FTS22105
Qty
Part #
2
FTBK5
4
FT749U
1
FT30316
2
FT30275
1
FT30240BK
1
FT30241BK
1
FTS419
Tool List: (Not Included)
Floor Jack
Jack Stands
Assorted Metric and S.A.E Sockets & Allen Wrenches
READ ALL INSTRUCTIONS THOROUGHLY FROM START TO FINISH BEFORE BEGINNING INSTALLATION!
2008-2015 FORD SUPER DUTY 4WD
REAR LIFT FOR 8" F-250 w/ FACTORY OVER LOAD
LEAF FTS22105
F-250 8" Rear Kit
Description
5" Block
U-Bolt
Hdwr Sub-Assembly Kit
Add-A-Leaf
Drv. Sway Bar Brkt
Pass. Sway Bar Brkt
Shim Kit
REAR LIFT KIT
PARTS LIST:
FT30316
Qty
Part #
1
FT58H
2
FT90080
2
FT30284
4
37000005081
2
37160003052
2
37161001081
4
50000005081
2
50130003052
2
50131501081
1
FT22105i
Hdwr Sub-Assembly Kit
Description
5/8" Hardware
Center Pin Kit
Leaf Spring Spacer
3/8" SAE Flat Washer
3/8"-16 NyLok Nut
3/8"-16 x 1" Bolt
1/2" SAE Flat Washer
1/2"-13 Nylok Nut
1/2"-13 x 1 1/2" Bolt
Instruction Sheet
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Fabtech FTS22105
Summary of Contents for Fabtech FTS22105
- Page 1 2008-2015 FORD SUPER DUTY 4WD REAR LIFT FOR 8” F-250 w/ FACTORY OVER LOAD LEAF FTS22105 REAR LIFT KIT PARTS LIST: FTS22105 F-250 8" Rear Kit FT30316 Hdwr Sub-Assembly Kit Part # Description Part # Description FTBK5 5" Block FT58H 5/8"...
- Page 2 4. Separate the individual leafs and install the provided FT30275 INSTRUCTIONS: add a leafs with the new center bolt in a pyramid pattern smallest on the bottom graduating to the longest on top. The 1. Disconnect the negative terminal on the battery. Jack up the factory flat overload leaf should remain on the top of the pack.
- Page 3 6. Locate and install the rear lift blocks, the factory block will be positioned on top of the new Fabtech block, with the short center pin of both blocks facing down, to the axle. The short end of the blocks should face to the front of the vehicle.
- Page 4 11. Recheck all bolts for proper torque. Recheck brake hoses and 9. Install FTS419 Shim Kit per the instructions in the FTS419 lines for proper clearances. box. 10. 2011 models only .Locate the factory brake line mount on the 12. Install tires and wheels and torque lug nuts to wheel driver side of the axle.
