Tool List: (Not Included)
Floor Jack
Jack Stands
Assorted Metric and S.A.E Sockets & Allen Wrenches
READ ALL INSTRUCTIONS THOROUGHLY FROM START TO FINISH BEFORE BEGINNING INSTALLATION!
THE FACTORY READ LOAD CARRYING CAPACITY WILL BE REDUCED WITH USE OF THIS REAR SPRING KIT
2008-2015 FORD SUPER DUTY 4WD
REAR BOX KIT
LIFT FTS22108
FTS22108
Qty
Part #
1
FT20073
1
FT30240BK
1
FT30241BK
1
FT30355
4
FT728U
2
FTBK2
1
FTS419
2
FTS42000
FT30355
Qty
Part #
4
37000005081
2
37160003052
2
37161001081
4
50000005081
2
50130003052
2
50131501081
2
FT22108i
1
FT58H
1
FTAS12
1
FTAS16
1
FTREGCARD
FOR 10" REAR
Rear Lift For 10" F-250
Description
Carrier Bearing Drop Bracket
Drv. Sway Bar Bracket
Pass. Sway Bar Bracket
Hdwr Sub-Assembly Kit
U-Bolt
2" Block
S/D Driveshaft Shim Kit
Rear Leaf Pack
Hdwr Sub-Assembly Kit
Description
3/8" SAE Flat Washer
3/8"-16 NyLok Nut
3/8"-16 x 1" Hex Bolt Gr. 8
1/2" SAE Flat Washer
1/2"-13 Nylok Nut
1/2"-13 x 1 1/2" Hex Bolt Gr. 8
Instruction Sheet
U-Bolt Hardware
Sticker
Driver Warning Decal
Registration Card
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Fabtech FTS22108
Summary of Contents for Fabtech FTS22108
- Page 1 2008-2015 FORD SUPER DUTY 4WD REAR BOX KIT FOR 10” REAR LIFT FTS22108 FTS22108 Rear Lift For 10" F-250 Part # Description FT20073 Carrier Bearing Drop Bracket FT30240BK Drv. Sway Bar Bracket FT30241BK Pass. Sway Bar Bracket FT30355 Hdwr Sub-Assembly Kit...
- Page 2 Remove the vent line from the bolt and remove the bolt. Save hardware. Locate the supplied brake line bracket 8. Install Fabtech shock part number FTS7266 (not included) FT30059 from the front box kit and attach the side with the with the factory hardware and torque bolts to 65 ft-lbs.
- Page 3 shims from the FTS419 kit in between the carrier bearing and 10. Install tires and wheels and torque lug nuts to wheel the FT20073 drop spacer. Place a lock washer, followed by a manufacturer’s specifications. flat washer on each bolt and insert them through the carrier bearing and shims, into the drop bracket with the Nylock nut.
