IntesisBox BACnet/IP Server – Notifier ID3000

Technical characteristics

Enclosure
Colour
Power
Terminal wiring (for
power supply and
low-voltage signals)
Mounting
Notifier ID3000 port
BACnet/IP port
LED indicators
Console port
Configuration
Firmware
Operational
temperature
Operational humidity 5 to 95%, non condensing
Protection
RoHS conformity
Norms and
standards
1
Standard cable DB9male-DB9female 1,8 meters long is supplied with the device for connection to a PC COM port for
configuring and monitoring the device. The configuration software, compatible with Windows
supplied.
This information is subject to change without notice.
Plastic, type PC (UL 94 V-0).
Dimensions: 107mm x 105mm x 58mm.
Light Grey. RAL 7035.
9 to 30Vdc +/-10%, Max.: 125mA.
24Vac +/-10% 50-60Hz, Max.: 127mA
Must use a NEC Class 2 or Limited Power Source (LPS) and SELV
rated power supply.
Plug-in terminal block for power connection (2 poles).
Per terminal: solid wires or stranded wires (twisted or with
ferrule)
2
1 core: 0.5mm
2 cores: 0.5mm
3 cores: not permitted
Wall.
DIN rail EN60715 TH35.
1 x Serial EIA232 (DB9 male DTE). SELV
1 x Ethernet 10Base-T RJ45.
1 x Power.
2 x Notifier ID3000 port activity (Tx, Rx).
2 x Link and activity Ethernet port (LNK, ACT).
EIA232. (DB9 female connector, DCE). SELV
Via console port.
Allows upgrades via console port.
0°C to +70°C
IP20 (IEC60529).
Compliant with RoHS directive (2002/95/CE).
CE conformity to EMC directive (2004/108/EC) and Low-voltage
directive (2006/95/EC)
EN 61000-6-2
EN 61000-6-3
EN 60950-1
EN 50491-3
URL http://www.intesis.com
email info@intesis.com
tel +34 938047134
2
... 2.5mm
2 2
... 1.5mm
1
Installation Manual
®
operating systems, is also
Doc. Rev.2
4 / 5
