Modem Installation; Connect The Adsl - D-Link DSL-200 User Manual

Before you connect the USB cable, you must install the driver. See the next chapter for
driver installation instructions. The only cable you should connect initially is the ADSL
cable.
Place the Modem in a location so that you are able to view the LEDs. It should be
placed in an area that is clean, dry and ventilated. Make sure it is not placed near a
heat source such as a heater or fireplace.

Connect the ADSL

You can begin installing the Modem by performing the following steps:
Insert the Installation CD into the CD-ROM drive.
Insert one end of the ADSL cable (26 AWG twisted-pair telephone cable) into the
telephone wall jack (RJ-11 port).
Insert the other end of the ADSL cable into the ADSL port (RJ-11 port) on the Modem.
Follow the software installation instructions in Chapter 3.
DO NOT CONNECT THE USB CABLE!
You must install the software driver before you connect the device to your computer
via the USB cable. You will be prompted to connect the device during the installation.
Connecting the USB cable at this point will initiate the Found New Hardware process.
The driver install will load the necessary drivers onto your PC so that when you
connect the USB cable to your PC, Windows can load the drivers correctly.
12
3 M
ODEM
I
NSTALLATION
2
