MANUFACTURED BY:
Summer Cottage
Playhouse
Backyard Discovery
3305 Airport Drive
Pittsburg, KS 66762
Model # 6613
Owner's Manual & Assembly Instructions
800-856-4445
WARNING
Adult Assembly Required.
Not suitable for children under two years,
due to sharp points and small parts.
Before you begin
FOR QUICK &
EASY ASSEMBLY
average 2 person assembly time
FIND 3D INSTRUCTIONS
FOR THIS PRODUCT IN
3
DOWNLOAD THE FREE APP
assembly time may vary based on skill level
For the most up to date assembly manual,
to register your set, or to order replacement parts please visit
www.backyarddisovery.com
SAVE THIS ASSEMBLY MANUAL FOR FUTURE REFERENCE IN THE
EVENT THAT YOU NEED TO ORDER REPLACEMENT PARTS.
Para obtener instrucciones en español, visite www.backyarddiscovery.com
Made in China | INS-6613-B-SUMMER COTTAGE-ENG 10-9-18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6613 and is the answer not in the manual?

Questions and answers

Related Manuals for Backyard Discovery 6613

Summary of Contents for Backyard Discovery 6613

  • Page 1 SAVE THIS ASSEMBLY MANUAL FOR FUTURE REFERENCE IN THE EVENT THAT YOU NEED TO ORDER REPLACEMENT PARTS. Para obtener instrucciones en español, visite www.backyarddiscovery.com Made in China | INS-6613-B-SUMMER COTTAGE-ENG 10-9-18...
  • Page 2 INSTALLATION SERVICES AVAILABLE! Need a helping hand? Let our team of professionals handle the installation for you! *Installation services are only available to U.S. customers. With Go Con gure, we bring you 18 years of experience right to your doorstep. We service a wide array of indoor and outdoor recreation products that most consumers don’t have the time or ability to deliver &...
  • Page 3 Owner’s Manual Please Read This Before Starting Assembly MISSING A PART? CALL US BEFORE GOING BACK TO THE STORE The store where you made your purchase does not stock parts for this item. If you have assembly questions or you are missing or have damaged parts, please call 800-856-4445 you can also visit www.backyarddiscovery.com...

  • Page 4: Limited Warranty

    Botanical, Adventure Playsets, and Leisure Time Products. Backyard Discovery warrants that this product is free from defect in materials and workmanship for a period of one (1) year from the original date of purchase. This one (1) year warranty covers all parts including wood, hardware, and accessories. All wood carries a five (5) year pro-rated warranty against rot and decay. Refer to the schedule below for charges associated with replacement of parts under this Limited Warranty.

  • Page 5: Burn Hazard

    Owner’s Manual Operating Instructions and Safety Warnings WARNING: BURN HAZARD • Pay special attention to plastic and metal surfaces as they may be hot enough to cause burns. • Always check the temperature of the product before NOTE: letting your children play on it. •...
  • Page 6 Owner’s Manual Please Read This Before Starting Assembly Positioning Your Playhouse Suggested Playground Surfacing • Do not install home playground equipment over • The playhouse is designed to be installed on a concrete, asphalt, packed earth, grass, carpet, level surface by an Adult with an Adult helper. or any other hard surface.
  • Page 7 Owner’s Manual Please Read This Before Starting Assembly APPENDIX A The following information is from the United States X3.1.3.2 Do not install loose-fill surfacing over hard surfaces such as concrete or asphalt. Consumer Product Safety Commission’s Information X3.1.4 Poured-In-Place Surfaces or Pre-Manufactured Sheet for playground surfacing material;...

  • Page 8: Instructions For Proper Maintenance

    Check all moving parts including swing seats, third party person or service to assemble this product. ropes, cables, and chains for wear, rust, or other Backyard Discovery assumes no responsibility or deterioration. Replace as needed. liability for any charge incurred by the Customer for any assembly services’...
  • Page 9 About Our Wood Backyard Discovery uses 100% Cedar (C. Lanceolata) wood. Although we take great care in selecting the best quality lumber available, wood is still a product of nature and susceptible to weathering which can change the appearance of your set.
  • Page 10 Owner’s Manual Assembly Tips Protrusion Hazard Incorrect Correct If you see exposed threads and your bolt protrudes beyond the T-Nut you may have over tightened the bolt or used incorrect hardware. If you’ve overtightened, remove the bolt and add washers to eliminate the protrusion.

  • Page 11: Assembly Tips

    Owner’s Manual Assembly Tips ASSEMBLY TIP: Keep an eye out for these boxes which will contain helpful pictures and information making the assembly process as quick and painless as possible. Sorting Wood When removing the wood from the boxes we recommend arranging them by part number before you begin assembly.
  • Page 12 SAFETY AND ASSEMBLY INFORMATION SELECTING THE CORRECT LOCATION FOR YOUR PLAY PRODUCT IS IMPORTANT FOR YOUR CHILDREN’S SAFETY AND THE PRODUCT’S LONGEVITY Dimensions: General Information: • The Summer Cottage has one layout option. Your set has been designed and engineered for Layout Ground Dimension children only and for residential use only.

  • Page 13: Parts Identification

    Parts Identification Wood Components (NOT TO SCALE) G1 - COUNTER SUPPORT - W4L05257 1"x5 1/4"x6 3/4" (24x134x170) H1 - SHELF SUPPORT - W4L05264 1"x3 3/8"x3 3/8" (24x86x86) H2 - ANGLED HEADER - W103189 1"x3 3/8"x47 1/8" (24x86x1198) H3 - HEADER - W103190 1"x3 3/8"x47 1/8"...
  • Page 14 Parts Identification Wood Components (NOT TO SCALE) K3 - RAFTER - W103194 5/8"x5 1/4"x28 7/8" (16x134x735) M2 - BENCH SEAT - W102469 5/8"x3 3/8"x27 3/8" (16x86x694) N1 - TIE STRAP - W103362 5/8"x2 3/8"x47 1/8" (16x60x1198) N2 - TIE STRAP - W103361 5/8"x2 3/8"x45 7/8"...
  • Page 15 Parts Identification Wood Components (NOT TO SCALE) WP5 - FRONT PANEL- W2A01656 1 1/8"x14"x40 5/8" (27x356x1032) RP1 - ROOF PANEL - W2A01665 1 3/8"x31 7/8"x55 3/8" (35x809x1405) WP4 - WINDOW PANEL- W2A01657 1 1/8"x14"x40 5/8" (27x356x1032) WP1 - MIDDLE PANEL - W2A01659 1 1/8"x20 5/8x"21"...
  • Page 16 Parts Identification Hardware CK - SCREW PFH 8x2 - H100111 (68) BS - SCREW PFH 8x1 3/4 - H100089 (92) BP - SCREW PFH 8x1 1/2 - H100086 - T-40 TORX BIT - A100042 BQ - SCREW PFH 8x1 1/4 - H100087 BR - SCREW PFH 8x1 1/8 - H100088 (35) SN - WASHER LOCK EXT 5x11 - H100178...
  • Page 17 Parts Identification Accessories (NOT TO SCALE) FZ - L BRACKET WHITE 32x51 - A100133 - FLOWER POT HOLDER - A6P00023 SR - "B" REVISION TAG - A100315 - SURFACE MOUNT BASIN - A6P00032 VB - PLASTIC SUNBURST - A100361 HZ - KNOB - A100071 - FAUCET KIT - A6P00024 - STOVE KIT - A6P00025 - LTP ID TAG (SMALL) WITH AGES - A4M00515...
  • Page 18 Parts Identification Accessories (NOT TO SCALE) WE - CUPOLA ROOF - A100386 WB - RIDGE CAP - A100374 WC - CUPOLA BASE - A100384 WD - CUPOLA LOUVER - A100385...
  • Page 19 STEP 1 USING THE DIAGRAM BELOW, POSITION PLAYHOUSE PANELS AND PARTS EXTERIOR SURFACE FACE DOWN AS SHOWN FOR EASE OF ASSEMBLY.

  • Page 20: Lag Screw

    P2 - POST - W103181 1 3/8"x1 3/8"x44" (36x36x1118) WP2 - SIDE PANEL- W2A01658 WP4 - WINDOW PANEL- W2A01657 1 1/8"x12 1/2"x40 5/8" (27x318x1032) 1 1/8"x14"x40 5/8" (27x356x1032) STEP 2 LAG SCREW WH PH 10x2-1/2 WASHER LOCK EXT 5x11 WASHER LOCK EXT 5x11 (6 PLCS) LAG SCREW WH PH 10x2-1/2 (6PLCS)

  • Page 21: Screw Pfh

    N2 - TIE STRAP - W103361 5/8"x2 3/8"x45 7/8" (16x60x1164) WP2 - SIDE PANEL- W2A01658 1 1/8"x12 1/2"x40 5/8" (27x318x1032) WP3 - MIDDLE REAR PANEL - W2A01660 1 1/8"x22 1/8"x21" (27x562x534) STEP 3 SCREW PFH (12) 8x1 1/2 SCREW PFH 8x1 1/2 (12 PLCS) 11/16...
  • Page 22 P3 - FRONT RIGHT POST - W103180 1 3/8"x1 3/8"x44" (36x36x1118) WP4 - WINDOW PANEL- W2A01657 1 1/8"x14"x40 5/8" (27x356x1032) STEP 4 LAG SCREW WH PH 10x2-1/2 WASHER LOCK EXT 5x11 LAG SCREW WH PH 10x2-1/2 (6 PLCS) WASHER LOCK EXT 5x11 (6 PLCS)
  • Page 23 N1 - TIE STRAP - W103362 5/8"x2 3/8"x47 1/8" (16x60x1198) WP2 - SIDE PANEL- W2A01658 P2 - POST - W103181 1 1/8"x12 1/2"x40 5/8" (27x318x1032) WP1 - MIDDLE PANEL - W2A01659 1 3/8"x1 3/8"x44" (36x36x1118) 1 1/8"x20 5/8x"21" (27x524x534) STEP 5 LAG SCREW WH PH 10x2-1/2 (3 PLCS) WASHER LOCK EXT 5x11...
  • Page 24 N3 - TIE STRAP - W103403 5/8"x2 3/8"x47 1/8" (16x60x1198) WP2 - SIDE PANEL- W2A01658 WP7 - RIGHT MIDDLE PANEL - W2A01661 P3 - FRONT RIGHT POST - W103180 1 1/8"x12 1/2"x40 5/8" (27x318x1032) 1 1/8"x20 5/8"x21" (27x524x534) 1 3/8"x1 3/8"x44" (36x36x1118) STEP 6 LAG SCREW WH PH 10x2-1/2 (3 PLCS)
  • Page 25 HZ - KNOB - A100071 WP5 - FRONT PANEL- W2A01656 DP1 - DOOR ASSEMBLY- W2A01663 MV - METAL TIE STRAP - A100257 1 1/8"x14"x40 5/8" (27x356x1032) 4 1/8"x19 1/8x 40 3/4" (105x486x1033) STEP 7 LAG SCREW WH PH 10x2-1/2 (6 PLCS) WASHER LOCK EXT 5x11 (6 PLCS) SCREW PWH...
  • Page 26 H3 - HEADER - W103190 1"x3 3/8"x47 1/8" (24x86x1198) STEP 8 LAG SCREW WH PH 10x2-1/2 (2 PLCS) WASHER LOCK EXT 5x11 (2 PLCS) SCREW PFH LAG SCREW WH PH 10x2-1/2 SCREW PFH 8x2 (2 PLCS) WASHER LOCK EXT 5x11...
  • Page 27 N4 - TIE STRAP - W102424 H2 - ANGLED HEADER - W103189 5/8”x2”x3 1/8” (16x50x80) 1"x3 3/8"x47 1/8" (24x86x1198) STEP 9 LAG SCREW WH PH 10x2-1/2 9/16" 1 13/16" (2 PLCS) WASHER LOCK EXT 5x11 (2 PLCS) SCREW PFH 8x1 1/2 LAG SCREW WH PH 10x2-1/2...
  • Page 28 N4 - TIE STRAP - W102424 H3 - HEADER - W103190 5/8”x2”x3 1/8” (16x50x80) 1"x3 3/8"x47 1/8" (24x86x1198) STEP 10 LAG SCREW WH PH 10x2-1/2 (2 PLCS) 9/16" WASHER LOCK EXT 5x11 1 13/16" (2 PLCS) SCREW PFH 8x1 1/2 LAG SCREW WH PH 10x2-1/2...
  • Page 29 N4 - TIE STRAP - W102424 H2 - ANGLED HEADER - W103189 5/8”x2”x3 1/8” (16x50x80) 1"x3 3/8"x47 1/8" (24x86x1198) STEP 11 LAG SCREW WH PH 10x2-1/2 (2 PLCS) WASHER LOCK EXT 5x11 (2 PLCS) SCREW PFH 8x1 1/2 SCREW PFH 8x1 1/2 LAG SCREW (8 PLCS) WH PH...
  • Page 30 H1 - SHELF SUPPORT - W4L05264 K6 - LEMONADE STAND SHELF - W103233 1"x3 3/8"x3 3/8" (24x86x86) 5/8"x5 1/4"x25 3/8" (16x134x644) STEP 12 SCREW PFH 8x1 3/4 (6 PLCS) SCREW PFH 8x1 3/4...
  • Page 31 H1 - SHELF SUPPORT - W4L05264 K2 - LEMONADE STAND SHELF - W103252 1"x3 3/8"x3 3/8" (24x86x86) 5/8"x5 1/4"x26 7/8" (16x134x682) STEP 13 SCREW PFH 8x1 3/4 (6 PLCS) SCREW PFH 8x1 3/4...
  • Page 32 H1 - SHELF SUPPORT - W4L05264 K6 - LEMONADE STAND SHELF - W103233 1"x3 3/8"x3 3/8" (24x86x86) 5/8"x5 1/4"x25 3/8" (16x134x644) STEP 14 SCREW PFH 8x1 3/4 (6 PLCS) SCREW PFH 8x1 3/4...
  • Page 33 T1 - TIE STRAP - W103192 1"x1 3/8"x47 1/8" (24x34x1198) STEP 15 SCREW PFH 8x1 3/4 SCREW PFH 8x1 3/4 (6 PLCS) 10 3/16"...
  • Page 34 T1 - TIE STRAP - W103192 1"x1 3/8"x47 1/8" (24x34x1198) STEP 16 SCREW PFH 8x1 3/4 SCREW PFH 8x1 3/4 (6 PLCS) 10 3/16"...

  • Page 35: Screw Pfh

    M1 - COUNTER TOP - W4L05255 G1 - COUNTER SUPPORT - W4L05257 5/8”x3 3/8”x47 1/8” (16x86x1196) 1"x5 1/4"x6 3/4" (24x134x170) STEP 17 SCREW PFH 8x1 3/4 (10 PLCS) SCREW PFH 8x1 1/2 SCREW PWH 8x5/8 (2 PLCS) SCREW PFH (10) 8x1 3/4 SCREW PWH 8x5/8...
  • Page 36 - SURFACE MOUNT BASIN - A6P00032 - STOVE KIT - A6P00025 - FAUCET KIT - A6P00024 STEP 18 SCREW PFH 8x1 1/8 (4 PLCS) SCREW PFH 8x1 1/2 SCREW PFH 8x1 1/8 SCREW PWH 8x5/8 SCREW PWH 8x5/8 (2 PLCS) SCREW PFH 8x1 1/2 (2 PLCS)
  • Page 37 - FLOWER POT HOLDER - A6P00023 STEP 19 SCREW PFH 8x1 1/4 (8 PLCS) SCREW PFH 8x1 1/4...
  • Page 38 K3 - RAFTER - W103194 5/8"x5 1/4"x28 7/8" (16x134x735) STEP 20 SCREW PFH 8x1 1/2 (8 PLCS) SCREW PFH 8x1 1/2...
  • Page 39 VB - PLASTIC SUNBURST - A100361 STEP 21 SCREW PWH 8x3/4 (8 PLCS) SCREW PWH 8x1-1/4 SCREW PWH 8x3/4 SCREW PWH 8x1-1/4 (4 PLCS)
  • Page 40 RP1 - ROOF PANEL - W2A01665 1 3/8"x31 7/8"x55 3/8" (35x809x1405) STEP 22 SCREW PFH 8x1 1/2 (16 PLCS) SCREW PFH (16) 8x1 1/2...
  • Page 41 O1 - SCREW BLOCK - W103197 5/8"x1 3/8"x49" (16x34x1245) WD - CUPOLA LOUVER - A100385 WE - CUPOLA ROOF - A100386 WC - CUPOLA BASE - A100384 STEP 23 SINGLE RIB RESTS BETWEEN DOUBLE RIBS DOUBLE RIBS SHOWN ON PREVIOUS PANEL. CUPOLA LOUVER SCREW PWH ASSEMBLY...
  • Page 42 H5 - BENCH UPRIGHT - W102471 H6 - BENCH GROUND BOARD - W102472 FZ - L BRACKET WHITE 32x51 - A100133 1"x3 3/8"x11 3/4" (24x86x300) 1"x3 3/8"x18 1/8" (24x86x460) STEP 24 NUT BARREL WH 5/16x7/8 (2 PLCS) BOLT WH 5/16x1/2 (2 PLCS) WASHER LOCK EXT 12x19 (2 PLCS)
  • Page 43 H4 - BENCH SEAT SUPPORT - W102470 M2 - BENCH SEAT - W102469 1"x3 3/8"x6 1/2" (24x86x166) 5/8"x3 3/8"x27 3/8" (16x86x694) STEP 26 SCREW PFH 8x1 3/4 (8 PLCS) STEP 27 SCREW PFH (16) 8x1 3/4 SCREW PFH 8x1 3/4 (8 PLCS)

  • Page 44: Bench Assembly

    (1) BENCH ASSEMBLY STEP 28 BOLT WH 5/16x1 1/2 WASHER LOCK EXT 12x19 NUT BARREL WH 5/16x5/8 NUT BARREL WH 5/16x5/8 (8 PLCS) WASHER LOCK EXT 12x19 BOLT WH 5/16x1 1/2 (8 PLCS) (8 PLCS)
  • Page 45 - LTP ID TAG (SMALL) WITH AGES - A4M00515 STEP 29 SCREW PFH 8x1/2 LTP ID TAG (SMALL) WITH AGES (1 PLC) SCREW PFH 8x1/2 (2 PLCS)
