Delta Childrens Products 6965 Instructions For Use Manual

Crib
Hide thumbs

Advertisement

Quick Links

Download this manual
Crib
THIS PRODUCT IS NOT INTENDED FOR INSTITUTIONAL OR COMMERCIAL USE.
Consumer Care:
www.DeltaChildren.com
Delta Children's Products
114 West 26th Street
New York, NY 10001
Tele.212-645-9033
Conforms to
ASTM F1169-10a Full
Size Crib & F1821
Safety Standards
To register your product for important safety alerts and updates to your product please
visit www.DeltaChildren.com and click on Product Registration.
NOVEMBER 15, 2011, 22524, R0
Read all instructions before assembly and use.
KEEP INSTRUCTIONS FOR FUTURE USE.
ADULT ASSEMBLY REQUIRED
Due to the presence of small parts during assembly, keep out of
reach of children until assembly is complete.
Style #:
___________
Lot:
___________
Date:
___________
When contacting Delta Consumer
Care you will need to reference the
above numbers. They can also be
found on the label on the Crib End
bottom rail.
A
REV
FACTORY
©2011 DELTA ENTERPRISE CORP.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 6965 and is the answer not in the manual?

Questions and answers

Related Manuals for Delta Childrens Products 6965

Summary of Contents for Delta Childrens Products 6965

  • Page 1 Read all instructions before assembly and use. KEEP INSTRUCTIONS FOR FUTURE USE. ADULT ASSEMBLY REQUIRED Due to the presence of small parts during assembly, keep out of reach of children until assembly is complete. Crib THIS PRODUCT IS NOT INTENDED FOR INSTITUTIONAL OR COMMERCIAL USE. Consumer Care: Style #: ___________...
  • Page 2 CAUTION: ANY MATTRESS USED IN THIS CRIB SHALL BE AT LEAST 27 1/4 BY 51 5/8 IN. WITH A THICKNESS NOT EXCEEDING 6 IN. WARNING: *Infants can suffocate on soft bedding. Never add a pillow or comforter. Never place additional padding under an infant.
  • Page 3 TODDLER BED WARNING INFANTS HAVE DIED IN TODDLER BEDS FROM ENTRAPMENT. Openings in and between bed parts can entrap head and neck of a small child. NEVER use bed with children younger than 15 months. ALWAYS follow assembly instructions. The maximum user weight is 50lbs (22.7kg) WARNING STRANGULATION HAZARD NEVER place bed near windows where cords from blinds or drapes may strangle a child.
  • Page 4 PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT. A. Crib End Top x 2 E. Right Leg x 2 C. Right Crib End x 1 Part # 22522 Part # 22517 Part # 22519 D. Left Leg x 2 Part # 22521 PRODUCT LABEL B.
  • Page 5 PARTS: HARDWARE KIT PART # 22523 FOR COLOR 260 OR # 22526 FOR COLOR 604 OR # 22527 FOR COLOR 100. SEE FRONT COVER. J. M6 x 105 mm Bolt x 4 Part # 5581 No drills necessary. Do not use power screwdriver.

  • Page 6: Section 1: Crib Assembly

    SECTION 1: CRIB ASSEMBLY STEP 1 PARTS AND TOOLS REQUIRED TO COMPLETE STEP C. Right Crib End x 1 B. Left Crib End x 1 E. Right Leg x 2 L. M6 x 60 mm Bolt x 4 R. Φ4x30 mm Metal Pin x 4 P.
  • Page 7 SECTION 1: CRIB ASSEMBLY STEP 2 PARTS AND TOOLS REQUIRED TO COMPLETE STEP M. M6 x 45 mm Bolt x 8 A. Crib End Top x 2 M4 Allen Wrench Supplied From Step 1 Insert the slot of the Crib End Top (Part A) into the tenon on top of the Left Crib End (Part B), then insert the (4) M6x45mm Bolts (Part M), through the legs into the Metal Inserts on the Crib End Top (Part A) as shown.
  • Page 8 SECTION 1: CRIB ASSEMBLY STEP 3 PARTS AND TOOLS REQUIRED TO COMPLETE STEP J. M6 x 105 mm Bolt x 2 K. M6 x 85 mm Bolt x 2 From Step 2 INSIDE BOTTOM LABEL M4 Allen Wrench Supplied F. Crib Side x 1 P.
  • Page 9 SECTION 1: CRIB ASSEMBLY STEP 4 PARTS AND TOOLS REQUIRED TO COMPLETE STEP N. M6 x 15 mm Bolt x 4 H. Mattress Support x 1 M4 Allen Wrench Supplied From Step 3 Attach the Mattress Support (Part H) in all corners using (1) M6 x 15 mm Bolt (Part N) in each corner. Tighten with the M4 Allen Wrench.
  • Page 10 SECTION 1: CRIB ASSEMBLY STEP 5 PARTS AND TOOLS REQUIRED TO COMPLETE STEP J. M6 x 105 mm Bolt x 2 K. M6 x 85 mm Bolt x 2 From Step 4 INSIDE BOTTOM LABEL M4 Allen Wrench Supplied F. Crib Side x 1 P.
  • Page 11 SECTION 1: CRIB ASSEMBLY STEP 6 PARTS AND TOOLS REQUIRED TO COMPLETE STEP Read all instructions before assembly and use. ASSEMBLY INSTRUCTION KEEP INSTRUCTIONS FOR FUTURE USE. ADULT ASSEMBLY REQUIRED Due to the presence of small parts during assembly, keep out of reach of children until assembly is complete.

  • Page 12: Section 2: Toddler Bed Conversion

    SECTION 2: TODDLER BED CONVERSION STEP 1 PARTS AND TOOLS REQUIRED TO COMPLETE STEP M4 Allen Wrench Supplied Finished Crib Remove the Crib Side installed in Step 5 of Section 1 crib assembly. Remove only one side.
  • Page 13 SECTION 2: TODDLER BED CONVERSION STEP 2 PARTS AND TOOLS REQUIRED TO COMPLETE STEP J. M6 x 105 mm Bolt x 2 R. Φ4x30 mm Metal Pin x 2 G. Stabilizer Bar x 1 From Step 1 M4 Allen Wrench Supplied P.
  • Page 14 SECTION 2: TODDLER BED CONVERSION STEP 3 WARNING: SEE PAGE 3 FOR TODDLER BED WARNINGS The mattress support must be in the lowest positions. Store all hardware safely. Read all warnings on page 3. As shown, use as a day bed or love seat sofa. Do Not use without stabilizer bar installed.
  • Page 15 Style Number and Lot Number available. Use the space below to make note of those numbers. They can be found on the label on the Crib End bottom rail. STYLE No: 6965 COLOR Lot No. : _______________________...
