Delta Childrens Products 7950 Instructions For Use Manual

4 in 1 crib
Hide thumbs
Table of Contents

Advertisement

Quick Links

4 in 1 Crib
THIS PRODUCT IS NOT INTENDED FOR INSTITUTIONAL OR COMMERCIAL USE.
Consumer Care:
www.DeltaChildren.com
Delta Children's Products
114 West 26th Street
New York, NY 10001
Tele.212-645-9033
Conforms to
ASTM F1169-10a Full
Size Crib & F1821
Safety Standards
To register your product for important safety alerts and updates to your product please
visit www.DeltaChildren.com and click on Product Registration.
NOVEMBER 11, 2011, 22504, R0
Read all instructions before assembly and use.
KEEP INSTRUCTIONS FOR FUTURE USE.
ADULT ASSEMBLY REQUIRED
Due to the presence of small parts during assembly, keep out of
reach of children until assembly is complete.
Style #:
___________
Lot:
___________
Date:
___________
When contacting Delta Consumer
Care you will need to reference the
above numbers. They can also be
found on the label on the Crib End
bottom rail.
A
REV
FACTORY
©2011 DELTA ENTERPRISE CORP.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7950 and is the answer not in the manual?

Questions and answers

Alycia Bredniak
July 15, 2025

I received this crib as a gift from my grandmother and I can’t seem to find the screws to put it together. Can you please tell me if I can buy them from a hardware store?

0

Related Manuals for Delta Childrens Products 7950

Summary of Contents for Delta Childrens Products 7950

  • Page 1 Read all instructions before assembly and use. KEEP INSTRUCTIONS FOR FUTURE USE. ADULT ASSEMBLY REQUIRED Due to the presence of small parts during assembly, keep out of reach of children until assembly is complete. 4 in 1 Crib THIS PRODUCT IS NOT INTENDED FOR INSTITUTIONAL OR COMMERCIAL USE. Consumer Care: Style #: ___________...

  • Page 2: Part

    CAUTION: ANY MATTRESS USED IN THIS CRIB SHALL BE AT LEAST 27 1/4 BY 51 5/8 IN. WITH A THICKNESS NOT EXCEEDING 6 IN. WARNING: *Infants can suffocate on soft bedding. Never add a pillow or comforter. Never place additional padding under an infant.

  • Page 3: Part

    TODDLER BED WARNING INFANTS HAVE DIED IN TODDLER BEDS FROM ENTRAPMENT. Openings in and between bed parts can entrap head and neck of a small child. NEVER use bed with children younger than 15 months. ALWAYS follow assembly instructions. The maximum user weight is 50lbs (22.7kg) WARNING STRANGULATION HAZARD NEVER place bed near windows where cords from blinds or drapes may strangle a child.
  • Page 4 PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT. D. Right Rear Leg x 1 A. Back Top Rail x 1 Part # 22497 J. Right Front Leg x 1 Part # 22488 Part # 22499 B. Back Rail x 1 H.

  • Page 5: Table Of Contents

    PARTS: HARDWARE KIT PART # 22503 FOR COLOR 100 OR # 22505 FOR COLOR 260,604 AND 607. SEE WARRANTY PAGE. R. M6 x 110 mm Bolt x 2 Part # 5580 No drills necessary. Do not S. M6 x 60 mm Bolt x 4 use power screwdriver.
  • Page 6 SECTION 1: CRIB ASSEMBLY STEP 1 PARTS AND TOOLS REQUIRED TO COMPLETE STEP D. Right Rear Leg x 1 U. M6 x 50 mm Bolt x 2 BACK INSIDE BOTTOM LABEL C. Left Rear Leg x 1 M4 Allen Wrench Supplied B.
  • Page 7 SECTION 1: CRIB ASSEMBLY STEP 2 PARTS AND TOOLS REQUIRED TO COMPLETE STEP A. Back Top Rail x 1 U. M6 x 50 mm Bolt x 4 M4 Allen Wrench Supplied From Step 1 Insert the slot of the Back Top Rail (Part A) into the tenon on top of the Back Rail (Part B), then insert the (4) M6x50mm Bolts (Part U), through the legs into the Metal Inserts on the Back Top Rail (Part A) as shown.
  • Page 8 SECTION 1: CRIB ASSEMBLY STEP 3 PARTS AND TOOLS REQUIRED TO COMPLETE STEP From Step 2 U. M6 x 50 mm Bolt x 6 PRODUCT LABEL LEFT INSIDE BOTTOM LABEL RIGHT INSIDE BOTTOM LABEL F. Right Crib End x 1 E.
  • Page 9 SECTION 1: CRIB ASSEMBLY STEP 4 PARTS AND TOOLS REQUIRED TO COMPLETE STEP Y. M6 x 15 mm Bolt x 4 G. Mattress Support x 1 M4 Allen Wrench Supplied From Step 3 Attach the Mattress Support (Part G) in all corners using (1) M6 x 15 mm Bolt (Part Y) in each corner. Tighten with the M4 Allen Wrench.
  • Page 10 SECTION 1: CRIB ASSEMBLY STEP 5 PARTS AND TOOLS REQUIRED TO COMPLETE STEP W. M6 x 30 mm Bolt x 3 L. Stabilizer Bar x 1 Z. Φ4x30 mm Metal Pin x 2 M. Stabilizer Bar Molding x 1 M4 Allen Wrench Supplied Attach (1) Stabilizer Bar Molding (Part M) to (1) Stabilizer Bar (Part L) using (2) Φ4x30 mm Metal Pins (Part Z) and (3) M6x30mm Bolts (Part W).
  • Page 11 SECTION 1: CRIB ASSEMBLY STEP 6 PARTS AND TOOLS REQUIRED TO COMPLETE STEP From Step 5 S. M6 x 60 mm Bolt x 4 K. Front Rail x 1 M4 Allen Wrench Supplied Attach (1) Front Rail (Part K) to the assembly from step 5 using (4) M6x60mm Bolts (Part S). Tighten with the M4 Allen Wrench.

  • Page 12: Part # 22497 J. Right Front Leg X

    SECTION 1: CRIB ASSEMBLY STEP 7 PARTS AND TOOLS REQUIRED TO COMPLETE STEP R. M6 x 110 mm Bolt x 2 Z. Φ4x30 mm Metal Pin x 2 P. Left Front Foot x 1 J. Right Front Leg x 1 H.

  • Page 13: Part

    SECTION 1: CRIB ASSEMBLY STEP 8 PARTS AND TOOLS REQUIRED TO COMPLETE STEP U. M6 x 50 mm Bolt x 4 From Step 6 Z. Φ4x30 mm Metal Pin x 8 From Step 7 M4 Allen Wrench Supplied Attach the assembly from step 7 to the assembly from step 6 using (8) Φ4x30 mm Metal Pins (Part Z) and (4) M6x50mm Bolt (Part U).

  • Page 14: Part

    SECTION 1: CRIB ASSEMBLY STEP 9 PARTS AND TOOLS REQUIRED TO COMPLETE STEP V. M6 x 40 mm Bolt x 6 From Step 8 From Step 4 M4 Allen Wrench Supplied Attach the assembly from step 8 to the assembly from step 4 using (6) M6x40mm Bolts (Part V). Tighten with the M4 Allen Wrench.

  • Page 15: Part

    SECTION 1: CRIB ASSEMBLY STEP 10 PARTS AND TOOLS REQUIRED TO COMPLETE STEP Read all instructions before assembly and use. ASSEMBLY INSTRUCTION KEEP INSTRUCTIONS FOR FUTURE USE. ADULT ASSEMBLY REQUIRED Due to the presence of small parts during assembly, keep out of reach of children until assembly is complete.

  • Page 16: Part

    SECTION 2: TODDLER BED CONVERSION STEP 1 PARTS AND TOOLS REQUIRED TO COMPLETE STEP M4 Allen Wrench Supplied Finished Crib Remove the Front Rail Assembly installed in Step 9 of Section 1 crib assembly.

  • Page 17: Part

    SECTION 2: TODDLER BED CONVERSION STEP 2 PARTS AND TOOLS REQUIRED TO COMPLETE STEP M4 Allen Wrench Supplied From Section 2 Step 1 Disassemble the Front Rail Assembly from Step 8 and 6 of Section 1 crib assembly.
  • Page 18 SECTION 2: TODDLER BED CONVERSION STEP 3 PARTS AND TOOLS REQUIRED TO COMPLETE STEP From Section 2 Step 2 S. M6 x 60 mm Bolt x 4 N. Day Bed Rail x 1 M4 Allen Wrench Supplied Attach (1) Day Bed Rail (Part N) to the assembly from section 2 step 2 using (4) M6x60mm Bolts (Part S).
  • Page 19 SECTION 2: TODDLER BED CONVERSION STEP 4 PARTS AND TOOLS REQUIRED TO COMPLETE STEP U. M6 x 50 mm Bolt x 2 Z. Φ4x30 mm Metal Pin x 6 From Section 2 Step 3 From Section 2 Step 2 M4 Allen Wrench Supplied Attach the Left Front Leg and Right Front Leg (from section 2 step 2) to the assembly from section 2 step 3 using (6) Φ4x30 mm Metal Pins (Part Z) and (2) M6x50mm Bolts (Part U).

  • Page 20: Part

    SECTION 2: TODDLER BED CONVERSION STEP 5 PARTS AND TOOLS REQUIRED TO COMPLETE STEP V. M6 x 40 mm Bolt x 6 From Section 2 Step 4 M4 Allen Wrench Supplied From Section 2 Step 1 Attach the assembly from section 2 step 4 to the assembly from section 2 step 1 using (6) M6x40mm Bolts (Part V).
  • Page 21 SECTION 2: TODDLER BED CONVERSION STEP 6 WARNING: SEE PAGE 3 FOR TODDLER BED WARNINGS The mattress support must be in the lowest positions. Store all hardware safely. Read all warnings on page 3. As shown, use as a day bed or love seat sofa. Do Not use without stabilizer bar installed.

  • Page 22: Part

    SECTION 3: FULL SIZE BED CONVERSION STEP 1 PARTS AND TOOLS REQUIRED TO COMPLETE STEP M4 Allen Wrench Supplied You have the option to convert the crib to a Full Size Bed. Simply follow steps in reverse order to disassemble the crib. The Headboard is the Back Rail assembly done through step 1 and 2 of section 1. To created the Footboard, see step 5,6,7 and 8 of section 1 crib assembly for the details.
  • Page 23 SECTION 3: FULL SIZE BED CONVERSION STEP 2 PARTS AND TOOLS REQUIRED TO COMPLETE STEP W. M6 x 30 mm Bolt x 2 Y. M6 x 15 mm Bolt x 12 M4 Allen Wrench Supplied From Section 3 Step 1 AA.

  • Page 24: Part

    Style Number and Lot Number available. Use the space below to make note of those numbers. They can be found on the label on the Crib End bottom rail. STYLE No: 7950 COLOR Lot No. : _______________________...
