safeTy MarKInGs

The equipment is Listed by UL to applicable US and Canadian standards for use in hazardous locations under Liquid Controls file
E180172
Class I
Potentially Explosive Gas/Vapor Atmospheres
dIvIsIon 2
Gases and vapor are not normally present in an explosive concentration but may accidentally exist during abnormal operations
GrouPs C & d
Flammable/explosive Gas groups
T6
Temperature class for surface temperature limitations. T6 is ≤ 85º C
-40°C ≤ Tamb ≤ 70°C
Safe limits of ambient temperature
IP66 and neMa 4
Ingress protection: dust tight and protected against powerful water jetting
6
Consult factory for current compliance status.
F
ronT
4.72"
9.9"
T
op
LectroCount LCR 600
Ø7.5"

dIMensIons

S
ide
70°
13"
r
ear
Tapped for Ground Screw
½" NPT Ports (5)
Holes for Weights
& Measures Seal
¾" NPT Ports (2)
10.7"
8.13"
7
