Matrix R7XI-01 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
r 7 x i - 0 1 B i K E
S E r V i C E M A N U A l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R7XI-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Matrix R7XI-01

Summary of Contents for Matrix R7XI-01

  • Page 1 r 7 x i - 0 1 B i K E S E r V i C E M A N U A l...

  • Page 2: Table Of Contents

    Service Mode - Virtual Active ..................51 7.13 Service Mode - Management ..................51 7.14 Service Mode - Service ....................52 7.15 Service Mode - Errors ....................52 7.16 Service Mode - Netpulse .................... 53 7.17 Matrix fitness 7xi series feature access codes ............54...
  • Page 3 9.22 Crank Axle Set Replacement ..................98 9.23 Testing the Bike ....................... 99 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.1 R7xi-01 Bike Specifications ..................100 10.2 Fasteners and Assembly Tools ................... 101 10.3 Assembly Instructions ....................102 10.4 Adjusting the Pedal Straps and Seat ................106 10.5...

  • Page 4: Chapter 1: Serial Number Location

    CHAPTEr 1: SEriAl NUMBEr loCATioN 1.1 SEriAl NUMBEr loCATioN A serial number plate is located below the bottom of the console mast beneath a rubber boot. There is also a serial number tag on the middle of the main frame pointed towards the floor.
  • Page 5 CHAPTEr 1: SEriAl NUMBEr loCATioN 1.1 SEriAl NUMBEr loCATioN - CoNTiNUED console serial number location CoNSolE SEriAl NUMBEr loCATioN...

  • Page 6: Chapter 2: Important Safety Instructions

    To ensure proper use of the Matrix R7xi Bike, make sure that all users read this manual. Remind the users that before undertaking CAUTioN! any changes or modifications to this equipment any fitness program, they should obtain complete physical could void the product warranty.

  • Page 7: Electrical Requirements

    110 V UNiTS All Matrix 3x, 5x, 7xe and 7xi 110 V bikes require the use of a 100-125 V, 60 Hz and a 15 A “Dedicated Circuit”, with a non-looped (isolated) neutral/ground for power. This outlet should be a NEMA 5-15R and have the same configuration as the plug.

  • Page 8: Chapter 3: Preventative Maintenance

    3.2 CHECK for DAMAgED PArTS Do NoT use any equipment that is damaged or has worn or broken parts. Use only replacement parts supplied by Matrix Fitness Systems. MAiNTAiN lABElS AND NAMEPlATES. Do not remove labels for any reason. They contain important information. If unreadable or missing, contact Matrix Fitness Systems for a replacement.

  • Page 9: Care And Maintenance Instructions

    3.3 CArE AND MAiNTENANCE iNSTrUCTioNS In order to maximize life span, and minimize down time, all MATRIX equipment requires regular cleaning, and maintenance items performed on a scheduled basis. This section contains detailed instructions on how to perform these items and the frequency of which they should be done.

  • Page 10: Touch Screen Care & Cleaning

    CHAPTEr 3: PrEVENTATiVE MAiNTENANCE 3.4 ToUCH SCrEEN CArE & ClEANiNg ToUCH SCrEEN CArE AND ClEANiNg * The touch screen requires very little maintenance. We recommend that you periodically clean the touch screen surface with a clean dry 100% lint free cloth and water / soap mixture or a computer or LCD / LED screen cleaner. * It is very important to avoid using any other chemical on the touch screen.

  • Page 11: Chapter 4: Console Overlay And Workout Description

    CHAPTEr 4: CoNSolE oVErlAy AND WorKoUT DESCriPTioN 4.1 CoNSolE DESCriPTioN The R7xi has a fully integrated touch screen display. All information required for workouts is explained on screen. Exploration of the interface is highly encouraged. The information explaining how to program for various workouts will give an explanation about the contents of each screen. Go: One touch Start.

  • Page 12: Workout Setup Steps

    Heart rate - The Matrix R7xi bike comes with standard digital contact heart rate sensors and are POLAR telemetry compatible. The heart rate control workout mode allows the user to program their desired heart rate zone, and the bike will automatically adjust the level based upon the user's heart rate.

  • Page 13: Chapter 5: Manager Mode

    CHAPTEr 5: MANAgEr MoDE 5.1 USiNg MANAgEr MoDE 1) To enter Manager Mode, press "ENTER, 1, 0, 0, 1, ENTER" on the number keypad and Manager Mode will appear on the display. 2) Manager Mode is divided into 9 tabs, located on the left side of the screen. They are General, Workout, Setup Defaults, Asset Management, Weather, TV, Applications, Hardware and Service.

  • Page 14: Manager Mode - General

    CHAPTEr 5: MANAgEr MoDE 5.2 MANAgEr MoDE – gENErAl – TAB 1 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED General Accumulated Time Total time on the unit since production. Cannot be modified. Accumulated Distance Total distance on the unit since production. Cannot be modified.
  • Page 15 CHAPTEr 6: MANAgEr MoDE 5.2 MANAgEr MoDE - gENErAl – TAB 2 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED General Date & Time This option sets the current date and time of the machine. 5.2 MANAgEr MoDE - gENErAl – TAB 3 MANAgEr MoDE fUNCTioN &...
  • Page 16 CHAPTEr 5: MANAgEr MoDE 5.2 MANAgEr MoDE – gENErAl – TAB 4 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED General Language Setup Sets the language used on the console. English (US), English (UK), German, French, Italian, Spanish, Dutch, Portuguese, Korean, Israeli, Swiss, Russian, Finnish, Taiwanese, Chinese, or Japanese.

  • Page 17: Manager Mode - Workout

    CHAPTEr 5: MANAgEr MoDE 5.3 MANAgEr MoDE - WorKoUT – TAB 1 fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED MANAgEr MoDE Workout Maximum Workout Time This option allows the club to set the Maximum: 120 Minutes maximum workout duration limits during Minimum: 10 Minutes peak and non peak hours.
  • Page 18 CHAPTEr 5: MANAgEr MoDE 5.3 MANAgEr MoDE - WorKoUT – TAB 2 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Workout Max Cooldown Time This option allows the club to set the Maximum: 10 Minutes maximum cool down duration limits during Minimum: 5 Minutes peak and non peak hours.

  • Page 19: Manager Mode - Setup Defaults

    CHAPTEr 5: MANAgEr MoDE 5.4 MANAgEr MoDE - SETUP DEfAUlTS – TAB 1 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Level This option controls the default program Maximum: 20 Setup Defaults levels. Minimum: 1 This option controls the default user's age Maximum: 99 used in the target heart rate calculations.
  • Page 20 CHAPTEr 5: MANAgEr MoDE 5.4 MANAgEr MoDE - SETUP DEfAUlTS – TAB 2 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Default Workout Distance This option controls the default program Maximum: 12.4 Setup Defaults Distance. Minimum: 0.1 Default Web Brower Page This option controls the default machine Web Brower Page.

  • Page 21: Manager Mode - Asset Management

    CHAPTEr 5: MANAgEr MoDE 5.5 MANAgEr MoDE - ASSET MANAgEMENT MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Club ID This option records the club ID of the Asset Management fitness facility. Show Custom Logo This option allows the user to select the True or False screen Logo from True 5.6 MANAgEr MoDE - WEATHEr...

  • Page 22: Manager Mode Tv

    CHAPTEr 5: MANAgEr MoDE 5.7 MANAgEr MoDE - TV – TAB 1 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED TV Channel Setup This option is for setting the TV tuner functions. Press the "Start Scan" to search the TV Channel. 5.7 MANAgEr MoDE - TV –...

  • Page 23: Manager Mode - Applications

    CHAPTEr 5: MANAgEr MoDE 5.7 MANAgEr MoDE - TV – TAB 3 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Channel Button Setup This option is for setting the TV channel button. Press the "Add" to edit the channel icon, channel name and channel. 5.8 MANAgEr MoDE - APPliCATioNS fUNCTioN &...

  • Page 24: Manager Mode - Hardware

    CHAPTEr 5: MANAgEr MoDE 5.9 MANAgEr MoDE - HArDWArE MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Hardware This option controls the ErP function is Disabled or Enabled Disabled or Enabled. ErP Timeout Amount of time before the console will Maximum: 60 enter ErP mode if user does not touch the Minimum: 1 screen or press any key.

  • Page 25: Manager Mode - Service

    CHAPTEr 5: MANAgEr MoDE 5.10 MANAgEr MoDE - SErViCE MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Service History This option allows the club to record key Service components replacement history.

  • Page 26: Chapter 6: Engineering Mode

    CHAPTEr 6: ENgiNEEriNg MoDE 6.1 USiNg ENgiNEEriNg MoDE 1) To enter Engineering Mode, press "ENTER, 2, 0, 0, 1, ENTER" on the number keypad and Engineering Mode will appear on the display. 2) Engineering Mode is divided into 12 tabs, located on the left side of the screen. They are General, Workout, Setup Defaults, Network, Asset Management, Weather, TV, Applications, Calibration, Hardware, Service, Errors.

  • Page 27: Engineering Mode - General

    CHAPTEr 6: ENgiNEEriNg MoDE 6.2 ENgiNEEriNg MoDE - gENErAl – TAB 1 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED General Accumulated Time Total time on the unit since production. Cannot be modified. Accumulated Distance Total distance on the unit since production. Cannot be modified.
  • Page 28 CHAPTEr 6: ENgiNEEriNg MoDE 6.2 ENgiNEEriNg MoDE - gENErAl – TAB 2 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED General Date & Time This option sets the current date and time of the machine. 6.2 ENgiNEEriNg MoDE - gENErAl – TAB 3 MANAgEr MoDE fUNCTioN &...
  • Page 29 CHAPTEr 6: ENgiNEEriNg MoDE 6.2 ENgiNEEriNg MoDE - gENErAl – TAB 4 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED General Language Setup Sets the language used on the console. English (US), English (UK), German, French, Italian, Spanish, Dutch, Portuguese, Korean, Israeli, Swiss, Russian, Finnish, Taiwanese, Chinese, or Japanese.

  • Page 30: Engineering Mode - Workout

    CHAPTEr 6: ENgiNEEriNg MoDE 6.3 ENgiNEEriNg MoDE - WorKoUT – TAB 1 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Maximum Workout Time This option allows the club to set the Maximum: 120 Minutes Workout maximum workout duration limits during Minimum: 10 Minutes peak and non peak hours.
  • Page 31 CHAPTEr 6: ENgiNEEriNg MoDE 6.3 ENgiNEEriNg MoDE - WorKoUT – TAB 2 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Workout Max Cooldown Time This option allows the club to set the Maximum: 10 Minutes maximum cool down duration limits during Minimum: 5 Minutes peak and non peak hours.

  • Page 32: Engineering Mode - Setup Defaults

    CHAPTEr 6: ENgiNEEriNg MoDE 6.4 ENgiNEEriNg MoDE - SETUP DEfAUlTS – TAB 1 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Setup Defaults Level This option allows the club to set the Maximum: 20 maximum workout duration limits during Minimum: 1 peak and non peak hours.

  • Page 33: Engineering Mode - Network

    CHAPTEr 6: ENgiNEEriNg MoDE 6.4 ENgiNEEriNg MoDE - SETUP DEfAUlTS – TAB 2 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Setup Defaults Default Workout Distance This option controls the default program Maximum: 12.4 Distance. Minimum: 0.1 Default Web Brower Page This option controls the default machine Web Brower Page.

  • Page 34: Engineering Mode - Asset Management

    CHAPTEr 6: ENgiNEEriNg MoDE 6.5 ENgiNEEriNg MoDE - NETWorK – TAB 2 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Network Wireless Network Setup Wifi setting 6.6 ENgiNEEriNg MoDE - ASSET MANAgEMENT MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Asset Management Club ID This option records the club ID of the fitness facility.

  • Page 35: Engineering Mode - Weather

    CHAPTEr 6: ENgiNEEriNg MoDE 6.7 ENgiNEEriNg MoDE - WEATHEr MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Weather Default City This option controls the default City Weather . Enable Alerts This option controls the City Weather function True or False. True or False Weather Temperature Unit This option controls how temperature is displayed.
  • Page 36 CHAPTEr 5: ENgiNEEriNg MoDE 6.8 ENgiNEEriNg MoDE - TV – TAB 2 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Default TV Channel This option controls the default TV channel Maximum: 1000 on start up. Minimum: 2 6.8 ENgiNEEriNg MoDE - TV – TAB 3 fUNCTioN &...

  • Page 37: Engineering Mode - Applications

    CHAPTEr 6: ENgiNEEriNg MoDE 6.9 ENgiNEEriNg MoDE - APPliCATioNS MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Applications Application Setup This option is for setting the screen table functions.

  • Page 38: Engineering Mode - Hardware

    CHAPTEr 6: ENgiNEEriNg MoDE 6.10 ENgiNEEriNg MoDE - HArDWArE MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Hardware This option controls the ErP function is Disabled or Enabled Disabled or Enabled. ErP Timeout Console will enter ErP mode if user does Maximum: 60 not touch the screen or press any key pad Minimum: 1...

  • Page 39: Engineering Mode - Service

    CHAPTEr 6: ENgiNEEriNg MoDE 6.11 ENgiNEEriNg MoDE - SErViCE MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Service History This option allows the club to record key Service components replacement history. 6.12 ENgiNEEriNg MoDE - ErrorS MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Errors...

  • Page 40: Chapter 7: Service Mode

    CHAPTEr 7: SErViCE MoDE 7.1 USiNg SErViCE MoDE 1) To enter Service Mode, press "ENTER 3, 0, 0, 1, ENTER" on the number keypad and Service Mode will appear on the display. 2) Service Mode is divided into 15 tabs, located on the left side of the screen. They are General, Workout, Setup Defaults, Update, Network, Asset Management, Weather, TV, Applications, Calibration, Hardware, Virtual Active, Management, Service, Errors.

  • Page 41: Service Mode - General

    CHAPTEr 7: SErViCE MoDE 7.2 SErViCE MoDE - gENErAl - TAB 1 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED General Accumulated Time Total time on the unit since production. Cannot be modified. Accumulated Distance Total distance on the unit since production. Cannot be modified.
  • Page 42 CHAPTEr 7: SErViCE MoDE 7.2 SErViCE MoDE - gENErAl – TAB 2 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED General Date & Time This option sets the current date and time of the machine. 7.2 SErViCE MoDE - gENErAl – TAB 3 MANAgEr MoDE fUNCTioN &...
  • Page 43 CHAPTEr 7: SErViCE MoDE 7.2 SErViCE MoDE - gENErAl - TAB 4 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED General Language Setup Sets the language used on the console. English (US), English (UK), German, French, Italian, Spanish, Dutch, Portuguese, Korean, Israeli, Swiss, Russian, Finnish, Taiwanese, Chinese, or Japanese.

  • Page 44: Service Mode - Workout

    CHAPTEr 7: SErViCE MoDE 7.3 SErViCE MoDE - WorKoUT – TAB 1 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Workout Maximum Workout Time This option allows the club to set the Maximum: 120 Minutes maximum workout duration limits during Minimum: 10 Minutes peak and non peak hours.
  • Page 45 CHAPTEr 7: SErViCE MoDE 7.3 SErViCE MoDE - WorKoUT – TAB 2 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Workout Max Cooldown Time This option allows the club to set the Maximum: 10 Minutes maximum cool down duration limits during Min: 5 Minutes peak and non peak hours.

  • Page 46: Service Mode - Setup Defaults

    CHAPTEr 7: SErViCE MoDE 7.4 SErViCE MoDE - SETUP DEfAUlTS – TAB 1 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Level This option controls the default program Maximum: 20 Setup Defaults levels. Minimum: 1 This option controls the default user's age Maximum: 99 used in the target heart rate calculations.

  • Page 47: Service Mode - Update

    CHAPTEr 7: SErViCE MoDE 7.4 SErViCE MoDE - SETUP DEfAUlTS – TAB 2 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Setup Defaults Default Workout Distance This option controls the default program Maximum: 12.4 Distance Minimum: 0.1 Default Web Brower Page This option controls the default machine Web Brower Page Show Sliders In Workout...

  • Page 48: Service Mode - Network

    CHAPTEr 7: SErViCE MoDE 7.6 SErViCE MoDE - NETWorK – TAB 1 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Network Wireless Network Setup Wifi setting 7.6 SErViCE MoDE - NETWorK – TAB 2 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Network Wireless Network Setup Wifi setting...

  • Page 49: Service Mode - Asset Management

    CHAPTEr 7: SErViCE MoDE 7.7 SErViCE MoDE - ASSET MANAgEMENT MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Asset Management Club ID This option records the club ID of the fitness facility. Show Custom Logo This option allows the user to select the True or False screen Logo from True 7.8 SErViCE MoDE - WEATHEr...

  • Page 50: Service Mode - Tv

    CHAPTEr 7: SErViCE MoDE 7.9 SErViCE MoDE - TV – TAB 1 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED TV Channel Setup This option is for setting the TV tuner functions. Press the "Start Scan" to search the TV Channel. 7.9 SErViCE MoDE - TV –...

  • Page 51: Service Mode - Applications

    CHAPTEr 7: SErViCE MoDE 7.9 SErViCE MoDE - TV – TAB 3 fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED MANAgEr MoDE Channel Button Setup This option is for setting the TV channel button. Press the "Add" to edit the channel icon, channel name and channel. 7.10 SErViCE MoDE - APPliCATioNS MANAgEr MoDE fUNCTioN &...

  • Page 52: Service Mode - Hardware

    CHAPTEr 7: SErViCE MoDE 7.11 SErViCE MoDE - HArDWArE – TAB 1 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Hardware This option controls the ErP function is Disabled or Enabled Disabled or Enabled. ErP Timeout Amount of time before the screen goes Maximum: 60 into ERP mode if the user does not touch Minimum: 1...
  • Page 53 CHAPTEr 7: SErViCE MoDE 7.11 SErViCE MoDE - HArDWArE – TAB 2 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Hardware Play Workout Countdown Sound This option can set the play workout True or False countdown to sound or not sound. Volume Basic This option controls the default volume on Maximum: 30...

  • Page 54: Service Mode - Virtual Active

    CHAPTEr 7: SErViCE MoDE 7.12 SErViCE MoDE - VirTUAl ACTiVE MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Virtual Active Root Path This Virtual Active root path setting 7.13 SErViCE MoDE - MANAgEMENT MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Management Setting Manager Setting Manager date...

  • Page 55: Service Mode - Service

    CHAPTEr 7: SErViCE MoDE 7.14 SErViCE MoDE - SErViCE MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Service History This option allows the club to record key Service components replacement history. 7.15 SErViCE MoDE - ErrorS MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Errors...

  • Page 56: Service Mode - Netpulse

    CHAPTEr 7: SErViCE MoDE 7.16 SErViCE MoDE - NETPUlSE MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Netpulse Test network and netpulse install.

  • Page 57: Matrix Fitness 7Xi Series Feature Access Codes

    CHAPTEr 7: SErViCE MoDE 7.17 MATrix fiTNESS 7xi SEriES fEATUrE ACCESS CoDES This document defines the supported feature access codes for the Matrix Fitness 7xi series fitness equipment. Instruction All codes are entered in by: Press the “Enter” key. Press the series of numbers in the code.

  • Page 58: Chapter 8: Troubleshooting

    CHAPTEr 8: TroUBlESHooTiNg 8.1 ElECTriCAl DiAgrAMS...
  • Page 59 CHAPTEr 8: TroUBlESHooTiNg 8.1 ElECTriCAl DiAgrAMS - CoNTiNUED...
  • Page 60 CHAPTEr 8: TroUBlESHooTiNg 8.1 ElECTriCAl DiAgrAMS - CoNTiNUED PUlSE SENSor WirE PoWEr rESiSTANCE WirE...
  • Page 61 CHAPTEr 8: TroUBlESHooTiNg 8.1 ElECTriCAl DiAgrAMS - CoNTiNUED DigiTAl CoMMUNiCATioN WirE CHAPTEr 8: TroUBlESHooTiNg 8.1 ElECTriCAl DiAgrAMS - CoNTiNUED ECB WirE...

  • Page 62: Lcb Led Indicators

    CHAPTEr 8: TroUBlESHooTiNg 8.2 lCB lED iNDiCATorS ====================== firMWArE DEfiNiTioN ======================== lED6: lCB STATUS (BliNKiNg: oK) lED7: rESiSTANCE rEgUlATE STATUS (BrigHT : NorMAl ) lED8: UCB/lCB CoMMUNiCATioN STATUS (BliNKiNg : oK ) ====================== HArDWArE DEfiNiTioN ======================= lED1: AC PlUg-iN STATUS (BrigHT : AC ) lED2: DC 5V STATUS (BrigHT : oK) lED3: AC PlUg-iN STATUS (BrigHT : AC ) lED4: DC 12V STATUS (BrigHT : oK )

  • Page 63: Lcb Wiring Connections

    CHAPTEr 8: TroUBlESHooTiNg 8.3 lCB WiriNg CoNNECTioNS...

  • Page 64: Troubleshooting - Error 04A0

    CHAPTEr 8: TroUBlESHooTiNg 8.4 TroUBlESHooTiNg - Error 04A0 Error CoDE 04A0 1) SyMPToM: 04A0 – UCB communication disconnected. 2) SolUTioN: 1) Check the connection of the console cable at the UCB and LCB. Also check the console cable for damage, replace as needed. 2) If the console cable connections are good, the issue is likely with the UCB.

  • Page 65: Troubleshooting - Error 04B0

    CHAPTEr 8: TroUBlESHooTiNg 8.5 TroUBlESHooTiNg - Error 04B0 Error CoDE 04B0 1) SyMPToM: 04B0 – LCB communication disconnected. 2) SolUTioN: 11) Check the connection of the console cable at the UCB and LCB. Also check the console cable for damage, replace as needed. 2) If the console cable connections are good, the issue is likely with the LCB.

  • Page 66: Troubleshooting - Error 0248

    CHAPTEr 8: TroUBlESHooTiNg 8.6 TroUBlESHooTiNg - Error 0248 Error CoDE 0248 1) SyMPToM: 0248 –Battery disconnection or fail. (When power is on, LCB battery voltage is less than 6 VAC). 2) SolUTioN: 1) Check the battery wire connection between the battery and LCB (Figure A). 2) Check the battery voltage (Figure B), if it is less than 6 VAC, replace the battery.

  • Page 67: Troubleshooting - Error 02B4

    CHAPTEr 8: TroUBlESHooTiNg 8.7 TroUBlESHooTiNg - Error 02B4 Error CoDE 02B4 1) SyMPToM: 02B4 – Resistance type error. 2) SolUTioN: 1) Check if the machine has the correct resistance system (resistor or ECB) (Figures A & B). 2) Check if the console is matched with the correct frame, and that the Machine Type is set correctly in Engineering Mode. 3) Replace the LCB.

  • Page 68: Troubleshooting - Error 02Ab

    CHAPTEr 8: TroUBlESHooTiNg 8.8 TroUBlESHooTiNg - Error 02AB Error CoDE 02AB 1) SyMPToM: 02AB –Machine type error. 2) SolUTioN: 1) Enter into Manager Mode and verify that the Machine Type setting is correct (Figure A). - If not correct, press ENTER, 3, 0, 0, 2, ENTER on the lower keypad and select the correct Machine Type (Figure B). figUrE A figUrE B...

  • Page 69: Troubleshooting - Error 01Ac

    CHAPTEr 8: TroUBlESHooTiNg 8.9 TroUBlESHooTiNg - Error 01AC Error CoDE 01AC 1) SyMPToM: 01AC - Resistance over current 2) SolUTioN: 1) Check the resistance coming out of the resistor (Figure A). - If the resistance value is under 8 ohms, replace the power resistance. - If the resistance value is over 8 ohms, replace the LCB.

  • Page 70: Troubleshooting - No Resistance Issues

    CHAPTEr 8: TroUBlESHooTiNg 8.10 TroUBlESHooTiNg - No rESiSTANCE iSSUES No rESiSTANCE TroUBlESHooTiNg 1) SyMPToM: No resistance 2) SolUTioN: 1) Check the power resistor wire connection between the power resistor and the LCB (Figure A). 2) Check if there is a resistance value by measuring amperage through the generator cable (Figure A). - If there is not a resistance value, replace the resistor.

  • Page 71: Troubleshooting - Heart Rate Issues

    An ohm reading of less than 1 should be received. If it is higher, replace the HR grip wiring. 3) Perform a continuity check on the console (See Service Bulletin - Continuity Test on Matrix Bikes). a. Once the console continuity is confirmed, perform a continuity check on the HR board ground wire. With a multi meter set for ohms, place one prong on the HR board ground wire (Figure D), and the other on the console ground wire.

  • Page 72: Tv Troubleshooting - Seat Adjustment Issues

    CHAPTEr 8: TroUBlESHooTiNg 8.12 TroUBlESHooTiNg - SEAT ADjUSTMENT iSSUES SEAT WoBBly or looSE 1) See if the seat rollers are loose or mis-positioned. To adjust the roller to tighten the seat: a. Loosen the nylok nuts putting tension on the roller brackets (Figure A). b.

  • Page 73: Tv Troubleshooting - Overview

    Fitness equipment. The Matrix Bike includes an integrated TV that shows in the large display window. The TV is capable of being shown as a 9" or 15" screen (Figures A & B). The console should be equipped with an entertainment keypad similar to Figure C.

  • Page 74: Tv Troubleshooting - Picture Fuzzy Or Unclear

    CHAPTEr 8: TroUBlESHooTiNg 8.14 TV TroUBlESHooTiNg - PiCTUrE fUZZy or UNClEAr 1) For a fuzzy or unclear picture, see the TV programming instructions in Section 10. If the TV is still fuzzy or unclear after programming: a) Check the coax connection at the entertainment port (Figure A). b) Remove the 5 screws holding the console to the console mast and check the coax connection at the console (Figure B).

  • Page 75: Tv Troubleshooting - Tv Will Not Turn On

    CHAPTEr 8: TroUBlESHooTiNg 8.15 TV TroUBlESHooTiNg - TV Will NoT TUrN oN 1) Remove the console back and check the electrical connections for the TV (Figures A & B). figUrE A figUrE B 2) If internal electrical connections are good (the console turns on), and the outlet is outputting 120V, the issue is likely with the integrated TV. Replace the console.

  • Page 76: Tv Troubleshooting - Entertainment Keypad Issues

    CHAPTEr 8: TroUBlESHooTiNg 8.16 TV TroUBlESHooTiNg - ENTErTAiNMENT KEyPAD iSSUES ENTErTAiNMENT KEyPAD iS NoT WorKiNg 1) SyMPToM: a. The entertainment keypad (Figure A) is not responding. 2) SolUTioN: a. Remove the console and check the connection of the entertainment keypad (Figure B). b.

  • Page 77: Chapter 9: Part Replacement Guide

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.1 CoNSolE rEPlACEMENT 1) Remove the 4 screws holding the console to the frame (Figure A). figUrE A figUrE B...

  • Page 78: Handlebar Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.2 HANDlEBAr rEPlACEMENT 1) Remove the 2 screws holding on the handlebar cover (Figures A & B). figUrE A figUrE B 2) Remove the 4 screws holding the heart rate handlebar to the console mast being careful to support the handlebar (Figure C). 3) Remove the defective handlebar (Figure D).

  • Page 79: Cup Holder Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.3 CUP HolDEr rEPlACEMENT 1) Remove the 2 screws holding the cup holder to the frame (Figure A). figUrE A 2) Remove the cup holder (Figure B). figUrE B 3) Reverse Steps 1-2 to install a new cup holder.

  • Page 80: Keypad / Overlay Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.4 KEyPAD / oVErlAy rEPlACEMENT note: The instructions below are for console overlays / keypads replacement, but the procedure is the same regardless of where the overlay / keypad is. 1) Remove the console as outlined in Section 9.1. 2) Remove the back cover of the console (Figure A).
  • Page 81 CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.4 KEyPAD / oVErlAy rEPlACEMENT - CoNTiNUED 6) Push the overlay / keypad ribbon cable through the hole in the console and plug it in (Figure E). 7) Match the overlay / keypad to the cutout in the console (Figure F). figUrE E figUrE f 8) Press down on the corners of the overlay / keypad to keep it in place.

  • Page 82: Console Mast Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.5 CoNSolE MAST rEPlACEMENT 1) Remove the console as outlined in Section 9.1. 2) Remove the handlebars as outlined in Section 9.2. 3) Lift up the rubber boot at the bottom of the console mast (Figure A). figUrE A 4) With the rubber boot lifted, remove the 4 screws holding the console mast to the frame (Figure B).

  • Page 83: Seat Pad Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.6 SEAT PAD rEPlACEMENT 1) Remove the 4 screws holding the seat pad to the seat frame (Figure A). figUrE A 2) Lift the seat pad away from the seat frame (Figure B). figUrE B 3) Reverse Steps 1-2 to install a new seat pad.

  • Page 84: Back Pad Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.7 BACK PAD rEPlACEMENT 1) Remove the 8 screws holding the plastic cover onto the back of the seat pad and remove it (Figure A). 2) Remove the 4 screws holding the back pad onto the seat frame (Figure B). figUrE B figUrE A 3) Remove the back pad (Figure C).

  • Page 85: Handlebar Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.8 HEArT rATE HANDlEBAr rEPlACEMENT 1) Remove the seat pad as outlined in Section 9.6. 2) Remove the back pad as outlined in Section 9.7. 3) Disconnect the heart rate wiring exposed when the seat pad is removed (Figure A). 4) Remove the 3 screws holding the heart rate handlebars to the seat frame (Figure B).

  • Page 86: Grips Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.9 HEArT rATE griPS rEPlACEMENT 1) Remove the 3 screws holding the HR grip together (Figure A). 2) Once the 3 screws are removed, the HR grip can be split into 2 pieces (Figure B). figUrE A figUrE B 3) Disconnect the keypad / overlay and the HR plate wiring and remove the old HR grip (Figure C).

  • Page 87: Upper Seat Frame Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.10 UPPEr SEAT frAME rEPlACEMENT 1) Remove the seat pad as outlined in Section 9.6. 2) Remove the back pad as outlined in Section 9.7. 3) Disconnect and remove the HR handlebar as outlined in Section 9.8. 4) Remove the 4 screws holding the upper seat frame to the lower seat frame (Figure A).

  • Page 88: Lower Seat Frame Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.11 loWEr SEAT frAME rEPlACEMENT 1) Remove the seat pad as outlined in Section 9.6. 2) Remove the back pad as outlined in Section 9.7. 3) Remove the 2 screws holding the seat position plate onto the seat frame and remove the seat position plate (Figures A & B). figUrE A figUrE B 4) Disconnect the HR wiring that is exposed when the seat pad is removed and slide it out the hole in the frame so it does not restrict the seat...
  • Page 89 CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.11 loWEr SEAT frAME rEPlACEMENT - CoNTiNUED 6) Remove the screw holding the rear seat roller to the seat track and remove the roller (Figure G). 7) Remove the 2 screws holding the rear end cap onto the seat track (Figure H). figUrE g figUrE H 8) Remove the end cap (Figure I).

  • Page 90: Seat Adjustment Handle Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.12 SEAT ADjUSTMENT HANDlE rEPlACEMENT 1) Remove the 2 screws holding the seat adjustment handle to the seat frame (Figure A). figUrE A 2) Remove the seat adjustment handle (Figure B). figUrE B 3) Reverse Steps 1-2 to install a new seat adjustment handle. 4) Test the bike for function as outlined in Section 9.23.

  • Page 91: Rear Shrouds Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.13 rEAr SHroUD rEPlACEMENT 1) Remove the 8 screws holding the right side shroud to the frame and left shroud and remove it (Figure A). 2) Remove the 6 screws holding the left side shroud to the frame and remove it (Figure B). figUrE B figUrE A 3) Figure C shows the bike with both rear shrouds removed.

  • Page 92: Pedal Replacement

    9.14 PEDAl rEPlACEMENT 1) Use a 15 mm wrench commercial pedal wrench (available from Matrix - part # ZMS4001254) to remove the pedal from the crank (Figure A). note: For the right side pedal, the threads are normal. For the left side pedal, the threads are reversed (the pedal turns off counterclockwise).

  • Page 93: Front Shroud Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.15 froNT SHroUD rEPlACEMENT 1) Remove the pedals as outlined in Section 9.14. 2) Remove the 9 screws holding the right side front shroud to the frame and the left shroud and remove it (Figure A). note: You will need to angle the shrouds so that the crank passes through the hole in the shroud.

  • Page 94: Lower Control Board Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.16 loWEr CoNTrol BoArD rEPlACEMENT 1) Remove the rear shrouds as outlined in Section 9.13. 2) Disconnect the 5 wire connections to the lower board (Figure A). 3) Remove the 2 screws holding the lower board to the frame (Figure B), and remove the lower board. figUrE A figUrE B 4) Reverse Steps 1-3 to install a new lower board.

  • Page 95: Battery Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.17 BATTEry rEPlACEMENT 1) Remove the left side rear shroud as outlined in Section 9.11. 2) Disconnect the 2 wires from the battery (Figure A). figUrE A 3) Remove the wing nut on the battery bracket (Figure B). 4) Swivel the battery bracket out of the way and remove the battery (Figure C).

  • Page 96: Drive Belt Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.18 DriVE BElT rEPlACEMENT 1) Remove the right side front shroud as outlined in Section 9.15. 2) Remove the screw that applies tension to the belt (Figure A). 3) Rotate the tension assembly to remove the tension from the belt (Figure B). figUrE A figUrE B 4) Remove the belt (Figure C).

  • Page 97: Generator Belt Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.19 gENErATor BElT rEPlACEMENT 1) Remove the front shrouds as outlined in Section 9.15. 2) Loosen the nuts holding the generator to the frame (Figure A), and remove the nuts putting tension on the generator belt (Figure B). figUrE A figUrE B 3) Once the tension has been removed, the generator belt can be walked off of the pulley (Figure C).

  • Page 98: Generator Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.20 gENErATor rEPlACEMENT 1) Remove the front shrouds as outlined in Section 9.15. 2) Remove the nuts holding the generator to the frame (Figure A), and remove the nuts putting tension on the generator belt (Figure B). figUrE A figUrE B 3) Once the tension has been removed, the generator belt can be walked off of the pulley (Figure C).

  • Page 99: Pulley Axle Set Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.21 PUllEy AxlE SET rEPlACEMENT 1) Remove the front shrouds as outlined in Section 9.15. 2) Remove the drive belt as outlined in Section 9.18. 3) Loosen the nuts holding the generator to the frame (Figure A), and remove the nuts putting tension on the generator belt (Figure B). figUrE A figUrE B 4) Once the tension has been removed, walk the generator belt off of the pulley (Figure C).
  • Page 100 CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.21 PUllEy AxlE SET rEPlACEMENT - CoNTiNUED 6) Remove the bearing (Figure E). 7) Remove the large nut holding in the pulley axle assembly with a large channel lock pliers or a pipe wrench (Figure F). figUrE E figUrE f 8) Once the large nut is removed, the pulley axle set can be removed from the left side of the frame (Figure G).

  • Page 101: Crank Axle Set Replacement

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.22 CrANK AxlE SET rEPlACEMENT 1) Remove the front shrouds as outlined in Section 9.15. 2) Remove the drive belt as outlined in Section 9.18 3) Remove the 3 screws holding the crank axle bearings in place on both sides (Figure A). 4) Bend the tabs of the nut on the left side of the frame so that this nut will turn (Figure B).

  • Page 102: Testing The Bike

    CHAPTEr 9: PArT rEPlACEMENT gUiDE 9.23 TESTiNg THE BiKE oNCE THE UNiT or rEPlACEMENT PArT iS fUlly iNSTAllED AND ASSEMBlED AND ProPErly PlACED oN THE floor, USE THE folloWiNg iNSTrUCTioNS To SETUP AND TEST THE MACHiNE: 1) Enter Service Mode (ENTER, 3, 0, 0, 1, ENTER) and input the serial number of the console. Also set the Machine Type (ENTER, 3, 0, 0, 2, ENTER) and verify that the Date and Time are correct (See Section 7.2).

  • Page 103: Chapter 10: Bike Specifications And Assembly Guide

    CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.1 r7xi-01 BiKE SPECifiCATioNS MoDEl NAME R-3x/5x/7x CYCLE TYPE R7xi RECUMBENT FRAME PART # R-3X/5X/7X-03-F CONSOLE PART # HURESAC-7XI-C fEATUrES CONTACT & TELEMETRIC HR SENSORS HANDLEBAR DESIGN SEAT SIDE AND FRONT VERTICAL ERGO BEND...

  • Page 104: Fasteners And Assembly Tools

    CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.2 fASTENErS AND ASSEMBly ToolS qUANTITY PART SKETCH DESCRIPTION NOTES 4 MM ALLEN WRENCH PURPLE 5MM ALLEN WRENCH PURPLE 6 MM ALLEN WRENCH PURPLE OPEN WRENCH (15 & 17 MM) PURPLE #2 PHILLIPS SCREWDRIVER PURPLE BUTTON HEAD SCREW (M8 X 25L) WHITE...

  • Page 105: Assembly Instructions

    CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.3 ASSEMBly iNSTrUCTioNS AfTEr THESE ASSEMBly STEPS ArE CoMPlETE, BE SUrE To SETUP AND TEST THE UNiT AS oUTliNED iN SECTioN 9.23. STEP 1 STEP 2...
  • Page 106 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.3 ASSEMBly iNSTrUCTioNS - CoNTiNUED STEP 3...
  • Page 107 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.3 ASSEMBly iNSTrUCTioNS - CoNTiNUED STEP 4 STEP 5...
  • Page 108 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.3 ASSEMBly iNSTrUCTioNS - CoNTiNUED FINAL ASSEMBLY...

  • Page 109: Adjusting The Pedal Straps And Seat

    Release the clip to lock the strap in place. aDjustinG tHe r7xi seat While seated on the Matrix Recumbent Bike, an optimum position will allow movement through the bottom of the stroke without locking the knees or shifting in the seat.

  • Page 110: Leveling The Bike

    CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.5 lEVEliNg THE BiKE stabiliZinG tHe matriX r7Xi biKe After positioning the bike in its intended location, check its stability by attempting to shake it side to side. Shaking or wobbling indicates that your bike needs to be leveled.

  • Page 111: Tv Programming Instructions

    CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.6 TV ProgrAMMiNg iNSTrUCTioNS (US) Once the cardio equipment has been installed and proper power and cable wiring is provided, The Television must be programmed to the club's channels and settings. auto tuning - An auto scan will search for channel signals from the coax cable.
  • Page 112 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.6 TV ProgrAMMiNg iNSTrUCTioNS (US) - CoNTiNUED auto tuning (continued): 7. The achieved scan will be displayed on the bottom left hand corner of the screen (Figure G). Once the channel scan is complete, the scanned channels will be displayed on the channel list on the screen (Figure H).
  • Page 113 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.6 TV ProgrAMMiNg iNSTrUCTioNS (US) - CoNTiNUED auto tuning (continued): 10. Press Start Scan to begin scanning (Figure M). Scan Started will be displayed on the bottom left hand corner of the screen (Figure N). figUrE M figUrE N 11.
  • Page 114 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.6 TV ProgrAMMiNg iNSTrUCTioNS (iD MArKET) Once the cardio equipment has been installed and proper power and cable wiring is provided, The Television must be programmed to the club's channels and settings. auto tuning - An auto scan will search for channel signals from the coax cable.
  • Page 115 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.6 TV ProgrAMMiNg iNSTrUCTioNS (iD MArKET)- CoNTiNUED auto tuning (continued): 7. Select the Analog source on the screen (Figure G). Select your country location (Figure H). figUrE g figUrE H 8. Select the signal delivery type on the screen (Figure I). Select the tuner type on the screen (Figure J). figUrE i figUrE j 9.
  • Page 116 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.6 TV ProgrAMMiNg iNSTrUCTioNS (iD MArKET) - CoNTiNUED auto tuning (continued): 10. The achieved scan will be displayed on the bottom left hand corner of the screen (Figure M). Once the channel scan is complete, the scanned channels will be displayed on the channel list on the screen (Figure N).

  • Page 117: Using Update Manager

    CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.7 USiNg UPDATE MANAgEr 1) To enter Update Manager Mode, press "ENTER, 3, 0, 0, 4, ENTER" on the number keypad and Update Manager Mode will appear on the display. 2) Choose a correct model type by touching the screen desired tab. . 3) Press the "HOME"...
  • Page 118 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.7 UPDATE MANAgEr - iNSTAllED UPDATES – TAB 1 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Installed Updates Show the all software version of console. 10.7 UPDATE MANAgEr - AVAilABlE UPDATES – TAB 2 MANAgEr MoDE fUNCTioN &...
  • Page 119 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.7 UPDATE MANAgEr - UPDATE HiSTory – TAB 3 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Update History Show the all software update history. 10.7 UPDATE MANAgEr - SETTiNgS – TAB 4 MANAgEr MoDE fUNCTioN &...
  • Page 120 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.7 UPDATE MANAgEr - iNSTAllED UPDATES – TAB 5 MANAgEr MoDE fUNCTioN & DEfAUlTS DESCriPTioNS MoDifiED Installed All Updates Active the all software updates onto console.

  • Page 121: Netpulse & Am Setting Sop

    Please note that this guide is meant to provide an overview on the configuration and setup steps that are unique to the 7xi product. The equipment itself is assembled and installed almost identically to the Matrix Fitness 7xe product line. What sets the Matrix Fitness 7xi equipment apart is our new ‘app’...
  • Page 122 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.8 NETPUlSE & AM SETTiNg UP SoP 2. install gateway server and switch a. Connect the modem to the Gateway with a patch cable. b. Connect the Gateway to the Switch with a patch cable. c.
  • Page 123 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.8 NETPUlSE & AM SETTiNg UP SoP 4. Connect 7xi Units to gateway server via Ethernet cables B - Wireless connecting solution 1. Prepare site for local server and internet connection a. Find a secure location (like an AV closet or a server room) for the gateway and related network equipment. b.
  • Page 124 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.8 NETPUlSE & AM SETTiNg UP SoP STEP 1 - Identifying areas that need coverage and estimating the number of APs needed: Wireless coverage only needs to be provided in areas where cardio machines need to have a wireless connection. If there are spaces in the facility that don’t have cardio machines, there is no need to install access points in that area.
  • Page 125 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.8 NETPUlSE & AM SETTiNg UP SoP Both the 2.4GHz and 5 GHz patterns are fairly symmetric in the azimuthal plane (XY), so it makes little to no difference how the AP is rotated about the Z-axis when mounting.
  • Page 126 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.8 NETPUlSE & AM SETTiNg UP SoP With this type of coverage pattern it is very important to mount the AP so that the base of the coverage cone covers the desired wireless clients. This can be accomplished by mounting the AP to the ceiling above the clients with the face of the AP (the side with the LED lights) pointed down toward the floor.
  • Page 127 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.8 NETPUlSE & AM SETTiNg UP SoP ExAMPlE 3 - iMProPEr iNSTAllATioN Please see the Meraki MR installation guide (Section 4) for additional details on mounting the access point to different fixtures. http://docs.meraki.com/download/attachments/8519767/meraki_setup_MR24.pdf?version=1&modificationDate=1349988446756 STEP 4 - After all the APs are up and running, perform a post installation coverage check.
  • Page 128 10.8 NETPUlSE & AM SETTiNg UP SoP Post-installation console setup Upon completing the install of the Matrix Fitness 7xi cardio equipment, it will be necessary to connect the consoles to the media gateway that is included with the 7xi equipment.
  • Page 129 “npwireless” SSID by manual. iv. If the facility is using a different SSID, select the correct SSID. v. Touch the window provided for entering the pass phrase, Enter the password provided by Matrix Fitness for the npwireless SSID. vi. Press Connect.
  • Page 130 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.8 NETPUlSE & AM SETTiNg UP SoP 3. Access Point setting. a. Use your web browser to open www.meraki.com and login, in the access point screen you can modify the AP name and verify the MAC address (Figure H).
  • Page 131 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.8 NETPUlSE & AM SETTiNg UP SoP Set the NAT mode: Use Meraki DHCP. ii. “npwireless” setting for Netplse accessing, select the npwireless SSID. Set the pre-shared key with WPA2.
  • Page 132 CHAPTEr 10: BiKE SPECifiCATioNS AND ASSEMBly gUiDE 10.8 NETPUlSE & AM SETTiNg UP SoP Set the NAT mode: Use Meraki Bridge mode.
  • Page 133 CHAPTEr 11: SofTWArE UPgrADE iNSTrUCTioNS 11.1 SofTWArE UPgrADE iNSTrUCTioNS 1) Copy the Picard software onto the USB drive (Figure A). 2) Turn on the power to the bike, wait until the standard display picture has been come up (Figure B). figUrE A figUrE B 3) Enter Manager Mode by pressing ENTER, 1, 0, 0, 1, ENTER on the lower keypad.
  • Page 134 CHAPTEr 11: SofTWArE UPgrADE iNSTrUCTioNS 11.1 SofTWArE UPgrADE iNSTrUCTioNS - CoNTiNUED 11) Press the Install All Updates key on the screen (Figure G). 12) Press the Yes key to auto run the upgrade process (Figure H). figUrE g figUrE H 13) The screen will show every software install status (Figure I).
  • Page 135 CHAPTEr 11: SofTWArE UPgrADE iNSTrUCTioNS 11.1 SofTWArE UPgrADE iNSTrUCTioNS - CoNTiNUED 17) Enter Service Mode by pressing ENTER, 3, 0, 0, 1, ENTER on the lower keypad and press the edit key on the screen. Enter the values recorded in Step 3 if necessary (Figure M). figUrE M...
  • Page 136 NoTES...
