ORiNG RGS-9244GP User Manual

Industrial rack-mount ethernet switch
Hide thumbs Also See for RGS-9244GP:
Table of Contents

Advertisement

Quick Links

Download this manual
RGS-9244GP
Industrial Rack-Mount Ethernet Switch
User Manual
Version 1.0
September, 2016
www.oring-networking.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RGS-9244GP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ORiNG RGS-9244GP

Summary of Contents for ORiNG RGS-9244GP

  • Page 1 RGS-9244GP Industrial Rack-Mount Ethernet Switch User Manual Version 1.0 September, 2016 www.oring-networking.com...
  • Page 2 ORing warrants that all ORing products are free from defects in material and workmanship for a specified warranty period from the invoice date (5 years for most products). ORing will repair or replace products found by ORing to be defective within this warranty period, with shipment expenses apportioned by ORing and the distributor.

  • Page 3: Table Of Contents

    Hardware Installation ................... 10 Rack-mount Installation ..................10 Wiring ........................11 3.2.1 AC Power Connection ..................... 11 3.2.2 DC Power Connection (RGS-9244GP-E only) ............12 3.2.3 Relay contact (RGS-9244GP-E only) ..............12 3.2.4 Grounding (RGS-9244GP-E only) ................12 Connection ......................12 3.3.1...
  • Page 4 RGS-9244GP Series User Manual 4.3.1 Introduction ......................21 4.3.2 Configurations ......................21 STP/RSTP/MSTP ....................22 4.4.1 STP/RSTP ......................22 STP Bridge Status ....................... 22 4.4.2 MSTP ........................25 4.4.3 CIST ........................28 Fast Recovery ......................30 Management ....................32 Basic Settings ......................33 5.1.1...
  • Page 5 RGS-9244GP Series User Manual 5.4.3 Private VLAN ....................67 SNMP ......................... 69 5.5.1 SNMP System Configurations ............... 69 5.5.2 SNMP Community Configurations ..............71 5.5.3 SNMP User Configurations ................72 5.5.4 SNMP Group Configurations ................. 73 5.5.5 SNMP View Configurations ................74 5.5.6...
  • Page 6 RGS-9244GP Series User Manual 5.8.6 NAS (802.1x) ....................121 Alerts ........................ 132 5.9.1 Fault Alarm ....................132 5.9.2 System Warning ..................132 5.10 Monitor and Diag ....................136 5.10.1 MAC Table ....................136 5.10.2 Port Statistics ..................139 5.10.3 Port Mirroring ................... 141 5.10.4...

  • Page 7: Getting Started

    The RGS-9244GP-E is an enhanced model with dual DC inputs and relay output. With complete support for Ethernet redundancy protocols such as O-Ring (recovery time <...

  • Page 8: Hardware Specifications

    RGS-9244GP Series User Manual  Supports 9.6K Bytes Jumbo Frame  Supports multiple notifications for incidents  Supports management via Web-based interfaces, Telnet, Console (CLI), and Windows utility (Open-Vision)  Supports LLDP Protocol 1.3 Hardware Specifications  19-inch rack mountable design ...

  • Page 9: Hardware Overview

    RGS-9244GP Series User Manual ardware Overview 2.1 Front Panel 2.1.1 Ports and Connectors The series comes with the following ports and connectors on the front panel. Port Description 24 x 10/100/1000Base-T(X) copper ports Ethernet ports 4 x 100/1000Base-X SFP ports...

  • Page 10: Rear Panel

    Transmitting data 2.2 Rear Panel The RGS-9244GP provides an AC power input on the back, while the RGS-9244GP-E comes with an AC and DC power input on the back. The terminal block on the RGS-9244GP-E includes redundant DC power supplies. RGS-9244GP RGS-9244GP-E 1.

  • Page 11: Hardware Installation

    RGS-9244GP Series User Manual ardware Installation 3.1 Rack-mount Installation The switch comes with two rack-mount kits to allow you to fasten the switch to a rack in any environments. Rack-mount measurement (Unit = mm) Follow the following steps to install the switch to a rack.

  • Page 12: Wiring

    3.2.1 AC Power Connection Both RGS-99244GP and RGS-9244GP-E can be powered by AC electricity. Simply insert the AC power cable to the power connector at the back of the switch and turn on the power switch. The input voltage is 100V~240V / 50~60Hz.

  • Page 13: Dc Power Connection (Rgs-9244Gp-E Only)

    RGS-9244GP Series User Manual 3.2.2 DC Power Connection (RGS-9244GP-E only) The RGS-9244GP-E supports dual DC power supplies, Power Supply 1 (PWR1) and Power Supply 2 (PWR2). The connections for PWR1, PWR2 and the RELAY are located on the terminal block.

  • Page 14: 1000Base-T Rj-45 Ports

    RGS-9244GP Series User Manual 10/100Base-T(X) RJ-45 ports Pin Number Assignment 1000Base-T RJ-45 ports Pin Number Assignment BI_DA+ BI_DA- BI_DB+ BI_DC+ BI_DC- BI_DB- BI_DD+ BI_DD- The series also support auto MDI/MDI-X operation. You can use a cable to connect the switch to a PC.

  • Page 15: Console Port Wiring

    RGS-9244GP Series User Manual 1000 Base-T MDI/MDI-X Pin Assignments: Pin Number MDI port MDI-X port BI_DA+ BI_DB+ BI_DA- BI_DB- BI_DB+ BI_DA+ BI_DC+ BI_DD+ BI_DC- BI_DD- BI_DB- BI_DA- BI_DD+ BI_DC+ BI_DD- BI_DC- Note: “+” and “-” signs represent the polarity of the wires that make up each wire pair.

  • Page 16: O-Ring/O-Chain

    RGS-9244GP Series User Manual Insert clean dust plugs into the SFPs after the cables are extracted from them. 2. Clean the optic surfaces of the fiber cables before you plug them back into the optical bores of another SFP module.
  • Page 17 RGS-9244GP Series User Manual connected, for example, switch A and B from Ring 1 and switch C and D from Ring 2. Decide which port on each switch to be used as the coupling port and then link them together, for example, port 1 of switch A to port 2 of switch C and port 1 of switch B to port 2 of switch D.
  • Page 18 RGS-9244GP Series User Manual O-Chain When connecting multiple O-Rings to meet your expansion demand, you can create an O- Chain topology through the following steps. 1. Select two switches from the chain (Switch A & B) that you want to connect to the O-Ring and connect them to the switches in the ring (Switch C &...

  • Page 19: Redundancy

    4.1 O-Ring 4.1.1 Introduction O-Ring is ORing's proprietary redundant ring technology, with recovery time of less than 30 milliseconds (in full-duplex Gigabit operation) or 10 milliseconds (in full-duplex Fast Ethernet operation) and up to 250 nodes. The ring protocols identify one switch as the master of the network, and then automatically block packets from traveling through any of the network’s...
  • Page 20 RGS-9244GP Series User Manual Label Description Check to enable O-Ring topology. Redundant Ring Only one ring master is allowed in a ring. However, if more than one switch are set to enable Ring Master, the switch with the Ring Master lowest MAC address will be the active ring master and the others will be backup masters.

  • Page 21: O-Chain

    RGS-9244GP Series User Manual 4.2 O-Chain 4.2.1 Introduction O-Chain is ORing’s revolutionary network redundancy technology which enhances network redundancy for any backbone networks, providing ease-of-use and maximum fault-recovery swiftness, flexibility, compatibility, and cost-effectiveness in a set of network redundancy topologies. The self-healing Ethernet technology designed for distributed and complex...

  • Page 22: Mrp (*Note)

    RGS-9244GP Series User Manual Label Description Enable Check to enable O-Chain function The first port connecting to the ring Ring Port Ring Port The second port connecting to the ring Edge Port An O-Chain topology must begin with edge ports. The ports with a smaller switch MAC address will serve as the backup link and RM LED will light up.

  • Page 23: Stp/Rstp/Mstp

    RGS-9244GP Series User Manual set to be Manager, the MRP topology will fail. React on Link Change Faster mode. Enabling this function will cause MRP topology to converge more rapidly. This function only can be set in MRP (Advanced mode) manager switch.
  • Page 24 RGS-9244GP Series User Manual sum of port path costs on the least cost path to the Root Bridge. Topology Flag The current state of the topology change flag for the bridge instance. Topology The time since last topology change occurred.
  • Page 25 RGS-9244GP Series User Manual Label Description The switch port number to which the following settings will be applied. Port The number of RSTP configuration BPDUs received/transmitted on the RSTP port The number of legacy STP configuration BPDUs received/transmitted on the port The number of (legacy) topology change notification BPDUs received/transmitted on the port.

  • Page 26: Mstp

    RGS-9244GP Series User Manual values is 4 to 30 seconds. The maximum time the information transmitted by the root bridge is considered valid. The range of valid values is 6 to 40 seconds, Max Age and Max Age must be <= (FwdDelay-1)*2.
  • Page 27 RGS-9244GP Series User Manual Label Description The switch port number of the corresponding STP CIST (and Port MSTI) port Configures the path cost incurred by the port. Auto will set the path cost according to the physical link speed by using the 802.1D- recommended values.
  • Page 28 RGS-9244GP Series User Manual Label Description The name which identifies the VLAN to MSTI mapping. Bridges must share the name and revision (see below), as well as the Configuration Name VLAN-to-MSTI mapping configurations in order to share spanning trees for MSTIs (intra-region). The name should not exceed 32 characters.

  • Page 29: Cist

    RGS-9244GP Series User Manual Priority This page allows you to examine and change the configurations of current STP MSTI bridge instance priority. Label Description The bridge instance. CIST is the default instance, which is always MSTI active. Indicates bridge priority. The lower the value, the higher the Priority priority.
  • Page 30 RGS-9244GP Series User Manual Port Settings Label Description Port The switch port number to which the following settings will be applied. STP Enabled Check to enable STP for the port Configures the path cost incurred by the port. Auto will set the path cost according to the physical link speed by using the 802.1D-...

  • Page 31: Fast Recovery

    RGS-9244GP Series User Manual a network administrator to prevent bridges outside a core region of the network from influencing the active spanning tree topology because those bridges are not under the full control of the administrator. This feature is also known as Root Guard.
  • Page 32 RGS-9244GP Series User Manual Label Description Active Activates fast recovery mode Ports can be set to 12 priorities. Only the port with the highest port priority will be the active port. 1st Priority is the highest. Apply Click to activate the configurations.

  • Page 33: Management

    RGS-9244GP Series User Manual anagement The switch can be controlled via a built-in web server which supports Internet Explorer (Internet Explorer 5.0 or above versions) and other Web browsers such as Chrome. Therefore, you can manage and configure the switch easily and remotely. You can also upgrade firmware via a web browser.

  • Page 34: Basic Settings

    RGS-9244GP Series User Manual After logging in, you will see the general information of the switch including its OID, MAC address, kernel version, and software version. On the right hand side of the management interface shows links to various settings. You can click on the links to access the configuration pages of different functions.

  • Page 35: Admin & Password

    RGS-9244GP Series User Manual allowed string length is 0 to 255, and only ASCII characters from 32 to 126 are allowed. Click to save changes. Save Reset Click to undo any changes made locally and revert to previously saved values.

  • Page 36: Ip Settings

    RGS-9244GP Series User Manual Label Description Client The management client for which the configuration below applies. Authentication Method can be set to one of the following values: Authentication None: authentication is disabled and login is not possible. Method Local: local user database on the switch is used for authentication.

  • Page 37: Ipv6 Settings

    RGS-9244GP Series User Manual Enable the DHCP client by checking this box. If DHCP fails or the configured IP address is zero, DHCP will retry. If DHCP retry fails, DHCP Client DHCP will stop trying and the configured IP settings will be used.

  • Page 38: Daylight Saving Time

    RGS-9244GP Series User Manual 128 bits represented as eight groups of four hexadecimal digits with a colon separating each field (:). For example, in 'fe80::215:c5ff:fe03:4dc7', the symbol '::' is a special syntax that can be used as a shorthand way of representing multiple 16-bit groups of contiguous zeros;...
  • Page 39 RGS-9244GP Series User Manual Label Description This is used to set the clock forward or backward according to the configurations set below for a defined Daylight Saving Time duration. Select Disable to disable the configuration or Recurring Daylight Saving Time to configure the duration to repeat every year.

  • Page 40: Https

    RGS-9244GP Series User Manual Label Description Week Select the ending week number. Select the ending day. Select the ending month. Month Hours Select the ending hour. Select the ending minute. Minutes Offset Settings Label Description Offset Configures the offset time. The time is measured by minute.

  • Page 41: Ssh

    RGS-9244GP Series User Manual 5.1.8 SSH You can configure SSH settings in the following page. Label Description Indicates the selected SSH mode. The modes include: Mode Enabled: enable SSH. Disabled: disable SSH. Save Click to save changes Click to undo any changes made locally and revert to previously...
  • Page 42 RGS-9244GP Series User Manual Rx only: the switch will not send out LLDP information, but LLDP information from its neighbors will be analyzed. Tx only: the switch will drop LLDP information received from its neighbors, but will send out LLDP information.
  • Page 43 RGS-9244GP Series User Manual Management The neighbor's address which can be used to help network Address management. This may contain the neighbor's IP address. Click to refresh the page immediately Refresh Check to enable an automatic refresh of the page at regular...

  • Page 44: Modbus Tcp

    RGS-9244GP Series User Manual Label Description Local Port The port that receives or transmits LLDP frames Tx Frames The number of LLDP frames transmitted on the port The number of LLDP frames received on the port Rx Frames Rx Errors...

  • Page 45: Backup/Restore Configurations

    RGS-9244GP Series User Manual Label Description Mode Shows the existing status of the Modbus TCP function 5.1.11 Backup/Restore Configurations You can save/view or load switch configurations. The configuration file is in XML format. 5.1.12 Firmware Update This page allows you to update the firmware of the switch.

  • Page 46: Dynamic Client List

    RGS-9244GP Series User Manual checkbox to activate the function. Once the box is checked, you will be able to input information in each column. 5.2.2 Dynamic Client List When DHCP server functions are activated, the switch will collect DHCP client information and display in the following table.
  • Page 47 RGS-9244GP Series User Manual DHCP relay is used to forward and transfer DHCP messages between the clients and the server when they are not in the same subnet domain. You can configure the function in this page. Label Description Relay Mode Indicates the existing DHCP relay mode.
  • Page 48 RGS-9244GP Series User Manual Disabled: disable DHCP relay information Relay Information Indicates the policies to be enforced when receiving DHCP relay information. When DHCP relay information mode is enabled, if the Policy agent receives a DHCP message that already contains relay agent information, it will enforce the policy.

  • Page 49: Port Setting

    RGS-9244GP Series User Manual Receive Bad Remote ID The number of packets whose Remote ID do not match the known Remote ID Label Description Transmit to Client The number of packets relayed from the server to the client Transmit Error...
  • Page 50 RGS-9244GP Series User Manual Label Description The switch port number to which the following settings will be Port applied. The current link state is shown by different colors. Green indicates Link the link is up and red means the link is down.

  • Page 51: Port Trunk

    RGS-9244GP Series User Manual Shows the current power consumption of each port in percentage. The Configured column allows you to change power saving parameters for each port. Power Control Disabled: all power savings functions are disabled ActiPHY: link down and power savings enabled...
  • Page 52 RGS-9244GP Series User Manual default, TCP/UDP Port Number is enabled. Label Description Group ID Indicates the ID of each aggregation group. Normal means no aggregation. Only one group ID is valid per port. Port Members Lists each switch port for each group ID. Select a radio button to include a port in an aggregation, or clear the radio button to remove the port from the aggregation.
  • Page 53 RGS-9244GP Series User Manual Label Description Port Indicates the ID of each aggregation group. Normal indicates there is no aggregation. Only one group ID is valid per port. LACP Enabled Lists each switch port for each group ID. Check to include a port in an aggregation, or clear the box to remove the port from the aggregation.
  • Page 54 RGS-9244GP Series User Manual saved values LACP System Status This page provides a status overview for all LACP instances. Label Description Aggr ID The aggregation ID is associated with the aggregation instance. For LLAG, the ID is shown as 'isid:aggr-id' and for GLAGs as...
  • Page 55 RGS-9244GP Series User Manual Label Description Port Switch port number LACP Yes means LACP is enabled and the port link is up. No means LACP is not enabled or the port link is down. Backup means the port cannot join in the aggregation group unless other ports are removed. The LACP status is disabled.

  • Page 56: Loop Gourd

    RGS-9244GP Series User Manual Label Description Port Switch port number LACP Transmitted The number of LACP frames sent from each port LACP Received The number of LACP frames received at each port Discarded The number of unknown or illegal LACP frames discarded at each port.
  • Page 57 RGS-9244GP Series User Manual Label Description Enable Loop Protection Activate loop protection functions (as a whole) Transmission Time The interval between each loop protection PDU sent on each port. The valid value is 1 to 10 seconds. Shutdown Time The period (in seconds) for which a port will be kept disabled when a loop is detected (shutting down the port).

  • Page 58: Vlan

    RGS-9244GP Series User Manual Label Description The switch port number of the logical port. Port Action The currently configured port action. Transmit The currently configured port transmit mode. Loops The number of loops detected on this port. Status The current loop protection status of the port Loop Whether a loop is currently detected on the port.

  • Page 59: Port Configurations

    RGS-9244GP Series User Manual Label Description Delete Check to delete the entry. It will be deleted during the next save. VLAN ID The VLAN ID for the entry The MAC address for the entry MAC Address Checkmarks indicate which ports are members of the entry. Check or...

  • Page 60: Introduction Of Port Types

    RGS-9244GP Series User Manual customer S- setting for all custom S-ports. Ports The switch port number to which the following settings will be applied. Port Port can be one of the following types: Unaware, Customer (C-port), Service (S-port), Custom Service (S-custom-port).
  • Page 61 RGS-9244GP Series User Manual custom-port. Ingress action Egress action Unaware When the port receives untagged frames, The TPID of a frame an untagged frame obtains a tag (based transmitted by The function of on PVID) and is forwarded. Unaware port will be...
  • Page 62 RGS-9244GP Series User Manual Custom S-ports. ORing Industrial Networking Corp.
  • Page 63 RGS-9244GP Series User Manual ORing Industrial Networking Corp.

  • Page 64: Examples Of Vlan Settings

    RGS-9244GP Series User Manual Examples of VLAN Settings VLAN Access Mode: Switch Port 7 is VLAN Access mode = Untagged 20 Port 8 is VLAN Access mode = Untagged 10 Below are the switch settings. ORing Industrial Networking Corp.
  • Page 65 RGS-9244GP Series User Manual VLAN 1Q Trunk Mode: Switch Port 1 = VLAN 1Qtrunk mode = tagged 10, 20 Port 2 = VLAN 1Qtrunk mode = tagged 10, 20 Below are the switch settings. ORing Industrial Networking Corp.
  • Page 66 RGS-9244GP Series User Manual VLAN Hybrid Mode: Port 1 VLAN Hybrid mode = untagged 10 Tagged 10, 20 Below are the switch settings. ORing Industrial Networking Corp.
  • Page 67 RGS-9244GP Series User Manual VLAN QinQ Mode: VLAN QinQ mode is usually adopted when there are unknown VLANs, as shown in the figure below VLAN “X” = Unknown VLAN 9000 Series Port 1 VLAN Settings: ORing Industrial Networking Corp.

  • Page 68: Private Vlan

    RGS-9244GP Series User Manual VLAN ID Settings When setting the management VLAN, only the same VLAN ID port can be used to control the switch. 9000 series VLAN Settings: 5.4.3 Private VLAN The private VLAN membership configuration for the switch can be monitored and modified here.
  • Page 69 RGS-9244GP Series User Manual Label Description Delete Check to delete the entry. It will be deleted during the next save. Private VLAN ID Indicates the ID of this particular private VLAN. The MAC address for the entry. MAC Address A row of check boxes for each port is displayed for each private VLAN ID.

  • Page 70: Snmp

    RGS-9244GP Series User Manual Label Description A check box is provided for each port of a private VLAN. When checked, port isolation is enabled for that port. Port Members When unchecked, port isolation is disabled for that port. By default, port isolation is disabled for all ports.
  • Page 71 RGS-9244GP Series User Manual SNMP v3: supports SNMP version 3. Indicates the read community string to permit access to SNMP agent. The allowed string length is 0 to 255, and only ASCII characters from 33 to 126 are allowed. Read Community The field only suits to SNMPv1 and SNMPv2c.

  • Page 72: Snmp Community Configurations

    RGS-9244GP Series User Manual include: SNMP v1: supports SNMP trap version 1 SNMP v2c: supports SNMP trap version 2c SNMP v3: supports SNMP trap version 3 Indicates the community access string when sending SNMP trap Trap Community packets. The allowed string length is 0 to 255, and only ASCII characters from 33 to 126 are allowed.

  • Page 73: Snmp User Configurations

    RGS-9244GP Series User Manual Label Description Delete Check to delete the entry. It will be deleted during the next save. Indicates the community access string to permit access to SNMPv3 agent. The allowed string length is 1 to 32, and only ASCII characters Community from 33 to 126 are allowed.

  • Page 74: Snmp Group Configurations

    RGS-9244GP Series User Manual communicate. In other words, if user engine ID is the same as system engine ID, then it is local user; otherwise it's remote user. A string identifying the user name that this entry should belong to. The...

  • Page 75: Snmp View Configurations

    RGS-9244GP Series User Manual Label Description Delete Check to delete the entry. It will be deleted during the next save. Indicates the security model that this entry should belong to. Possible security models included: Security Model v1: Reserved for SNMPv1.

  • Page 76: Snmp Access Configurations

    RGS-9244GP Series User Manual Label Description Delete Check to delete the entry. It will be deleted during the next save. A string identifying the view name that this entry should belong to. The View Name allowed string length is 1 to 32, and only ASCII characters from 33 to 126 are allowed.

  • Page 77: Traffic Prioritization

    RGS-9244GP Series User Manual any: Accepted any security model (v1|v2c|usm). v1: Reserved for SNMPv1. v2c: Reserved for SNMPv2c. usm: User-based Security Model (USM). Indicates the security model that this entry should belong to. Possible security models include: Security Level NoAuth, NoPriv: no authentication and no privacy...

  • Page 78: Port Classification

    RGS-9244GP Series User Manual Label Description The settings in a particular row apply to the frame type listed here: Frame Type unicast, multicast, or broadcast. Enable or disable the storm control status for the given frame type. Status The rate unit is packet per second (pps), configure the rate as 1K, Rate 2K, 4K, 8K, 16K, 32K, 64K, 128K, 256K, 512K, or 1024K.
  • Page 79 RGS-9244GP Series User Manual Label Description Port The port number for which the configuration below applies Controls the default QoS class All frames are classified to a QoS class. There is a one to one mapping between QoS class, queue, and priority. A QoS class of 0 (zero) has the lowest priority.

  • Page 80: Port Tag Remaking

    RGS-9244GP Series User Manual configured default QoS class. Controls the default Drop Precedence Level All frames are classified to a DP level. If the port is VLAN aware and the frame is tagged, then the frame is classified to a DP level that is equal to the DEI value in the tag.

  • Page 81: Port Dscp

    RGS-9244GP Series User Manual Label Description The switch port number to which the following settings will be Port applied. Click on the port number to configure tag remarking Shows the tag remarking mode for this port Classified: use classified PCP/DEI values...
  • Page 82 RGS-9244GP Series User Manual Label Description Shows the list of ports for which you can configure DSCP Ingress Port and Egress settings. In Ingress settings you can change ingress translation and classification settings for individual ports. Ingress There are two configuration parameters available in Ingress: 1.

  • Page 83: Port Policing

    RGS-9244GP Series User Manual DSCP value is always taken from the 'DSCP Translation->Egress Remap DP0' table. Remap DP Aware: DSCP from the analyzer is remapped and the frame is remarked with a remapped DSCP value. Depending on the DP level of the frame, the remapped DSCP value is either taken from the 'DSCP Translation->Egress Remap DP0' table or from...

  • Page 84: Queue Policing

    RGS-9244GP Series User Manual then pause frames are sent instead of being discarded. 5.6.6 Queue Policing This page allows you to configure Queue Policer settings for all switch ports. Label Description Port The port number for which the configuration below applies.
  • Page 85 RGS-9244GP Series User Manual Label Description Controls whether the scheduler mode is Strict Priority or Scheduler Mode Weighted on this switch port Queue Shaper Enable Check to enable queue shaper for individual switch ports Configures the rate of each queue shaper. The default value is Queue Shaper Rate 500.
  • Page 86 RGS-9244GP Series User Manual kbps or Mbps. The default value is kbps. Weighted Label Description Controls whether the scheduler mode is Strict Priority or Scheduler Mode Weighted on this switch port Check to enable queue shaper for individual switch ports Queue Shaper Enable Configures the rate of each queue shaper.

  • Page 87: Port Scheduled

    RGS-9244GP Series User Manual Weight This value is restricted to 1 to 100. This parameter is only shown if Scheduler Mode is set to Weighted. Shows the weight of the queue in percentage. This parameter is Queue Scheduler Percent only shown if Scheduler Mode is set to Weighted.

  • Page 88: Dscp Based Qos

    RGS-9244GP Series User Manual Label Description The switch port number to which the following settings will be Port applied. Click on the port number to configure the shapers Mode Shows disabled or actual queue shaper rate - e.g. "800 Mbps"...

  • Page 89: Dscp Translation

    RGS-9244GP Series User Manual as a non-IP frame. QoS Class QoS class value can be any number from 0-7. Drop Precedence Level (0-1) 5.6.11 DSCP Translation This page allows you to configure basic QoS DSCP translation settings for all switches. DSCP translation can be done in Ingress or Egress.

  • Page 90: Dscp Classification

    RGS-9244GP Series User Manual select the DSCP value from a selected menu to which you want to remap. DSCP value ranges form 0 to 63. 5.6.12 DSCP Classification This page allows you to configure the mapping of QoS class and Drop Precedence Level to DSCP value.
  • Page 91 RGS-9244GP Series User Manual Label Description Port Check to include the port in the QCL entry. By default, all ports are Members included. Key configurations include: Parameters Tag: value of tag, can be Any, Untag or Tag. VID: valid value of VLAN ID, can be any value from 1 to 4095 Any: user can enter either a specific value or a range of VIDs.
  • Page 92 RGS-9244GP Series User Manual IPv6 Note: all frame types are explained below. Allow all types of frames Ethernet Valid Ethernet values can range from 0x600 to 0xFFFF or Any' but excluding 0x800(IPv4) and 0x86DD (IPv6). The default value is Any.

  • Page 93: Qos Counters

    RGS-9244GP Series User Manual Parameters Valid Drop Precedence Level value can be (0-1) or Default. Valid DSCP value can be (0-63, BE, CS1-CS7, EF or AF11-AF43) or Default. Default means that the default classified value is not modified by this QCE.

  • Page 94: Multicast

    RGS-9244GP Series User Manual Label Description Indicates the QCL user User QCE# Indicates the index of QCE Indicates the type of frame to look for incoming frames. Possible frame types are: Any: the QCE will match all frame type. Ethernet: Only Ethernet frames (with Ether Type 0x600-0xFFFF) are allowed.

  • Page 95: Vlan Configurations Of Igmp Snooping

    RGS-9244GP Series User Manual Label Description Check to enable global IGMP snooping Snooping Enabled Unregistered Check to enable unregistered IPMC traffic flooding IPMCv4Flooding enabled Specifies which ports act as router ports. A router port is a port on the Ethernet switch that leads towards the Layer 3 Router Port multicast device or IGMP querier.

  • Page 96: Igmp Snooping Status

    RGS-9244GP Series User Manual The VLAN input field allows the user to select the starting point in the VLAN Table. Clicking the Refresh button will update the displayed table starting from that or the next closest VLAN Table match. The >> will use the last entry of the currently displayed entry as a basis for the next lookup.

  • Page 97: Groups Information Of Igmp Snooping

    RGS-9244GP Series User Manual Label Description The VLAN ID of the entry VLAN ID Querier Version Active Querier version Host Version Active Host version Querier Status Shows the Querier status as ACTIVE or IDLE Querier Receive The number of transmitted Querier...

  • Page 98: Security

    RGS-9244GP Series User Manual Label Description The VLAN ID of the group VLAN ID Groups The group address of the group displayed Port Members Ports under this group 5.8 Security 5.8.1 Remote Control Security Configurations Remote Control Security allows you to limit the remote access to the management interface.

  • Page 99: Device Binding

    RGS-9244GP Series User Manual Delete Check to delete entries 5.8.2 Device Binding This page provides device binding configurations. Device binding is a powerful way to monitor devices and network security. Label Description Indicates the device binding operation for each port. Possible...
  • Page 100 RGS-9244GP Series User Manual Low: the stream is getting low. DDoS Prevention Check to enable DDOS prevention. When enabled, the switch will monitor the device against DDOS attacks. Acton Indicates DDOS prevention status. Possible statuses are: ---: disable DDoS Prevention...
  • Page 101 RGS-9244GP Series User Manual Label Description Mode Disables or enables the port The action to be taken when the link fails, such as shutting down the port and logging the event, simply logging the event, and Action rebooting. DDoS Prevention This page provides DDOS Prevention configurations.
  • Page 102 RGS-9244GP Series User Manual Low: low sensibility Normal: normal sensibility Medium: medium sensibility High: high sensibility Indicates the types of DDoS attack packets to be monitored. Possible types are: RX Total: all ingress packets RX Unicast: unicast ingress packets Packet Type...
  • Page 103 RGS-9244GP Series User Manual Label Description Indicates device types. Possible types are: --- (no specification), IP Device Type Camera, IP Phone, Access Point, PC, PLC, and Network Video Recorder Indicates location information of the device. The information can be Location Address used for Google Mapping.

  • Page 104: Acl

    RGS-9244GP Series User Manual Label Description Mode Enables or disables stream monitoring of the port Indicates the action to take when the stream gets low. Possible actions are: Action ---: no action Log it: simply logs the event 5.8.3 ACL Ports This page allows you to configure the ACL parameters (ACE) of each switch port.
  • Page 105 RGS-9244GP Series User Manual Select to apply a policy to the port. The allowed values are 1 to 8. The Policy ID default value is 1. Select to Permit to permit or Deny to deny forwarding. The default Action value is Permit.
  • Page 106 RGS-9244GP Series User Manual Rate Limiter ID The rate limiter ID for the settings contained in the same row. The rate unit is packet per second (pps), which can be configured as 1, 2, 4, 8, 16, 32, 64, 128, 256, 512, 1K, 2K, 4K, 8K, 16K, 32K, 64K, Rate 128K, 256K, 512K, or 1024K.
  • Page 107 RGS-9244GP Series User Manual IPv4: only IPv4 frames can match the ACE. Notice the IPv4 frames will not match the ACE with Ethernet type. Specifies the action to take when a frame matches the ACE. Action Permit: takes action when the frame matches the ACE.
  • Page 108 RGS-9244GP Series User Manual matching the ACE will use this SMAC value. Specifies the destination MAC filter for this ACE Any: no DMAC filter is specified (DMAC filter status is "don't-care"). MC: frame must be multicast. DMAC Filter BC: frame must be broadcast.
  • Page 109 RGS-9244GP Series User Manual Label Description Specifies the IP protocol filter for the ACE Any: no IP protocol filter is specified ("don't-care"). Specific: if you want to filter a specific IP protocol filter with the ACE, choose this value. A field for entering an IP protocol filter appears.
  • Page 110 RGS-9244GP Series User Manual No: IPv4 frames whose MF bit is set or the FRAG OFFSET field is greater than zero must not be able to match this entry. Yes: IPv4 frames whose MF bit is set or the FRAG OFFSET field is greater than zero must be able to match this entry.
  • Page 111 RGS-9244GP Series User Manual Label Description Specifies the available ARP/RARP opcode (OP) flag for the ACE Any: no ARP/RARP OP flag is specified (OP is "don't-care"). ARP/RARP ARP: frame must have ARP/RARP opcode set to ARP RARP: frame must have ARP/RARP opcode set to RARP.
  • Page 112 RGS-9244GP Series User Manual Network: target IP filter is set to Network. Specify the target IP address and target IP mask in the Target IP Address and Target IP Mask fields that appear. When Host or Network is selected for the target IP filter, you can Target IP Address enter a specific target IP address in dotted decimal notation.
  • Page 113 RGS-9244GP Series User Manual 1: ARP/RARP frames where the PRO is equal to IP (0x800) must match this entry. Any: any value is allowed ("don't-care"). Label Description Specifies the ICMP filter for the ACE Any: no ICMP filter is specified (ICMP filter status is "don't-care").
  • Page 114 RGS-9244GP Series User Manual Label Description Specifies the TCP/UDP source filter for the ACE Any: no TCP/UDP source filter is specified (TCP/UDP source filter status is "don't-care"). Specific: if you want to filter a specific TCP/UDP source filter with the TCP/UDP Source ACE, you can enter a specific TCP/UDP source value.
  • Page 115 RGS-9244GP Series User Manual Range: if you want to filter a specific range TCP/UDP destination filter with the ACE, you can enter a specific TCP/UDP destination range. A field for entering a TCP/UDP destination value appears. When Specific is selected for the TCP/UDP destination filter, you can TCP/UDP enter a specific TCP/UDP destination value.

  • Page 116: Aaa

    RGS-9244GP Series User Manual entry. Any: any value is allowed ("don't-care"). Specifies the TCP URG ("urgent pointer field significant") value for the 0: TCP frames where the URG field is set must not be able to match TCP URG this entry.
  • Page 117 RGS-9244GP Series User Manual but only if more than one server has been configured. 5.8.5 RADIUS Authentication and Accounting Server Configurations The table has one row for each RADIUS authentication server and a number of columns, which are: Label Description The RADIUS authentication server number for which the configuration below applies.

  • Page 118: Authentication And Accounting Server Status Overview

    RGS-9244GP Series User Manual below applies. Enabled Check to enable the RADIUS accounting server The IP address or hostname of the RADIUS accounting server. IP IP Address address is expressed in dotted decimal notation. The UDP port to use on the RADIUS accounting server. If the port is...

  • Page 119: Authentication And Accounting Server Statistics

    RGS-9244GP Series User Manual temporarily been disabled, but will be re-enabled when the dead-time expires. The number of seconds left before this occurs is displayed in parentheses. This state is only reachable when more than one server is enabled. Label Description The RADIUS server number.
  • Page 120 RGS-9244GP Series User Manual Label Description RADIUS authentication server packet counters. There are seven ‘receive’ and four ‘transmit’ counters. Packet Counters This section contains information about the state of the server and the latest Other Info round-trip time. ORing Industrial Networking Corp.
  • Page 121 RGS-9244GP Series User Manual Label Description RADIUS accounting server packet counters. There are five ‘receive’ and four ‘transmit’ counters. Packet Counters ORing Industrial Networking Corp.

  • Page 122: Nas (802.1X)

    RGS-9244GP Series User Manual This section contains information about the state of the server and the latest round-trip time. Other Info 5.8.6 NAS (802.1x) This page allows you to configure the IEEE 802.1X and MAC-based authentication system and port settings.
  • Page 123 RGS-9244GP Series User Manual supplicant and the authentication server are using, or how many information exchange frames are needed for a particular method. The switch simply encapsulates the EAP part of the frame into the relevant type (EAPOL or RADIUS) and forwards it.
  • Page 124 RGS-9244GP Series User Manual authentication, and that the clients do npt need special supplicant software to authenticate. The disadvantage is that MAC addresses can be spoofed by malicious users, equipment whose MAC address is a valid RADIUS user can be used by anyone, and only the MD5-Challenge method is supported.
  • Page 125 RGS-9244GP Series User Manual does not imply that a client is still present on a port (see Age Period below). Determines the period, in seconds, after which a connected client Reauthentication must re-authenticated. This only active Period Reauthentication Enabled checkbox is checked. Valid range of the value is 1 to 3600 seconds.
  • Page 126 RGS-9244GP Series User Manual Port The port number for which the configuration below applies If NAS is globally enabled, this selection controls the port's authentication mode. The following modes are available: Force Authorized In this mode, the switch will send one EAPOL Success frame when the port link is up, and any client on the port will be allowed network access without authentication.
  • Page 127 RGS-9244GP Series User Manual Note: in an environment where two backend servers are enabled, the server timeout is configured to X seconds (using the authentication configuration page), and the first server in the list is currently down (but not considered dead), if the supplicant...
  • Page 128 RGS-9244GP Series User Manual successfully authenticated on a port, the whole port is opened for network traffic. This allows other clients connected to the port (for instance through a hub) to piggy-back on the successfully authenticated client and get network access even though they are not authenticated individually.
  • Page 129 RGS-9244GP Series User Manual RADIUS server must be configured accordingly. When authentication is complete, the RADIUS server sends a success or failure indication, which in turn causes the switch to open up or block traffic for that particular client, using the Port Security module.
  • Page 130 RGS-9244GP Series User Manual Clicking these buttons will not cause settings changed on the page to take effect. Reauthenticate: schedules a reauthentication whenever the quiet-period of the port runs out (EAPOL-based authentication). For MAC-based authentication, reauthentication will be attempted immediately.
  • Page 131 RGS-9244GP Series User Manual received Response Identity EAPOL frame for EAPOL-based authentication, and the source MAC address from the most recently received frame from a new client for MAC-based authentication. This page provides detailed IEEE 802.1X statistics for a specific switch port using port-based authentication.
  • Page 132 RGS-9244GP Series User Manual These backend (RADIUS) frame counters are available for the following administrative states: • 802.1X • MAC-based Auth. Backend Server Counters Information about the last supplicant/client that attempts to authenticate. Last This information is available for the following administrative states: Supplicant/Clie •...

  • Page 133: Alerts

    RGS-9244GP Series User Manual 5.9 Alerts 5.9.1 Fault Alarm When any selected fault event happens, the Fault LED on the switch panel will light up and the electric relay will signal at the same time. 5.9.2 System Warning SYSLOG Setting The SYSLOG is a protocol that transmits event notifications across networks.
  • Page 134 RGS-9244GP Series User Manual Label Description Server Mode Indicates existing server mode. When the mode operation is enabled, the syslog message will be sent to syslog server. The syslog protocol is based on UDP communications and received on UDP port 514 and...
  • Page 135 RGS-9244GP Series User Manual Label Description Enables or disables transmission of system warnings by e-mail E-mail Alarm Sender E-mail SMTP server IP address Address Subject of the mail Mail Subject  Username: the authentication username Authentication  Password: the authentication password ...
  • Page 136 RGS-9244GP Series User Manual Label Description System Cold Start Sends out alerts when the system is restarted Sends out alerts when power is up or down Power Status SNMP Authentication Failure Sends out alert when SNMP authentication fails O-Ring Topology Change Sends out alerts when O-Ring topology changes ...

  • Page 137: Monitor And Diag

    RGS-9244GP Series User Manual 5.10 Monitor and Diag 5.10.1 MAC Table The MAC address table can be configured on this page. You can set timeouts for entries in the dynamic MAC table and configure the static MAC table here. Aging Configuration By default, dynamic entries are removed from the MAC after 300 seconds.
  • Page 138 RGS-9244GP Series User Manual settings: Label Description Learning is done automatically as soon as a frame with unknown Auto SMAC is received. Disable No learning is done. Only static MAC entries are learned, all other frames are dropped. Note: make sure the link used for managing the switch is added to...
  • Page 139 RGS-9244GP Series User Manual MAC Address The MAC address for the entry Checkmarks indicate which ports are members of the entry. Check Port Members or uncheck to modify the entry. Click to add a new entry to the static MAC table. You can specify Adding New Static the VLAN ID, MAC address, and port members for the new entry.

  • Page 140: Port Statistics

    RGS-9244GP Series User Manual Label Description Type Indicates whether the entry is a static or dynamic entry MAC address The MAC address of the entry The VLAN ID of the entry VLAN Port Members The ports that are members of the entry.
  • Page 141 RGS-9244GP Series User Manual The number of frames received in error and the number of incomplete Errors transmissions per port The number of frames discarded due to ingress or egress congestion Drops Filtered The number of received frames filtered by the forwarding process Auto-refresh Check to enable an automatic refresh of the page at regular intervals.

  • Page 142: Port Mirroring

    RGS-9244GP Series User Manual Label Description Rx and Tx The number of received and transmitted (good and bad) packets Packets The number of received and transmitted (good and bad) bytes, Rx and Tx Octets including FCS, except framing bits The number of received and transmitted (good and bad) unicast...

  • Page 143: System Log Information

    RGS-9244GP Series User Manual or destination (tx) mirroring enabled are mirrored to this port. Disabled option disables mirroring. Label Description Port The switch port number to which the following settings will be applied. Drop-down list for selecting a mirror mode.

  • Page 144: Cable Diagnostics

    RGS-9244GP Series User Manual Label Description The ID (>= 1) of the system log entry The level of the system log entry. The following level types are supported: Info: provides general information Level Warning: provides warning for abnormal operation Error: provides error message...

  • Page 145: Sfp Monitor

    RGS-9244GP Series User Manual Press Start to run the diagnostics. This will take approximately 5 seconds. If all ports are selected, this can take approximately 15 seconds. When completed, the page refreshes automatically, and you can view the cable diagnostics results in the cable status table. Note that VeriPHY diagnostics is only accurate for cables 7 - 140 meters long.

  • Page 146: Ping

    RGS-9244GP Series User Manual 5.10.7 Ping This page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues After you press Start, five ICMP packets will be transmitted, and the sequence number and roundtrip time will be displayed upon reception of a reply. The page refreshes automatically until responses to all packets are received, or until a timeout occurs PING6 server ::10.10.132.20...

  • Page 147: Ipv6 Ping

    RGS-9244GP Series User Manual 64 bytes from ::10.10.132.20: icmp_seq=3, time=0ms 64 bytes from ::10.10.132.20: icmp_seq=4, time=0ms Sent 5 packets, received 5 OK, 0 bad You can configure the following properties of the issued ICMP packets Label Description IP Address The destination IP Address Ping Size The payload size of the ICMP packet.

  • Page 148: System Reboot

    RGS-9244GP Series User Manual Label Description Click to reset the configuration to factory defaults Click to return to the Port State page without resetting 5.11.2 System Reboot You can reset the stack switch on this page. After reset, the system will boot normally as if you...

  • Page 149: Command Line Interface Management

    RGS-9244GP Series User Manual ommand Line Interface Management Besides Web-based management, the device also support CLI management. You can use console or telnet to manage the switch by CLI. CLI Management by RS-232 Serial Console (115200, 8, none, 1, none) Before configuring RS-232 serial console, connect the RS-232 port of the switch to your PC Com port using a RJ45 to DB9-F cable.
  • Page 150 RGS-9244GP Series User Manual Step 2: Input a name for the new connection. Step 3: Select a COM port in the drop-down list. ORing Industrial Networking Corp.
  • Page 151 RGS-9244GP Series User Manual Step 4: A pop-up window that indicates COM port properties appears, including bits per second, data bits, parity, stop bits, and flow control. Step 5: The console login screen will appear. Use the keyboard to enter the Username and Password (same as the password for Web browsers), then press Enter.
  • Page 152 RGS-9244GP Series User Manual CLI Management by Telnet You can can use TELNETto configure the switch. The default values are: IP Address: 192.168.10.1 Subnet Mask: 255.255.255.0 Default Gateway: 192.168.10.254 User Name: admin Password: admin Follow the steps below to access console via Telnet.
  • Page 153 RGS-9244GP Series User Manual (same as the password for Web browser), and then press Enter. Commander Groups ORing Industrial Networking Corp.
  • Page 154 RGS-9244GP Series User Manual ORing Industrial Networking Corp.
  • Page 155 RGS-9244GP Series User Manual System Configuration [all] [<port_list>] Reboot Restore Default [keep_ip] Contact [<contact>] Name [<name>] Location [<location>] System> Description [<description>] Password <password> Username [<username>] Timezone [<offset>] Log [<log_id>] [all|info|warning|error] [clear] Configuration DHCP [enable|disable] IP> Setup [<ip_addr>] [<ip_mask>] [<ip_router>] [<vid>] Ping <ip_addr_string>...
  • Page 156 RGS-9244GP Series User Manual Delete <mac_addr> [<vid>] Lookup <mac_addr> [<vid>] Agetime [<age_time>] Learning [<port_list>] [auto|disable|secure] Dump [<mac_max>] [<mac_addr>] [<vid>] Statistics [<port_list>] Flush VLAN Configuration [<port_list>] PVID [<port_list>] [<vid>|none] FrameType [<port_list>] [all|tagged|untagged] IngressFilter [<port_list>] [enable|disable] tx_tag [<port_list>] [untag_pvid|untag_all|tag_all] PortType [<port_list>] [unaware|c-port|s-port|s-custom-port] EtypeCustomSport [<etype>]...
  • Page 157 RGS-9244GP Series User Manual Switch Switch security setting Security > Network Network security setting Authentication, Authorization and Accounting setting Security Switch Password <password> Auth Authentication Secure Shell Security/switch> HTTPS Hypertext Transfer Protocol over Secure Socket Layer RMON Remote Network Monitoring...
  • Page 158 RGS-9244GP Series User Manual <falling_threshold> <falling_event_index> [rising|falling|both] Alarm Delete <alarm_id> Alarm Lookup [<alarm_id>] Security Network Psec Port Security Status Network Access Server (IEEE 802.1X) Security/Network> Access Control List DHCP Dynamic Host Configuration Protocol Security Network Psec Switch [<port_list>] Security/Network/Psec> Port [<port_list>] Security Network NAS Configuration [<port_list>]...
  • Page 159 RGS-9244GP Series User Manual [<tag_prio>] [<dmac_type>][(etype [<etype>] [<smac>] [<dmac>]) | (arp [<sip>] [<dip>] [<smac>] [<arp_opcode>] [<arp_flags>]) | [<sip>] [<dip>] [<protocol>] [<ip_flags>]) | (icmp [<sip>] [<dip>] [<icmp_type>] [<icmp_code>] [<ip_flags>]) | (udp [<sip>] [<dip>] [<sport>] [<dport>] [<ip_flags>]) | (tcp [<sip>] [<dip>] [<sport>] [<dport>] [<ip_flags>] [<tcp_flags>])]...
  • Page 160 RGS-9244GP Series User Manual [<ip_addr_string>] [<secret>] [<server_port>] Statistics [<server_index>] Configuration Version [<stp_version>] Non-certified release, v Txhold [<holdcount>]lt 15:15:15, Dec 6 2007 MaxAge [<max_age>] FwdDelay [<delay>] bpduFilter [enable|disable] bpduGuard [enable|disable] recovery [<timeout>] CName [<config-name>] [<integer>] Status [<msti>] [<port_list>] Msti Priority [<msti>] [<priority>] Msti Map [<msti>] [clear]...
  • Page 161 RGS-9244GP Series User Manual Delete <aggr_id> Lookup [<aggr_id>] Mode [smac|dmac|ip|port] [enable|disable] LACP Configuration [<port_list>] Mode [<port_list>] [enable|disable] Key [<port_list>] [<key>] LACP> Role [<port_list>] [active|passive] Status [<port_list>] Statistics [<port_list>] [clear] LLDP Configuration [<port_list>] Mode [<port_list>] [enable|disable] LLDP> Statistics [<port_list>] [clear] Info [<port_list>] DSCP Map [<dscp_list>] [<class>] [<dpl>]...
  • Page 162 RGS-9244GP Series User Manual (ipv4 [<protocol>] [<sip>] [<dscp>] [<fragment>] [<sport>] [<dport>]) | (ipv6 [<protocol>] [<sip_v6>] [<dscp>] [<sport>] [<dport>])] [<class>] [<dp>] [<classified_dscp>] QCL Delete <qce_id> QCL Lookup [<qce_id>] QCL Status [combined|static|conflicts] QCL Refresh Mirror Configuration [<port_list>] Mirror> Port [<port>|disable] Mode [<port_list>] [enable|disable|rx|tx] Dot1x Configuration [<port_list>]...
  • Page 163 RGS-9244GP Series User Manual Groups [<vid>] Status [<vid>] Configuration [<port_list>] Action [<port_list>] [permit|deny] [<rate_limiter>] [<port_copy>] [<logging>] [<shutdown>] Policy [<port_list>] [<policy>] Rate [<rate_limiter_list>] [<packet_rate>] Add [<ace_id>] [<ace_id_next>] [switch | (port <port>) | (policy <policy>)] [<vid>] [<tag_prio>] [<dmac_type>] [(etype [<etype>] [<smac>] [<dmac>]) | (arp [<sip>] [<dip>] [<smac>] [<arp_opcode>] [<arp_flags>]) |...
  • Page 164 RGS-9244GP Series User Manual Firmware Load <ip_addr_string> <file_name> > SNMP Trap Inform Retry Times [<retries>] Trap Probe Security Engine ID [enable|disable] Trap Security Engine ID [<engineid>] Trap Security Name [<security_name>] Engine ID [<engineid>] Community Add <community> [<ip_addr>] [<ip_mask>] Community Delete <index>...
  • Page 165 RGS-9244GP Series User Manual Configuration [<clockinst>] PortState <clockinst> [<port_list>] [enable|disable|internal] ClockCreate <clockinst> [<devtype>] [<twostep>] [<protocol>] [<oneway>] [<clockid>] [<tag_enable>] [<vid>] [<prio>] ClockDelete <clockinst> [<devtype>] DefaultDS <clockinst> [<priority1>] [<priority2>] [<domain>] CurrentDS <clockinst> ParentDS <clockinst> Timingproperties <clockinst> [<utcoffset>] [<valid>] [<leap59>] [<leap61>] [<timetrac>] [<freqtrac>] [<ptptimescale>] [<timesource>] PTP PortDataSet <clockinst>...
  • Page 166 RGS-9244GP Series User Manual Port Configuration [<port_list>] Port Mode [<port_list>] [enable|disable] Port Action [<port_list>] [shutdown|shut_log|log] Port Transmit [<port_list>] [enable|disable] Status [<port_list>] IPMC Configuration [igmp] Mode [igmp] [enable|disable] Flooding [igmp] [enable|disable] VLAN Add [igmp] <vid> VLAN Delete [igmp] <vid> State [igmp] [<vid>] [enable|disable] IPMC>...
  • Page 167 RGS-9244GP Series User Manual SMTP Port [<port_list>] [disable|linkup|linkdown|both] DHCPServer Mode [enable|disable] DHCPServer> Setup [<ip_start>] [<ip_end>] [<ip_mask>] [<ip_router>] [<ip_dns>] [<ip_tftp>] [<lease>] [<bootfile>] Ring Mode [enable|disable] Master [enable|disable] 1stRingPort [<port>] 2ndRingPort [<port>] Ring> Couple Mode [enable|disable] Couple Port [<port>] Dualhoming Mode [enable|disable] Dualhoming Port [<port>]...
  • Page 168 RGS-9244GP Series User Manual syslog [enable|disable] temp [<temperature>] SFP> Info DeviceBinding Mode [enable|disable] Port Mode [<port_list>] [disable|scan|binding|shutdown] Port DDOS Mode [<port_list>] [enable|disable] Port DDOS Sensibility [<port_list>] [low|normal|medium|high] Port DDOS Packet [<port_list>] [rx_total|rx_unicast|rx_multicast|rx_broadcast|tcp|udp] Port DDOS Low [<port_list>] [<socket_number>] Port DDOS High [<port_list>] [<socket_number>] Port DDOS Filter [<port_list>] [source|destination]...
  • Page 169 RGS-9244GP Series User Manual Manager [enable|disable] React [enable|disable] 1stRingPort [<mrp_port>] 2ndRingPort [<mrp_port>] Parameter MRP_TOPchgT [<value>] Parameter MRP_TOPNRmax [<value>] Parameter MRP_TSTshortT [<value>] Parameter MRP_TSTdefaultT [<value>] Parameter MRP_TSTNRmax [<value>] Parameter MRP_LNKdownT [<value>] Parameter MRP_LNKupT [<value>] Parameter MRP_LNKNRmax [<value>] Modbus Status Modbus> Mode [enable|disable]...
  • Page 170 RGS-9244GP Series User Manual echnical Specifications ORing Switch Model RGS-9244GP RGS-9244GP-E Physical Ports 10/100/1000Base-T(X) with RJ45 Auto MDI/MDIX 100/1000Base-X with SFP port Technology IEEE 802.3 for 10Base-T IEEE 802.3u for 100Base-TX IEEE 802.3ab for 1000Base-T IEEE 802.3z for 1000Base-X IEEE 802.3x for Flow control IEEE 802.3ad for LACP (Link Aggregation Control Protocol )
  • Page 171 RGS-9244GP Series User Manual DNS client proxy SMTP Client O-Ring Open-Ring O-Chain Network Redundancy MSTP (RSTP/STP compatible) Fast Recovery RS-232 Serial Console Port RS-232 in DB-9 connector with console cable. 115200bps, 8, N, 1 LED indicators Power Indicator (PWR) Green : Power indicator Green LED x 3 : Power-1/2/3 indicator Ring Master Indicator (R.M.)

Table of Contents
