IntesisBox Modbus Server – DALI
®

Technical characteristics

Enclosure
Color
Supply Voltage
Terminal wiring
(for power supply
and low-voltage
signals)
Mounting
DALI bus power
source
DALI port
Ethernet port
(Modbus TCP,
device config)
Modbus RTU ports
LED indicators
Push buttons
Console port
Configuration
Firmware
Operational
temperature
Operational
humidity
Protection
RoHS conformity
Norms and
standards
1
DALI test push-button and LED are meant to perform a quick test of your DALI line and connected ballasts.
2
Standard cable DB9male-DB9female 1,8 meters long is supplied with the device for connection to a PC COM port for
configuring and monitoring the device using the serial port (Ethernet is also possible). The configuration software, compatible
®
with Windows operating systems, is also supplied.
2
The information in this document may change without previous notice.
Plastic, type PC (UL 94 V-0).
Dimensions: 159mm 105mm x 58mm.
Light Grey / RAL 7035.
230Vac +/-10% 6W
(3-pole plug-in terminal block – line, neutral and earth)
Per terminal: solid wires or stranded wires (twisted or with
ferrule)
2
1 core: 0.5mm ... 2.5mm
2
2 cores: 0.5mm ... 1.5mm
3 cores: not permitted
Wall.
DIN rail EN60715 TH35.
15Vdc +/-2% 250mA.
(DALI bus is powered from IntesisBox)
1 x DALI electrically isolated (2-pole plug-in terminal block). SELV
1 x Ethernet 10Base-T (RJ45).
1 x Serial EIA232 (DB9 male DTE). SELV
1 x Serial EIA485 (Plug-in screw terminal block 2 poles). SELV
1 x Power indicator.
2 x DALI activity (Tx, Rx).
2 x Ethernet link & activity (LNK, ACT).
2 x Modbus RTU serial port activity (Tx, Rx).
1 x DALI bus power
1
1 x DALI test
1
1 x DALI test
EIA232. DB9 female connector (DCE). SELV
Via Ethernet or serial console port.
Allows upgrades via console port.
0°C to +60°C
25-90% at 50ºC, non condensing
IP20 (IEC60529).
Compliant with RoHS directive (2002/95/CE).
CE conformity to EMC directive (2004/108/EC) and Low-voltage
directive (2006/95/EC)
EN 61000-6-2
EN 61000-6-3
EN 60950-1
EN 50491-3
