30 en | Configuration via IP, Advanced Mode
Auto-connect
Select the On option to automatically re-establish a connection to one of the previously
specified IP addresses after each reboot, after a connection breakdown or after a network
failure.
Notice!
In the default setting, Stream 2 is transmitted for automatic connections. Bear this fact in
mind when assigning the profile (see Encoder Profile, page 17).
Audio
Select On to activate audio alarms.
5.28

VCA

The camera has integrated video content analysis (VCA), which can detect and analyze
changes in the signal on the basis of image processing. Such changes can be due to
movements in the camera's field of view. You can select various VCA configurations and adapt
these to your application as required.
VCA configuration
Select one of the profiles here to activate it or edit it.
You can rename the profile.
1.
2.
The Silent MOTION+ Configuration is active by default. In this configuration, metadata is
created to facilitate searches of recordings; however, no alarm is triggered.
If you select the option Silent VCA, then the system creates metadata to facilitate searches of
recordings but no alarm is triggered. You cannot change any parameters for this configuration.
If you want to turn off VCA, then select Off.
Preset
Select Off or Test.
Alarm status
The alarm status is displayed here for information purposes. This means you can check the
effects of your settings immediately.
Aggregation times
Use the slider (from 0 (zero) to 20 (0 is the default) to select the aggregation times.
Set an aggregation time of between 0 and 20 seconds. The aggregation time always starts
when an alarm event occurs. It extends the alarm event by the value set. This prevents alarm
events that occur in quick succession from triggering several alarms and successive events in a
rapid sequence. No further alarm is triggered during the aggregation time.
The post-alarm time set for alarm recordings only starts once the aggregation time has
expired.
Analysis type
Select the required analysis algorithm. By default, only MOTION+ is available – this offers a
motion detector and essential recognition of tampering.
2015.03 | 1.0 |
To rename the file, click the icon to the right of the list field and enter the new profile
name in the field.
Click the icon again. The new profile name is saved.
