Summary of Contents for ESAB Origo Tig 3000i AC/DC

  • Page 1 Origo™ Tig 3000i AC/DC Instruction manual Valid for: 039-xxx-xxxx 0459 942 201 GB 20170502...
  • Page 3: Table Of Contents

    Fan control ....................Overheating protection ................MAINTENANCE ..................... 14 Inspection and cleaning................FAULT-TRACING................... 15 ORDERING SPARE PARTS ................16 DIAGRAM ......................ORDERING NUMBERS ..................ACCESSORIES ....................Rights reserved to alter specifications without notice. 0459 942 201 © ESAB AB 2017...
  • Page 4: Safety

    Data Sheets (SDSs). Safety precautions Users of ESAB equipment have the ultimate responsibility for ensuring that anyone who works on or near the equipment observes all the relevant safety precautions. Safety precautions must meet the requirements that apply to this type of equipment. The following recommendations should be observed in addition to the standard regulations that apply to the workplace.
  • Page 5 • Protect your eyes and body. Use the correct welding screen and filter lens and wear protective clothing. • Protect bystanders with suitable screens or curtains. NOISE - Excessive noise can damage hearing Protect your ears. Use earmuffs or other hearing protection. 0459 942 201 - 5 - © ESAB AB 2017...
  • Page 6 For further information contact the nearest ESAB dealer. ESAB has an assortment of welding accessories and personal protection equipment for purchase. For ordering information contact your local ESAB dealer or visit us on our website. 0459 942 201 - 6 -...
  • Page 7: Introduction

    The Tig 3000i AC/DC is a TIG welding power source for alternating current (AC) or direct current (DC). It can also be used for MMA welding. ESAB accessories for the product can be found in the "ACCESSORIES" chapter of this manual.
  • Page 8: Technical Data

    Constant A-weighted sound pressure < 70 dB Dimensions l x w x h 652 x 249 x 423 mm Weight 48.5 kg Insulation class transformer Enclosure class IP 23 Application class 0459 942 201 - 8 - © ESAB AB 2017...
  • Page 9 Mains supply, S sc min Minimum short circuit power on the network in accordance with IEC 61000-3-12. 0459 942 201 - 9 - © ESAB AB 2017...
  • Page 10: Installation

    Recommended fuse sizes and minimum cable area Tig 3000i AC/DC Mains voltage 400 V 1-3~ 50/60 Hz 400 V 1-3~ 50/60 Hz 4 mm / phase 4 mm / phase Mains cable area mm 0459 942 201 - 10 - © ESAB AB 2017...
  • Page 11 The welding power source is designed for connection to a 230 / 400 volt system with four conductors. If the power source is to be used in countries with a higher supply voltage, the power source must be connected via a safety transformer. 0459 942 201 - 11 - © ESAB AB 2017...
  • Page 12: Operation

    General safety regulations for handling the equipment can be found in the "SAFETY" chapter of this manual. Read it through before you start using the equipment!                                        0459 942 201 - 12 - © ESAB AB 2017...
  • Page 13: Connections And Control Devices

    When this occurs the welding current is interrupted and a fault code is displayed on the control panel. The overheating protection resets automatically when the temperature has fallen. 0459 942 201 - 13 - © ESAB AB 2017...
  • Page 14: Maintenance

    The wear parts of the welding torch should be cleaned and replaced at regular intervals in order to achieve trouble-free wire feed. Blow the wire guide clean regularly and clean the contact tip. 0459 942 201 - 14 - © ESAB AB 2017...
  • Page 15: Fault-Tracing

    • Check that the welding current supply and return cables are correctly connected. • Check that the correct current value is set. • Check that the correct electrodes are being used. • Check the mains power supply fuses. 0459 942 201 - 15 - © ESAB AB 2017...
  • Page 16: Ordering Spare Parts

    Spare parts and wear parts can be ordered through your nearest ESAB dealer, see the back cover of this document. When ordering, please state product type, serial number, designation and spare part number in accordance with the spare parts list.
  • Page 17: Diagram

    DIAGRAM DIAGRAM 0459 942 201 - 17 - © ESAB AB 2017...
  • Page 18 DIAGRAM 0459 942 201 - 18 - © ESAB AB 2017...
  • Page 19: Ordering Numbers

    Tig 3000i AC/DC 0459 839 003 Spare parts list Control panel Origo™ TA24 AC/DC 0459 944 Instruction manual Control panel Origo™ TA24 AC/DC Technical documentation is available on the Internet at: www.esab.com 0459 942 201 - 19 - © ESAB AB 2017...
  • Page 20: Accessories

    Cooling unit CoolMidi 1800 Includes 5 m cable 0465 720 002 ESAB ready mixed coolant (10 l / 2.64 gal) Use of any other cooling liquid than the prescribed one might damage the equipment. In case of such damage, all warranty undertakings from ESAB cease to apply.
  • Page 21 15 m 0459 554 883 25 m 0459 554 884 0.25 m 0156 743 907 Return cable 5 m 50 mm Information on Tig torches can be found in separate brochures. 0459 942 201 - 21 - © ESAB AB 2017...
