  • Page 1 Crestron TMK-17L & WMKT-17L Trim Ring Mount Kits Installation Guide...
  • Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2005 Crestron Electronics, Inc.
  • Page 3: Supplied Hardware

    The TMK-17L consists of a metal trim ring that attaches to the PMK-17L or BB-17L. The WMKT-17L consists of the trim ring found in the TMK-17L as well as a mounting plate. The mounting plate is the part that provides the necessary support for the touchpanel.
  • Page 4 (43.07 cm) MOUNTING PLATE (WMKT-17L ONLY) Cutout Dimensions (29 mm Max) TYP (4X) (127 mm Max) 2 • Trim Ring Mount Kits: TMK-17L & WMKT-17L Crestron TMK-17L & WMKT-17L DESCRIPTION Metal Plate, Mounting (WMKT-17L only) Metal Trim Ring 0.06 in 16.45 in...
  • Page 5: Installation

    The procedure in this section provides the necessary steps for the assembly of the TMK-17L to either the PMK-17L or BB-17L. It is assumed that the PMK-17L or BB-17L has been secured to the studs according to the procedures in the latest revisions of their respective Installation Guides (Doc.
  • Page 6 4 • Trim Ring Mount Kits: TMK-17L & WMKT-17L Crestron TMK-17L & WMKT-17L 3. When the trim ring is in position, bend the top two flanges of the ring upward and the bottom two flanges downward. •...
  • Page 7 (approximately 90 degrees). Refer to the following diagram. Bend Flanges – Front and Back View 7. Run the necessary cables for the touchpanel and secure them behind the mounting surface. Trim Ring Mount Kits: TMK-17L & WMKT-17L • 5 Trim Ring Mount Kits MOUNTING PLATE (2013469)
  • Page 8 Trim Ring Mount Kits CAUTION: To dissipate heat generated by the touchpanel, Crestron recommends the touchpanel be installed in a ventilated lectern for heat dissipation. 6 • Trim Ring Mount Kits: TMK-17L & WMKT-17L Crestron TMK-17L & WMKT-17L 8. The touchpanel can be installed using the eight tapped holes in the mounting plate.
  • Page 9: Further Inquiries

    For assistance in your local time zone, refer to the Crestron website (www.crestron.com) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features.
  • Page 10: Return And Warranty Policies

    CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures.
  • Page 11 Crestron TMK-17L & WMKT-17L Trim Ring Mount Kits This page intentionally left blank. Trim Ring Mount Kits: TMK-17L & WMKT-17L • 9 Installation Guide – DOC. 6370...
  • Page 12 Crestron Electronics, Inc. Installation Guide – DOC. 6370 15 Volvo Drive Rockleigh, NJ 07647 (2013439) Tel: 888.CRESTRON 08.05 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
