5/8 5/16x1 (2 PLCS) WASHER LOCK EXT 12x19 WASHER LOCK EXT 8x19...
  • Page 54 (1) 8 FT SLIDE ASSEMBLY STEP 24 6 5/16" BOLT WH 6 5/16" 1 5/16" 5/16x1/2 1 9/16" WASHER LOCK EXT 12x19 NUT BARREL 4 3/16" WH 5/16x5/8 DRILLING PATTERN BOLT WH 5/16x1/2 (3 PLCS) To prevent board splitting, you must pre-drill each board with a 7/16"...
  • Page 55 (1) 4 FT SWING BEAM ASSEMBLY HC - BYD ID TAG (LARGE) 2011 WITH AGES - A100164 STEP 25 SCREW PWH 8x5/8 BOLT HEX 5/16x1 1/4 WASHER SPLIT 5/16 WASHER FLAT 8x27 BOLT HEX 5/16x1 1/4 (4 PLCS) WASHER SPLIT 5/16 (4 PLCS) WASHER FLAT 8x27 (4 PLCS)
  • Page 56 FB - SWING SEAT YELLOW - A100070 FA - QUICK LINK - A100069 KN - CHAIN GREEN 31" - A100177 - TRAPEZE - A6P00034 EZ - CHAIN GREEN 51.25" - A100068 STEP 26 SWING HANGER QUICK LINK (6 PLCS)
  • Page 57 H5 - BENCH UPRIGHT - W104041 H6 - BENCH GROUND BOARD - W104042 1"x3 3/8"x11 3/4" (24x86x300) 1"x3 3/8"x18 1/8" (24x86x460) ES - L BRACKET GREEN 32x51 - A100061 STEP 27 NUT BARREL WH 5/16x7/8 BOLT WH 5/16x1/2 (2 PLCS) WASHER LOCK EXT 12x19 (2 PLCS) BOLT WH 5/16x1/2...
  • Page 58 H4 - BENCH SEAT SUPPORT - W104040 M2 - BENCH SEAT - W104043 1"x3 3/8"x6 1/2" (24x86x166) 5/8"x3 3/8"x24 3/8" (16x86x618) STEP 29 SCREW PFH 8x1-3/4 (4 PLCS) SCREW PFH 8x1-3/4 (4 PLCS) SCREW PFH 8x1-3/4 STEP 30 SCREW PFH 8x1-3/4 (4 PLCS) SCREW PFH 8x1-3/4 (4 PLCS)
  • Page 59 (1) BENCH ASSEMBLY STEP 31 BOLT WH 5/16x1/2 WASHER LOCK EXT 12x19 NUT BARREL WH 5/16x5/8 BOLT WH 5/16x1/2 (2 PLCS) NUT BARREL WH 5/16x5/8 (2 PLCS) WASHER LOCK EXT 12x19 (2 PLCS)
  • Page 60 KC - METAL GROUND STAKE BROWN - A100178 Anchoring Instructions STEP 32 BOLT WH 1/4x1/2" NOTE: BOLT WH FAILURE TO USE GROUND STAKES CAN VOID WARRANTY & CAUSE INJURY! 1/4x1 STAKE A WASHER FLAT 9x18 STAKE B WASHER STAKE A LOCK EXT 8x15 SWING...
