TIMBERLAKE PLAYHOUSE
DISPLAY ONLY
Model: 65416
• Assembly Instructions
Manufacturer: Backyard Discovery
3001 North Rouse
Pittsburg, KS 66762
1-800-856-4445
Features the
fastening system.
Save this assembly manual for future reference in the event that
you need to order replacement parts.
Made in China
INS-65416-A-TIMBERLAKE PH DISPLAY-ENG 11/10/15
Advertisement
Related Manuals for Backyard Discovery 65416
Summary of Contents for Backyard Discovery 65416
- Page 1 • Assembly Instructions Manufacturer: Backyard Discovery 3001 North Rouse Pittsburg, KS 66762 1-800-856-4445 Features the fastening system. Save this assembly manual for future reference in the event that you need to order replacement parts. Made in China INS-65416-A-TIMBERLAKE PH DISPLAY-ENG 11/10/15...
- Page 2 Basic Setup Dimensions 7'-8 3/16" 2 3/8" 3'- 7/8" 2'-9 7/8" 5 5/8" 5 5/8" 3'-10" 2'-6" 4'-1" 3'-5 1/4" 3'-10"...
- Page 3 Tools Required for Installation: (These are the tools that are generally required for assembly of our outdoor products. These tools are not included with the outdoor product purchase.) (Cordless Drill or Electric Drill) (Drill Attachments: Phillips Head) (Phillips Screw Driver) (Claw Hammer) (An Adult w/ an Adult Helper)
-
Page 4: Parts Identification
Parts Identification Wood Components (NOT TO SCALE) F1 - UPRIGHT - W4L06764 1 3/8"x2 3/8"x36 1/4" (36x60x920) G2 - GROUND BOARD - W4L04715 1"x5 1/4"x45 1/8" (24x134x1146) G1 - GROUND BOARD - W4L06766 1"x5 1/4"x44 1/8" (24x134x1120) F3 - ANGLE BRACE - W4L04717 1 3/8"x2 3/8"x14 1/8"... - Page 5 Parts Identification Hardware K - BOLT WH 5/16x2 - H100012 (28) AC - WASHER LOCK EXT 8x19 - H100030 L - BOLT WH 5/16x2 1/4 - H100013 (13) BG - T-NUT 5/16 - H100074 (11) Z - LAG SCREW WH 5/16x2 - H100027 BL - SCREW TAPPING 14x3/4 - H100083 (29) BS - SCREW PFH 8x1 3/4 - H100089...
- Page 6 G2 - GROUND BOARD - W4L04715 K4 - SIDE RAIL - W4L04719 1"x5 1/4"x45 1/8" (24x134x1146) 5/8"x5 1/4"x45 1/8" (16x134x1146) F1 - UPRIGHT - W4L06764 F2 - UPRIGHT - W4L06765 1 3/8"x2 3/8"x36 1/4" (36x60x920) 1 3/8"x2 3/8"x36 1/4" (36x60x920) - DISPLAYER SIGNAGE 28-3/8"x44"...
- Page 7 G1 - GROUND BOARD - W4L06766 1"x5 1/4"x44 1/8" (24x134x1120) K3 - BACK RAIL - W4L06767 - DISPLAYER SIGNAGE 28-3/8"x44" - A6P00121 5/8"x5 1/4"x44 1/8" (16x134x1120) STEP 2 WASHER LOCK EXT 8x19 (4 PLCS) LAG SCREW WH 5/16x1 1/2 (4 PLCS) LAG SCREW WH 5/16x1 1/2 LAG SCREW...
- Page 8 F3 - ANGLE BRACE - W4L04717 1 3/8"x2 3/8"x14 1/8" (36x60x360) STEP 3 WASHER LOCK EXT 8x19 (6 PLCS) LAG SCREW WH 5/16x2 (6 PLCS) LAG SCREW WH 5/16x2 SCREW PFH (12) 8x1 3/4 WASHER LOCK EXT 8x19 FLUSH SCREW PFH 8x1 3/4 (12 PLCS)
-
Page 9: Screw Pfh
K2 - TOP BOARD - W4L04720 K5 - TOP BOARD - W4L04721 K1 - TOP BOARD - W4L04722 5/8"x5 1/4"x45 3/8" (16x134x1152) 5/8"x5 1/4"x35 1/4" (16x134x894) 5/8"x5 1/4"x45 3/8" (16x134x1152) STEP 4 SCREW PFH 8x1 3/4 (15 PLCS) SCREW PFH (15) 8x1 3/4... - Page 10 (1) TIMBERLAKE PLAYHOUSE FZ - L BRACKET WHITE 32x51 - A100133 STEP 5 SCREW TAPPING 14x3/4 SCREW TAPPING 14x3/4 (8 PLCS)
