Strobel 327D Operating Instructions Manual

Model: 2
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
For the professional user
Für den professionellen Anwender
Operating Instructions
Betriebsanleitung
Class:
Klasse:
Model:
Ausführung:
Dated:
Stand:
327D
2
S p e z i a l m a s c h i n e n G m b H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 327D and is the answer not in the manual?

Questions and answers

Related Manuals for Strobel 327D

Summary of Contents for Strobel 327D

  • Page 1 For the professional user Operating Instructions Für den professionellen Anwender Betriebsanleitung Class: 327D Klasse: Model: Ausführung: Dated: Stand: S p e z i a l m a s c h i n e n G m b H...
  • Page 2 The sign of quality ou find the Strobel trademark on every Strobel machine leaving our works. And with good reason. This symbol is a guarantee of the high quality of our products. Quality which creates trust – trust in our technology, our service and, not least of all, in our good name.
  • Page 3 We wish you lots of success in your work with your new Strobel machine. S p e z i a l m a s c h i n e n G m b H...
  • Page 4 Boschstraße 16 D-82178 Puchheim Tel.: 089/80096-0 Fax: 089/80096-190 info@strobel.biz Maschinenklasse/Machine class: Serien-Nr./Serial No: Auftrags-Nr./Order Confirmation No: Lieferdatum/Delivery Date: Rechnungs-Nr./Invoice No: Rechnungsdatum/Invoice Date: Beanstandung/Complaint: Datum/Date Unterschrift/Signature: Bitte nicht vom Kunden ausfüllen/To be filled out by Strobel: Datum Bemerkung EXA: ETA: PROD: EXA:...
  • Page 5 BA_327D_A2_200715_en.doc...
  • Page 6 BA_327D_A2_200715_en.doc...

  • Page 7: Table Of Contents

    Operating Instructions STROBEL Class 327D C o n t e n t s General notes on safety ......................5 General .............................7 Operating instructions ....................7 Class description, serial number and initial basis for description .......7 Range of application and intended use ...............7 Technical data .......................8...
  • Page 8 Operating the sewing machine ..................... 26 Switch-on ........................26 Inserting and removing the sewing material ............27 Sewing ........................28 5.3.1 Hemming with blind stitch ................28 Problems during sewing and troubleshooting ............29 Incorrect stitches ....................... 31 Machine maintenance ......................32 Subject to change without prior notice BA_327D_A2_200715_en.doc...

  • Page 9: General Notes On Safety

    General notes on safety Manuals and additional information can be found on the STROBEL website at: http://www.strobel.biz Every person in charge of setting up, operating, servicing and repairing the machine must first read and understand the operating instructions and particularly the safety instructions before starting up the machine.
  • Page 10 It is essential that you observe and follow these instructions as well as the generally valid safety regulations. Warning instructions given in the operating instructions that pertain to especially dangerous parts of the machine must be indicated at these positions using a safety symbol.

  • Page 11: General

    General Operating instructions Any person involved in the installation, operation, maintenance and repair of the machine must have read and understood the operating instructions and mainly the safety instructions before starting the machine. Class description, serial number and initial basis for description For side-referenced descriptions, the operating side of the machine is the starting base.

  • Page 12: Technical Data

    Technical data Empfohlene Nennstichzahl / 1300 min-1 Recommended rated speed Stichlänge / stitch length 2,0 - 8,0 mm (abhängig vom Nähmaterial / depend on fabric) Auslieferzustand / delivery condition 8,0 mm Unter-, und differenzierender Obertransporteur / bottom and differential top feed gefederter Taucher / spring loaded plunger Stichplattenöffnung / Stitch plate opening...
  • Page 13 Technischer Auslieferzustand / delivery condition: Motor-Leistung min. / min. motor power 550 W Zahnriemenscheibe Maschine / toothed belt Z = 38 pulley/machine Zahnriemenprofil / toothed belt profile HTD 5M-9 Stichart / stitch type Zweifaden-Blind-Doppelsteppstich Typ 317 / two thread blind lock stitch type 317 Anschluss pneumatisch / pneumatic connection 6 bar Luftverbrauch, Mittelwert / avarage air...

  • Page 14: Set-Up And Commissioning

    Set-up and commissioning Unpacking of the machine Strobel machines are supplied either complete as upper part only. The cotton stand and another machine accessories are located in the packaging. Prior to disposing of the packing material it must be carefully checked whether all accessories parts have been unpacked.
  • Page 15 Fig. 1 BA_327D_A2_200715_en.doc...
  • Page 16 The cotton stand is mounted at the back on the right on the table plate after assembly of the individual parts. (Fig. 1) Check all screws at the frame for tight fit and retighten if necessary. Mount the position transmitter and adjust corresponding to point “3.4.2 Positions of the machine“.

  • Page 17: Sense Of Rotation Of The Machine (Fig. 3)

    Sense of rotation of the machine (Fig. 3) The correct rotation of the hand wheel is clockwise when looking at it from the front. Fig. 3 Motor drive via toothed belt 3.4.1 Tensioning the toothed belt (Fig. 4) C A U T I O N ! Danger of injury! To check the tension of the toothed belt, switch off the machine electrically, pull the mains plug and ensure the machine has actually stopped by pressing the motor pedal.

  • Page 18: Positions Of The Machine

    Fig. 4 3.4.2 Positions of the machine C A U T I O N ! Danger of injury! Danger of pulling in parts of clothing and of hair and danger of crushing fingers and stitching fingers with needles! When checking positions with switched-on machine keep fingers and hands away from moving parts.

  • Page 19: Intermediate Lifting (Fig. 5)

    Intermediate lifting (Fig. 5) If an intermediate lifting with the knee lever should become necessary with attached pneumatic venting, it can be mounted on the screw (1) in its usual position. Fig. 5 BA_327D_A2_200715_en.doc...

  • Page 20: Notes On Usage

    Notes on usage Needles and threads By selecting the most suitable needles and threads for the relevant sewing material one can influence the sewing quality decisively. Only tested GROZ-BECKERT needle system 1717 VRUE should be used. The machine is supplied with needles of thickness 90/14. NOTE: An intact needle is of decisive importance for a good initial stitch.

  • Page 21: Threading And Thread Run (Fig. 6)

    Threading and thread run (Fig. 6) C A U T I O N ! Danger of injury! Switch off the machine prior to threading and ensure the machine is off by pressing the pedal for switching the motor. Fig. 6 shows the correct threading by using the thread sensor. Fig.

  • Page 22: Winding Up The Thread (Fig. 7)

    Winding up the thread (Fig. 7) The course of the thread during winding up is shown in Fig. 7. Care must be taken that not too much of the thread is wound onto the bobbin and that the bobbin walls are not pushed apart, faulty bobbins must immediately be replaced with new ones.

  • Page 23: Thread Tensioning

    Fig. 8 Thread tensioning 4.5.1 Thread tensioning - needle thread (Fig. 9) Depending on the quality, configuration and thickness of the thread as well as the sewing material, the thread tension is set using the locking sleeve (1) (Fig. 9) to the desired seam diagram.

  • Page 24: Thread Tensioning - Bobbin Thread (Fig. 10)

    4.5.2 Thread tensioning – bobbin thread (Fig. 10) The leaf spring (2) regulates the bobbin thread tension. By turning the flat-head screw with catch (1), the leaf spring must be adjusted in such a way that when the bobbin is inserted, and the thread is correctly pulled under the leaf spring and the bobbin case is released, the latter, together with the bobbin drops slowly down.

  • Page 25: Adjusting The Stitch Length (Fig. 7 And Fig. 11)

    Adjusting the stitch length (Fig. 7 and Fig. 11) C A U T I O N ! Danger of injury! Switch off the machine electrically, and depress the motor switch pedal to make sure that the machine is truly switched off. Otherwise there is a danger of injury from crushing and needle punctures.

  • Page 26: Stitch Depth

    Stitch depth Stitch depth means the distance between the highest plunger position and the outer radius of the needle. The plunger forces the sewn item from underneath into the Stitch plate opening, so that the needle penetrates the layers of material to the desired depth.

  • Page 27: Digital Stitch Depth Display (Fig. 12)

    4.7.2 Digital stitch depth display (Fig. 12) The plunger height can be read off digitally from the stitch depth display. This makes finding earlier adjustments substantially easier by frequently changing sewing material thickness. The current supply is via a 9 V battery in the housing. To prevent premature discharging of the battery, the display should be switched off with the toggle switch at the housing during longer work breaks and when finishing work.

  • Page 28: Plunger Stop

    Plunger stop Frequently it is necessary when trimming fabric to sew over different fabric thicknesses at the same work piece, whereby the penetration depth of the needle, viewed from the upper side of the sewing material, must always remain the same. The plunger built- into our machines carries out this work automatically in cooperation with an adjustable plunger stop mounted on the stitch plate.

  • Page 29: Sewing Drive

    Fig. 13 Sewing drive The machine is equipped with a sewing drive. Please note the instructions available online. There you find notes and the instructions for programming the control including the motor speed adjustments. BA_327D_A2_200715_en.doc...

  • Page 30: Operating The Sewing Machine

    Operating the sewing machine C A U T I O N ! Danger of injury! Take sufficient care during sewing and observe the sewing area! Otherwise there is a danger of injury from crushing and needle punctures. For machines with 2 pedals: push down the left pedal fully increases the top feed length (multi-width take-up).

  • Page 31: Inserting And Removing The Sewing Material

    Inserting and removing the sewing material Foot lifting When during standstill of the machine the needle is approx. 15 mm after its upper dead point in front of the right penetration, the presser plate and the plunger can be moved downwards by activating the knee lever. At the same time the needle thread tension is vented.

  • Page 32: Sewing

    Sewing This machine performs a nice loose but resilient seam for felling the sleeve lining at the sleeve cuff on coats and jackets (minimum sleeve perimeter 24 cm). Productivity per day is app. 350 – 450 jackets. 5.3.1 Hemming with blind stitch If there are no experience values available, the best thing to do is to carry out the following settings in sequence: Adjust required stitch length...

  • Page 33: Problems During Sewing And Troubleshooting

    Problems during sewing and troubleshooting C A U T I O N ! Danger of injury! Switch off the machine and ensure it is switched off by pressing the pedal for switching the motor. Otherwise there is a danger of injury from crushing and needle punctures.
  • Page 34  Uneven stitching Possible reasons: frequently worn or damaged needles height of Stitch plate or needle slide plate incorrectly adjusted unsuitable needle thickness (too thin) Solutions: Replace damaged needle. Check adjustments and correct if necessary. Use correct needle thickness.  Missing loops Possible reasons: incorrectly adjusted or badly adjusted hook...

  • Page 35: Incorrect Stitches

     The sewing result does not come up to your expectations Possible reasons: Damaged sewing tools or wear caused by improper use or natural wear following long use of machine. The machine has become mechanically misadjusted Unsuitable needle thickness (see “4.1 Needles and threads”) Unsuitable sewing thread (see “4.1 Needles and threads”).

  • Page 36: Machine Maintenance

    Machine maintenance C A U T I O N ! Danger of injury! Switch off the machine electrically, and depress the motor switch pedal to make sure that the machine is truly switched off. Otherwise there is a danger of injury from crushing and needle punctures.
