40
en | Configuration via IP, Advanced Mode
–
–
–
–
File name
You can select how file names will be created for the individual images that are transmitted.
–
–
–
Posting interval
Enter the interval in seconds at which the images will be sent to an FTP server. Enter 0 (zero)
if you do not want any images to be sent.
Target
Select the target—the name of the account on the server—to which to save images.
5.42
Accounts
In order to configure image posting, and to save and retrieve JPEG images, you must create an
Account in which to save and access them. You can create a maximum of four (4) accounts.
Type
Select the type of account: FTP or Dropbox.
Account name
Enter the name of the account.
IP address
Enter the IP address of the server on which you wish to save the JPEG images.
Login
Enter the login ID for the server.
Password
Enter the password that gives you access to the server. To verify the password, click the
Check button to the right.
Path
Enter the exact path on which you wish to post the images on the server. To browse for the
correct path, click the Browse button to the right.
Maximum bit rate
Enter the maximum bit rate for the JPEG images (in kbps).
5.43
IPv4 Filter
Use this setting to configure a filter that allows or blocks network traffic that matches a
specified address or protocol.
IP Address 1 / 2
Enter the IPv4 address that you want to allow or block
Mask 1 / 2
Enter the subnet mask for the appropriate IPv4 address.
2015.03 | 1.0 |
Medium
Large
720p
1080p
Overwrite The same file name is always used and any existing file will be overwritten with
the current file.
Increment A number from 000 to 255 is added to the file name and automatically
incremented by 1. When it reaches 255 it starts again from 000.
Date/time suffix The date and time are automatically added to the file name. When
setting this parameter, ensure that the unit's date and time are always correctly set.
Example: the file snap011005_114530.jpg was stored on October 1, 2005 at 11:45 and
30 seconds.
Operation Manual
EXTEGRA IP 9000 FX
Bosch Security Systems
