Installation Instructions
2001-06 GM K2500HD & C2500HD 4WD & Hummer H2 4WD w/ 6" System
TOOL LIST:
(NOT INCLUDED)
•
FLOOR JACK & JACK STANDS
•
ASSORTED METRIC AND S.A.E SOCKETS, WRENCHES
•
TORQUE WRENCH
•
RATCHET OR PULL STRAPS
SHOCKS REQUIRED- (NOT INCLUDED)
•
4- Fabtech FTS7052 Shocks
FTS51009 Multiple Frt. Shock System
Qu
a
Part #
1
FT20367BK
1
FT20368BK
1
FT20084
8
FT402087
2
FT51009i
1
FTAS10
1
FTAS11
1
FT101
1
FT20340BK
1
FT20341BK
2
FTS60235
2
FT20155
2
50000005081
1
FT90032
4
FT84
4
FTS1001
4
FT1002
4
FT1500-6-101
1
FTLube
1
56183501052
1
56180003052
2
56000005052
Description
Driver Hoop
Passenger Hoop
Hardware
Shock Sleeve
Instruction Sheet
Sticker Passenger Side
Sticker Driver Side
Passenger Frame Sleeve
Upper Control Arm Driver
Upper Control Arm Pass.
Low-pro Bumpstops
Upper Ball Joint
WASHER 1/2 SAE G8
Hardware Kit, Ball Joint
Grease Fitting 1/4"-28
A-Arm Bushings
UCA Bushing
Sleeve Yellow Zinc
Urethane Lube 1 Packet
9/16"-18 x 3 1/2" Bolt
9/16"-18 Nylock
9/16" SAE Flat Washer
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Fabtech FTS51009
Summary of Contents for Fabtech FTS51009
-
Page 1: Installation Instructions
Installation Instructions FTS51009 Multiple Frt. Shock System 2001-06 GM K2500HD & C2500HD 4WD & Hummer H2 4WD w/ 6” System Part # Description FT20367BK Driver Hoop FT20368BK Passenger Hoop FT20084 Hardware FT402087 Shock Sleeve FT51009i Instruction Sheet FTAS10 Sticker Passenger Side... - Page 2 CHECK ALL PARTS INCLUDED IN THIS KIT TO THE PARTS LIST ABOVE BEFORE BEGINNING INSTALLATION OF THE KIT. IF ANY PIECES ARE MISSING, CONTACT FABTECH AT 909-597-7800 VEHICLES THAT WILL RECEIVE OVERSIZED TIRES SHOULD CHECK BALL JOINTS, TIE RODS ENDS AND...
- Page 3 Use supplied ½” flat washer 6. Place the upper control arm into the factory upper frame 8. Torque the upper ball joint to 75LBS and install cotter key. pockets and attach using the stock hardware. Set eccentric cams in the center position of the slots. Leave loose SEE 9.
- Page 4 Passenger Side Shown 14. Place the front leg of the hoop over the steering box bolt hole 16. Locate and install Fabtech shock part number FTS7052, and re-install the stock steering box bolt, nut, and washer. bushings, ½” x 6” bolts, nuts and washers. Torque bolt to Torque the steering box bolt to 110lbs and the rear lower 35LBS.
- Page 5 17. Repeat same procedure for passenger side with these exceptions. For Four Wheel Drive Trucks, remove the factory differential mounting bolt on the side of the frame For 2wd rather than the steering box bolt, torque bolt to 70 LBS. For Two Wheel Trucks &...
-
Page 6: Product Warranty And Warnings
Fabtech cannot be responsible for 100% compatibility, including the fitment of tire and wheel sizes listed. The Tire and Wheel sizes listed in Fabtech’s catalog are only a guideline for street driving with noted fender trimming. Fabtech is not responsible for damages to the vehicle’s body or tires.
