- Page 1 Crestron PMK-17L Pre-Construction Mount Kit Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2005 Crestron Electronics, Inc.
- Page 3 Refer to the physical views (bottom, side, and front) of the PMK-17L, shown after this paragraph. The table that follows lists all parts included with the PMK-17L.
-
Page 4: Installation
NOTE: The PMK-17L requires a 16¼-inch wide space between the studs where it is to be placed. The touchpanel will not fit otherwise. The PMK-17L consists of a single metal plate, which fastens to the studs of a framed wall prior to hanging drywall (shown after this paragraph). To accommodate the touchpanel, the space between the studs must be 16¼... - Page 5 The plate is designed to provide the necessary support for a single touchpanel and must mount to the right and left studs. Confirm that the PMK-17L is level before application of drywall. A rectangular opening with the dimensions shown in the illustration after this paragraph must be made in the drywall.
- Page 6 PAN HEAD SCREW (2007254) QTY. 8 NOTE: Prior to mounting the touchpanel, ensure that the PMK-17L is flush with the drywall (no kinks or bends in the metal). Any separation may make screwing in the touchpanel more difficult. One can purchase and attach a TMK-17L or MMK-17L to keep the PMK-17L straight.
-
Page 7: Further Inquiries
Crestron products. First-time users will need to establish a user account to fully benefit from all available features. As of the date of manufacture, the PMK-17L has been tested and found to comply with specifications for CE marking. -
Page 8: Return And Warranty Policies
Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures.
