EXTEGRA IP 9000 FX
NXF-9x30
en
Operation Manual

Advertisement

Table of Contents
loading

Related Manuals for Bosch EXTEGRA IP 9000 FX

Summary of Contents for Bosch EXTEGRA IP 9000 FX

  • Page 1 EXTEGRA IP 9000 FX NXF-9x30 Operation Manual...

  • Page 3: Table Of Contents

    EXTEGRA IP 9000 FX Table of Contents | en Table of contents Browser connection System requirements Establishing the connection 1.2.1 Password protection in camera Protected network System overview Live page Playback Settings Configuration Configuring Audio (Optional) Configuration via IP, Basic Mode...
  • Page 4 | Table of Contents EXTEGRA IP 9000 FX 5.28 5.29 Audio Alarm 5.30 Alarm E-Mail 5.31 Alarm Task Editor 5.32 Alarm Rules 5.33 Advanced Mode: Interfaces 5.34 Alarm Inputs 5.35 Alarm Outputs 5.36 Advanced Mode: Network 5.37 DynDNS 5.38 Advanced 5.39...

  • Page 5: Browser Connection

    If you cannot connect, the unit may have reached its maximum number of connections. Depending on the device and network configuration, each unit can have up to 50 web browser connections, or up to 100 connections via Bosch Video Client or Bosch Video Management System.

  • Page 6: System Overview

    | System overview EXTEGRA IP 9000 FX System overview When a connection is established, the LIVE page is initially displayed. The application title bar displays three items: LIVE, PLAYBACK, SETTINGS. Note: The PLAYBACK link is only visible if a storage medium has been configured for recording.

  • Page 7: Configuration

    EXTEGRA IP 9000 FX Configuration | en Configuration Configuring Audio (Optional) Enabling Audio Transmission To transmit audio via the IP connection, follow these steps: Open the Live page, and then click the Configuration tab. In the left pane, click Web Interface. The Web Interface menu expands.

  • Page 8: Configuration Via Ip, Basic Mode

    | Configuration via IP, Basic Mode EXTEGRA IP 9000 FX Configuration via IP, Basic Mode Basic Mode: Device Access Camera name You can give the camera a name to make it easier to identify. The name makes the task of administering multiple units in larger video monitoring systems easier, for example using the Bosch Video Management Systems programs.

  • Page 9: Basic Mode: Encoder

    If a DHCP server is employed in the network for the dynamic assignment of IP addresses, you can activate acceptance of IP addresses automatically assigned to the camera. Certain applications (VIDOS, Bosch Video Management Systems, Archive Player, Configuration Manager) use the IP address for the unique assignment of the unit. If you use these...

  • Page 10: Basic Mode: Audio

    | Configuration via IP, Basic Mode EXTEGRA IP 9000 FX Default Profile name Description DSL Optimized Ideal for encoding on a DSL uplink where bit rate limitations are critical. 3G Optimized Ideal for encoding on a 3G uplink where bit rate limitations are critical.

  • Page 11: Configuration Via Ip, Advanced Mode

    BVC or Bosch Video Management Systems Programs. Enter a unique, unambiguous name for the camera in this field. You can use both lines for this.

  • Page 12: Date/Time

    | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX With the user authorization level, you can operate the unit and also control cameras, for example, but you cannot change the configuration. The lowest authorization level is live. It can only be used to view the live video image and switch between the different live image displays.

  • Page 13: Display Stamping

    EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en Select the region or the city that is closest to the system's location from the list field below the table. Click the Generate button to generate data from the database in the unit and enter it into the table.

  • Page 14: Advanced Mode: Web Interface

    | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX In the Position (XY) fields, enter the values for the desired position. Display milliseconds If necessary, you can also display milliseconds. This information can be useful for recorded video images; however, it does increase the processor's computing time. Select Off if you do not need to display milliseconds.

  • Page 15: Appearance

    EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en Logging, page 16 Appearance On this page you can adapt the appearance of the web interface and change the website language to meet your requirements. If necessary, you can replace the manufacturer's logo (top right) and the product name (top left) in the top part of the window with individual graphics.

  • Page 16: Logging

    | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX Check the box for the items that are to be made available on the LIVE page. The selected items are indicated by a check mark. Check whether the required functions are available on the LIVE page.

  • Page 17: Advanced Mode: Camera

    EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 5.10 Advanced Mode: Camera 5.11 Installer Menu Click the Reboot button to restart the device. There is a ten (10) second pause before the camera adjusts the lens focus. The entire reboot sequence lasts approximately 40 seconds.
  • Page 18 | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX Encoding interval This parameter determines the interval at which images are encoded and transmitted. For example, entering or selecting 4 means that only every fourth image is encoded, while the following there are skipped, which can be particularly advantageous for networks with low bandwidths.

  • Page 19: Encoder Streams

    EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en To obtain the highest quality at the lowest bandwidth, even in the case of increased movement in the picture, configure the quality settings as follows: Observe the coverage area during normal movement in the preview images.
  • Page 20 | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX – Vibrant – Enhanced contrast color reproduction and sharpness The default setting depends on whether the camera is an in-ceiling camera or a pendant camera. Customize the mode, if necessary, for the specific requirements of the site by selecting different values for the fields below.
  • Page 21 EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en If you select this option, the camera makes the following change automatically: – Auto Iris: switches to Constant – Shutter: is disabled Shutter Adjusts the electronic shutter speed (AES). Controls the time period for which light is gathered by the collecting device.

  • Page 22: Lens Settings

    | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX Noise Reduction Level Adjusts the noise level to the appropriate level for shooting conditions. Select a value between 1 and 5. Intelligent Defog With the Defog mode feature, visibility can be improved significantly when viewing foggy or other low-contrast scenes.

  • Page 23: Miscellaneous

    It is also possible to let the VRM Video Recording Manager control all recording with accessing an iSCSI system. This is an external program for configuring recording tasks for video servers. For further information please contact your local customer service at Bosch Security Systems Inc.
  • Page 24 | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX Caution! Activating or deactivating VRM causes the current settings to be lost; they can only be restored through reconfiguration. Recording media Select the required recording media here so that you can then activate them and configure the recording parameters.

  • Page 25: Recording Profiles

    EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en Caution! If older recordings are not allowed to be overwritten when the available memory capacity has been used, the recording in question will be stopped. You can specify limitations for overwriting old recordings by configuring the retention time (see Maximum Retention Time, page 26).

  • Page 26: Maximum Retention Time

    | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX Standard profile From this field, you can select the encoder profile to be used for recording (see Encoder Profile, page 17). Notice! The recording profile can deviate from the standard setting Active profile and is only used during an active recording.

  • Page 27: Recording Scheduler

    EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 5.24 Recording Scheduler The recording scheduler allows you to link the created recording profiles with the days and times at which the camera's images are to be recorded in the event of an alarm.

  • Page 28: Recording Status

    VIDOS or Bosch Video Management System, you can store a general password here. The camera can use this general password to connect to all remote stations protected with the same password.
  • Page 29 EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en Notice! If you enter the destination IP address 0.0.0.0 for destination 10, this address will no longer be used for the tenth attempt at automatic connection in the event of an alarm. The parameter is then used only to save the general password.

  • Page 30: Vca

    | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX Auto-connect Select the On option to automatically re-establish a connection to one of the previously specified IP addresses after each reboot, after a connection breakdown or after a network failure.
  • Page 31 Notice! Additional analysis algorithms with comprehensive functions such as IVMD and IVA are available from Bosch Security Systems Inc. If you select one of these algorithms, you can set the corresponding parameters here directly. You can find information on this in the relevant documents on the product CD supplied.
  • Page 32 | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX Click Select Area to configure the sensor fields. A new window will open. If necessary, click Clear All first to clear the current selection (fields marked yellow). Left-click the fields to be activated. Activated fields are marked yellow.

  • Page 33: Audio Alarm

    EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en Reference Check You can save a reference image that is continuously compared with the current video image. If the current video image in the marked areas differs from the reference image, an alarm is triggered.

  • Page 34: Alarm E-Mail

    | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX Do not use any special characters, for example &, in the name. Special characters are not supported by the system's internal management. Signal Ranges You can exclude particular signal ranges in order to avoid false alarms. For this reason the total signal is divided into 13 tonal ranges (mel scale).

  • Page 35: Alarm Task Editor

    EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en Note: The name must include at least two character groups separated by a blank (for example, Parking Garage) in order for the system to generate an email from that name, as in “From Parking Garage”.

  • Page 36: Advanced Mode: Interfaces

    | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX Aux Off: defines a standard or custom keyboard OFF command. Refer to to User Command Table for a list of valid commands. Note: Only commands 1, 8, 18, 20, 43, 60, 80, 86 are supported. Support for the remaining commands is scheduled for a future release.

  • Page 37: Advanced

    EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en Provider The value in this field defaults to dyndns.org. Select another option as necessary. Host name Enter the host name registered on DynDNS.org for the camera here. User name Enter the user name you registered at DynDNS.org here.

  • Page 38: Network Management

    | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX 5.39 Network Management SNMP The camera supports the SNMP V1 (Simple Network Management Protocol) for managing and monitoring network components, and can send SNMP messages (traps) to IP addresses. The unit supports SNMP MIB II in the unified code.

  • Page 39: Image Posting

    EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en data stream is simultaneously distributed to multiple receivers in a defined group (Multicast). You can enter a dedicated multicast address and port for each stream. You can switch between the streams by clicking the appropriate tabs.

  • Page 40: Accounts

    | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX – Medium – Large – 720p – 1080p File name You can select how file names will be created for the individual images that are transmitted. – Overwrite The same file name is always used and any existing file will be overwritten with the current file.

  • Page 41: Encryption

    EXTEGRA IP 9000 FX Configuration via IP, Advanced Mode | en 5.44 Encryption A special license, with which you will receive a corresponding activation key, is required to encrypt user data. You can enter the activation key to release the function on the Licenses page (see Licenses, page 42).

  • Page 42: Licenses

    | Configuration via IP, Advanced Mode EXTEGRA IP 9000 FX Click OK to the warning message to continue the firmware upload, or Cancel to stop the upload. The page displays a progress bar as the firmware is uploaded. Note: Once the progress bar reaches 100%, the system opens the reset page. Allow the reset page to complete its action.

  • Page 43: Operation

    6.1.2 Storage, CPU and network status When accessing the unit with a browser, the local storage, processor and network status icons are shown in the upper right of the window next to the Bosch logo. Bosch Security Systems Operation Manual...

  • Page 44: View Control

    | Operation EXTEGRA IP 9000 FX When a local storage card is available, the memory card icon changes color (green, orange or red) to indicate the local storage activity. If you hover over this icon with the mouse the storage activity is shown as a percentage.

  • Page 45: Aux Control

    EXTEGRA IP 9000 FX Operation | en Iris open Sets the pre-set scene for the corresponding button 1, 2, 3, 4, 5 and 6 Zooms the camera to pre-set scene numbers 1, 2, 3, 4, 5 and 6 To control a peripheral, follow these steps: Click the appropriate controls.

  • Page 46: Presets

    | Operation EXTEGRA IP 9000 FX Command number field Keypad (numbers 0-9) Show a preset scene Set a preset scene Initiates a command Deletes a number in the Command Number field Used to select a menu item Stops a command To Enter a Keyboard Control Command: Place the cursor in the Command Number field.

  • Page 47: Digital I/O

    EXTEGRA IP 9000 FX Operation | en Notice! For more information about the camera settings and controls, click the Help on this page? link to open the online help. 6.1.6 Digital I/O The alarm icon is for information purposes and indicates the status of an alarm input: When an alarm is triggered, the icon lights up blue.

  • Page 48: Saving Snapshots

    | Operation EXTEGRA IP 9000 FX Release the F12 key when you want to stop sending audio signals to the camera. The status bar displays the message Send Audio OFF. Notice! When the voice contact connection to the camera is broken, the next user to make a connection to the camera can send audio data to the camera.
  • Page 49 EXTEGRA IP 9000 FX Operation | en Controlling Playback A time bar below the video image allows quick orientation. The time interval associated with the sequence is displayed in the bar in gray. A green arrow above the bar indicates the position of the image currently being played back within the sequence.

  • Page 50: Appendix

    | Appendix EXTEGRA IP 9000 FX Appendix Alarm Function Comm. Command Description Rule Output On/Off Play Custom Pre-position Activate/Deactivate Tour On/Off Play Pre-position Tour Activate/Deactivate On/Off Backlight Comp Backlight Compensation On/Off Stabilization Electronic Stabilization (Available only with the AUTODOME 7000 IP)
  • Page 51 EXTEGRA IP 9000 FX Appendix | en Alarm Function Comm. Command Description Rule Output On/Off Record Tour B On–start recording Off- stop recording Power Mode ` Temporarily displays current power mode “24 VAC:”, “POE+”, “POE++”, or “Unknown”) Camera Reboot Forces the camera to complete the power on boot sequence.
  • Page 54 Bosch Security Systems, Inc. Bosch Sicherheitssysteme GmbH 1706 Hempstead Road Robert-Bosch-Ring 5 Lancaster, PA, 17601 85630 Grasbrunn Germany www.boschsecurity.com © Bosch Security Systems, Inc., 2015...
