4 in 1 Crib
THIS PRODUCT IS NOT INTENDED FOR INSTITUTIONAL OR COMMERCIAL USE.
Consumer Care:
www.DeltaChildren.com
Delta Children's Products
114 West 26th Street
New York, NY 10001
Tele.212-645-9033
Conforms to
ASTM F1169-10a Full
Size Crib & F1821
Safety Standards
To register your product for important safety alerts and updates to your product please
visit www.DeltaChildren.com and click on Product Registration.
DECEMBER 16, 2011, 22729, R0
Read all instructions before assembly and use.
KEEP INSTRUCTIONS FOR FUTURE USE.
ADULT ASSEMBLY REQUIRED
Due to the presence of small parts during assembly, keep out of
reach of children until assembly is complete.
Style #:
___________
Lot:
___________
Date:
___________
When contacting Delta Consumer
Care you will need to reference the
above numbers. They can also be
found on the label on the Crib End
bottom rail.
A
REV
FACTORY
©2011 DELTA ENTERPRISE CORP.

Advertisement

loading
Need help?

Need help?

Do you have a question about the S26970-Crib and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Delta Childrens Products S26970-Crib

Summary of Contents for Delta Childrens Products S26970-Crib

  • Page 1 Read all instructions before assembly and use. KEEP INSTRUCTIONS FOR FUTURE USE. ADULT ASSEMBLY REQUIRED Due to the presence of small parts during assembly, keep out of reach of children until assembly is complete. 4 in 1 Crib THIS PRODUCT IS NOT INTENDED FOR INSTITUTIONAL OR COMMERCIAL USE. Consumer Care: Style #: ___________...
  • Page 2 CAUTION: ANY MATTRESS USED IN THIS CRIB SHALL BE AT LEAST 27 1/4 BY 51 5/8 IN. WITH A THICKNESS NOT EXCEEDING 6 IN. WARNING: *Infants can suffocate on soft bedding. Never add a pillow or comforter. Never place additional padding under an infant.
  • Page 3 TODDLER BED WARNING INFANTS HAVE DIED IN TODDLER BEDS FROM ENTRAPMENT. Openings in and between bed parts can entrap head and neck of a small child. NEVER use bed with children younger than 15 months. ALWAYS follow assembly instructions. The maximum user weight is 50lbs (22.7kg) WARNING STRANGULATION HAZARD NEVER place bed near windows where cords from blinds or drapes may strangle a child.
  • Page 4 PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT. A. Back Rail x 1 Part # 22708 C. Right Rear Leg x 1 B. Left Rear Leg x 1 Part # 22711 Part # 22710 BACK INSIDE BOTTOM LABEL PRODUCT LABEL LEFT INSIDE BOTTOM LABEL RIGHT INSIDE BOTTOM LABEL E.
  • Page 5 PARTS: HARDWARE KIT PART #22730 FOR COLOR 205 AND 607 OR #22716 FOR COLOR 100. SEE COVER PAGE. J. M6 x 85 mm Bolt x 10 Part # 5474 No drills necessary. Do not use power screwdriver. K. M6 x 60 mm Bolt x 4 Part # 5469 Flat Head Screwdrive (not supplied)

  • Page 6: Section 1: Crib Assembly

    SECTION 1: CRIB ASSEMBLY STEP 1 PARTS AND TOOLS REQUIRED TO COMPLETE STEP C. Right Rear Leg x 1 J. M6 x 85 mm Bolt x 4 M. M6 x 17 mm Barrel Nut x 4 BACK INSIDE BOTTOM LABEL M4 Allen Wrench Supplied A.
  • Page 7 SECTION 1: CRIB ASSEMBLY STEP 2 PARTS AND TOOLS REQUIRED TO COMPLETE STEP D. Left Crib End x 1 K. M6 x 60 mm Bolt x 4 M. M6 x 17 mm Barrel Nut x 4 PRODUCT LABEL LEFT INSIDE BOTTOM LABEL From Step 1 RIGHT INSIDE BOTTOM LABEL E.
  • Page 8 SECTION 1: CRIB ASSEMBLY STEP 3 PARTS AND TOOLS REQUIRED TO COMPLETE STEP L. M6 x 15 mm Bolt x 4 H. Mattress Support x 1 M4 Allen Wrench Supplied From Step 2 Attach the Mattress Support (Part H) in all corners using (1) M6 x 15 mm Bolt (Part L) in each corner. Tighten with the M4 Allen Wrench.
  • Page 9 SECTION 1: CRIB ASSEMBLY STEP 4 PARTS AND TOOLS REQUIRED TO COMPLETE STEP J. M6 x 85 mm Bolt x 2 M. M6 x 17 mm Barrel Nut x 2 FRONT INSIDE BOTTOM LABEL F. Front Rail x 1 M4 Allen Wrench Supplied From Step 3 Attach the Front Rail (Part F) to the assembly from step 3 using (2) M6x85mm Bolts (Part J) and (2) M6x17mm Barrel Nuts (Part M).
  • Page 10 SECTION 1: CRIB ASSEMBLY STEP 5 PARTS AND TOOLS REQUIRED TO COMPLETE STEP From Step 4 J. M6 x 85 mm Bolt x 4 N. Φ4x30 mm Metal Pin x 2 M. M6 x 17 mm Barrel Nut x 4 M4 Allen Wrench Supplied G.
  • Page 11 SECTION 1: CRIB ASSEMBLY STEP 6 PARTS AND TOOLS REQUIRED TO COMPLETE STEP ASSEMBLY INSTRUCTION Read all instructions before assembly and use. KEEP INSTRUCTIONS FOR FUTURE USE. ADULT ASSEMBLY REQUIRED Due to the presence of small parts during assembly, keep out of reach of children until assembly is complete.

  • Page 12: Section 2: Toddler Bed Conversion

    SECTION 2: TODDLER BED CONVERSION STEP 1 PARTS AND TOOLS REQUIRED TO COMPLETE STEP M4 Allen Wrench Supplied Finished Crib Remove the Front Rail and Stabilizer Bar intalled in Step 4 and 5 of Section 1 crib assembly.
  • Page 13 SECTION 2: TODDLER BED CONVERSION STEP 2 PARTS AND TOOLS REQUIRED TO COMPLETE STEP From Step 1 J. M6 x 85 mm Bolt x 4 M. M6 x 17 mm Barrel Nut x 4 M4 Allen Wrench Supplied G. Stabilizer Bar x 1 Attach the Stabilizer Bar (Part G) to the assembly from step 1 using (4) M6x85mm Bolts (Part J) and (4) M6x17mm Barrel Nuts (Part M).
  • Page 14 SECTION 2: TODDLER BED CONVERSION STEP 3 WARNING: SEE PAGE 3 FOR TODDLER BED WARNINGS The mattress support must be in the lowest positions. Store all hardware safely. Read all warnings on page 3. As shown, use as a day bed or love seat sofa. Do Not use without stabilizer bar intalled.

  • Page 15: Section 3: Full Size Bed Conversion

    SECTION 3: FULL SIZE BED CONVERSION STEP 1 PARTS AND TOOLS REQUIRED TO COMPLETE STEP M4 Allen Wrench Supplied You have the option to convert the crib to a Full Size Bed. Simply follow the steps in reverse order to disassemble the crib.
  • Page 16 SECTION 3: FULL SIZE BED CONVERSION STEP 2 PARTS AND TOOLS REQUIRED TO COMPLETE STEP L. M6 x 15 mm Bolt x 4 From Section 3 Step 1 M4 Allen Wrench Supplied Attach Bed Frame to the Headboard (From Section 3 Step 1) using (4) M6x15mm Bolts (Part L). Follow all instructions supplied with the Bed Frame.
  • Page 17 Style Number and Lot Number available. Use the space below to make note of those numbers. They can be found on the label on the Crib End bottom rail. STYLE No: S26970-Crib COLOR Lot No. : _______________________ Pack Date:_____________________...
