Summary of Contents for Crestron ST-VC
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON...
-
Page 3: Table Of Contents
Leading Specifications... 4 Setup ... 6 Preparation for Use... 6 Identity Code ... 7 Programming ... 8 Programming with the Crestron AppBuilder... 8 Programming with SIMPL Windows... 8 ST-VC Symbol ... 9 Example Program ... 11 Problem Solving ... 11 Troubleshooting ... -
Page 5: Volume Control Module: St-Vc
104 dB drop from any preset volume level. Likewise channels Operations Guide - DOC. 5676A OPTIONAL 600 OHM TERMINATOR BALANCED INPUT BALANCED OUTPUT EXAMPLE Volume Control Module UNBALANCED 10K INPUT UNBALANCED OUTPUT EXAMPLE Volume Control Module: ST-VC • 1... -
Page 6: Models
“pops” caused by accidental power-down/power-up conditions to the ST-VC. If the ST-VC is under program control and the power is cycled to the ST-VC, it renews the volume, bass, and treble levels to the current program settings. The mute status (per channel and the mute-all) are also restored. - Page 7 Crestron ST-VC ST-VC Ports A number of ports are provided on the back of the ST-VC. Each has a silk-screened label. Refer to illustration and descriptions below. ST-VC Ports 12 VDC .5 A NOTE: An external power pack is not supplied with the ST-VC. When the ST-VC is used as part of the Cresnet system, there is no need for a power pack.
-
Page 8: Leading Specifications
+ and - lines to the signal ground when muted. ST-VC Indicators There are eight LED indicators located on the front panel of the ST-VC. Refer to illustration and descriptions below. ST-VC Indicators PWR (Power) This green LED illuminates when power is supplied to the ST-VC. -
Page 9: Specification
Crestron. Update files with an "S" designator are for the ST-CP, "V" designator for CEN/CN-TVAV, "W" for CNRACKX-DP, and "X" for CNMSX-AV/Pro control systems. -
Page 10: Setup
SmarTouch STS. The second diagram showns connections to the Cresnet system. Complete the connections in any order, regardless of whether the ST-VC is part of SmarTouch STS or the Cresnet system. SmarTouch STS Hookup Connections for ST-VC 6 •... -
Page 11: Identity Code
03 to FE. The NET ID of each unit must match an ID code specified in the SIMPL Windows program. The NET ID of each ST-VC has been factory set to 10. The NET IDs of multiple ST-VCs in the same system must be unique and changed from a PC via Viewport, which is available from SIMPL Windows or VisionTools™... -
Page 12: Programming
(i.e., windows) in which a programmer can select, configure, program, test, and monitor a Crestron control system. The next three sections describe a ST-VC within SIMPL Windows. The first section provides initial configuration information, the second section identifies the ST-VC 8 •... -
Page 13: St-Vc Symbol
NOTE: The following descriptions assume that the reader has knowledge of SIMPL Windows. If not, refer to the extensive help information provided with the software. Configure ST-VC Program To create a program with a ST-VC, refer to the table below for initial configuration information. Configure ST-VC Program Device Library,... - Page 14 Volume Control Module Detail View of the ST-VC Symbol in SIMPL Windows' Programming Manager ST-VC Symbol Input Descriptions INPUT(S) mutea, muteb, mutec muteall volA, volB, volC trebA, trebB, trebC bassA, bassB, bassC 10 • Volume Control Module: ST-VC FUNCTION(S) Each channel (A through C) has a corresponding muting relay with 104 dB attenuation.
-
Page 15: Example Program
FLAT input which will take the bass and treble levels for channels A, B, and C to 50%. There is a MUTE ALL that simply toggles the MUTE ALL line on the ST-VC. When MUTE ALL is engaged, the mute states for A, B, and C are disregarded and all channels are muted. -
Page 16: Further Inquiries
Further Inquiries If after reviewing this Operations Guide for the Volume Control Module, you can not locate specific information or have questions, please take advantage of Crestron's award winning customer service team in your area. Dial one of the following numbers. -
Page 17: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 18 Volume Control Module Crestron ST-VC This page intentionally left blank. 14 • Volume Control Module: ST-VC Operations Guide - DOC. 5676A...
- Page 19 Crestron ST-VC Volume Control Module This page intentionally left blank. Volume Control Module: ST-VC • 15 Operations Guide – Doc. 5676A...
- Page 20 Crestron Electronics, Inc. Operations Guide – DOC. 5676A 15 Volvo Drive Rockleigh, NJ 07647 02.02 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
