CAUTION! The CCD image sensors are highly sensitive and require
!
special care for proper performance and extended lifetime. Do not
expose them to direct sunlight or bright spot lights in operating and
non-operating conditions.
2.7
Window Selection
Narrow Window
Wide Window
2.8
LED array- power adjustments
If adjustment is needed, the following procedure must be followed:
1) Remove the rear cover of the camera. Set cover aside.
Bosch Security Systems
Recommended
focal length [mm]
18-50mm
5-18mm
Photocell
Adjustment Pot
Quick Install
Recommended HFOV @ 100ft /
30m distance [ft / m]
28ft / 8m and narrower
Wider than 18ft / 8m
Pot
| en 9
IR Adjustment
MAN30IPB Rev.0
