Summary of Contents for VIRTUFIT Water Resistance Row 800
- Page 1 Water Resistance Row 800 Rowing Machine User Manual...
-
Page 2: Table Of Contents
FILL AND EMPTY THE WATER TANK 13 - 14 MAINTENANCE MAINTENANCE 15 - 17 CONTROL PANEL CONTROL PANEL EXPLODED DRAWING EXPLODED DRAWING 19 - 20 PARTS LIST PARTS LIST 21 - 23 TRAINING INSTRUCTIONS TRAINING INSTRUCTIONS VirtuFit Water Resistance Row 800 Rowing Machine... -
Page 3: Safety Instructions
– Always use the equipment as indicated. If you find any defective components while assembling or checking the equipment, or if you hear any unusual noises coming from the equipment during use, stop immediately. Do not use the equipment until the problem has been rectified. VirtuFit Water Resistance Row 800 Rowing Machine... - Page 4 Maintenance assembly and repair work not carried out by an official dealer. • In the event of improper use, neglect and / or poor maintenance. • Failure to maintain the fitness equipment in accordance with the manufacturer’s instructions (see the enclosed manual). VirtuFit Water Resistance Row 800 Rowing Machine...
-
Page 5: Checklist
When you open the carton, you will find the below parts in the carton: NO.54 NO.43L/R NO.1 NO.45 NO.12 NO.39 NO.101 NO.100 DESCTIPTION DESCTIPTION Main Frame Handlebar Holder Pedal Shaft Console Seat Syphon pump 43 L/R Pedal Funnel VirtuFit Water Resistance Row 800 Rowing Machine... - Page 6 TOOLKIT #102 S4 1PC #103 S6 1PC #104 S13-17 2PCS M10x115 1PC #87 M10 1PC #65 M10*55 2PCS #58 M5*10 2PCS #75 M6*16 6PCS #82 M10 3PCS #81 M10 2PCS #86 M10 2PCS VirtuFit Water Resistance Row 800 Rowing Machine...
-
Page 7: Assembly Instructions
In this way you prevent the head of the socket head screw from being rotated. STEP 1 • Unfold the Front Support (2) away from the Main Frame (1); • Unfold the Upright (4) away from the Rail (3). VirtuFit Water Resistance Row 800 Rowing Machine... - Page 8 Bolt the Front Support (2) to the Main Frame (1) with Button Head Bolt ( M10 X 1.5 X 115mm)(63) Washer(M10)(82), and Nylock Nut (M10 X 1.5)(87); • Attach the Upright (4) to the Front Support(2) with Button Head Bolt (M10 X 1.5 X 55mm)(65). VirtuFit Water Resistance Row 800 Rowing Machine...
- Page 9 Nuts (M10 X 1.5)(86) at both ends of the Pedal Shaft (12); • You need to use two combination Wrenches to tighten the Acorn Nuts (M10 X 1.5)(86) at both ends of the Pedal Shaft(12) at the same time. VirtuFit Water Resistance Row 800 Rowing Machine...
- Page 10 Attach the Meter(54) to the Meter Plate(6) with 2x Round Head Bolts (M5 X 0.8 X 10mm)(76). Plug the Sensor Wires(55) into the connecting wires of the Meter(54), and push the excess wires back into the Upright(4). VirtuFit Water Resistance Row 800 Rowing Machine...
-
Page 11: Moving The Rowing Machine
With the wheels on the ground, you can transport the rower to the desired location with ease. NOTE! The seat can slide. ADJUSTING BALANCE Adjust the Stand (59) below the Stabilizers of the machine if it is unbalanced during use. VirtuFit Water Resistance Row 800 Rowing Machine... -
Page 12: Fill And Empty The Water Tank
Maximum level - this could void the warranty. The amount of resistance is dictated by the amount of water in the tank. For example level 2 of water offer light resistance, Level 6 offers a heavier resistance. VirtuFit Water Resistance Row 800 Rowing Machine... -
Page 13: Maintenance
BLEACH. Use of these products will void the warranty and damage the product. NOTE! It is the user / owner’s responsibility to ensure that periodic maintenance is performed. Worn or damaged components shall be replaced immediately. Contact your dealer for help. VirtuFit Water Resistance Row 800 Rowing Machine... - Page 14 1. If you see an improper display on the monitor, please replace the batteries to have a good result. 2. Use 2 pcs 1.5 AAA batteries as power supply. See image opposite to install or replace the images. VirtuFit Water Resistance Row 800 Rowing Machine...
-
Page 15: Control Panel
In the setting mode, press the button to reset the setting values to zero. Press the (5) RESET button and hold it down for two seconds to reset all functions to zero VirtuFit Water Resistance Row 800 Rowing Machine... - Page 16 The Heart Rate Transmitter(95) is not a medical device. Maintaining a consistent signal can be difficult due to the varying distances experienced during the rowing stroke. The pulse function is a great tool to optimize your workout, but should be used as a reference only. VirtuFit Water Resistance Row 800 Rowing Machine...
- Page 17 The Meter will shut off automatically after 4 minutes of inactivity. All function values will be kept. You can continue to work out with these function values. Or, press the Reset or Mode button and hold it down for two seconds to reset all functions to zero. VirtuFit Water Resistance Row 800 Rowing Machine...
-
Page 18: Exploded Drawing
EXPLODED DRAWING VirtuFit Water Resistance Row 800 Rowing Machine... -
Page 19: Parts List
Shaft Retainer Strap / Bungee Pulley Stand Hook pad Beaering 6000zz One-way Bearing HF2016 Bearing 608zz Spring Pin Ø6X40mm Bolt Flat Sock Head M10x1.5x115mm Strap Pulley Bolt M10 X 1.5 X 105 mm VirtuFit Water Resistance Row 800 Rowing Machine... - Page 20 Arcon Nut M10 X 1.5 Nylock Nut M8 X 1.25 Nylock Nut M6 X 1 Nylock Nut M3 X 0.5 Large Washer M8 X Ø20mm Upper pad 25mm X 25mm Impeller Seal Tank Seal Foam Spacer VirtuFit Water Resistance Row 800 Rowing Machine...
-
Page 21: Training Instructions
The purpose of cooling down is to return the body to its normal or near normal, resting state at the end of each exercise session. A proper cool-down slowly lowers your heart rate and allows blood to return to the heart. VirtuFit Water Resistance Row 800 Rowing Machine... - Page 22 3. Push your body backwards while simultaneously straightening your back and legs (Fig. 2). Continue this movement until you are leaning slightly backwards. Bring your arms out of the side during this phase (Fig. 3). 4. Thereafter return to the second position and repeat it as shown below. VirtuFit Water Resistance Row 800 Rowing Machine...
- Page 23 1. Keep your back straight and arms out-stretched, bend your legs until you will grasp the rowing handles in the starting position (Fig. 7). 2. Use your legs to push your body back (Fig. 8) while keeping your arms and back straight as shown in Fig. 9. VirtuFit Water Resistance Row 800 Rowing Machine...
- Page 24 For questions or missing parts please contact your dealer.
