- Page 1 Row 600i Rowing Machine ser manual...
-
Page 2: Table Of Contents
3 - 4 SAFETY INSTRUCTIONS 5 - 7 CHECKLIST 8 - 13 ASSEMBLY INSTRUCTIONS FOLDING INSTRUCTIONS 15 -16 MAINTENANCE TROUBLE SHOOTING 18 - 19 CONTROL PANEL EXPLODED DRAWING 22 - 23 PARTS LIST TRAINING INSTRUCTIONS VirtuFit Row 600i Rowing Machine... -
Page 3: Safety Instructions
– Always use the equipment as indicated. If you find any defective components while assembling or checking the equipment, or if you hear any unusual noises coming from the equipment during use, stop immediately. Do not use the equipment until the problem has been rectified. VirtuFit Row 600i Rowing Machine... -
Page 4: Safety Instructions
Maintenance assembly and repair work not carried out by an official dealer. • In the event of improper use, neglect and / or poor maintenance. • Failure to maintain the fitness equipment in accordance with the manufacturer’s instructions (see the enclosed manual). VirtuFit Row 600i Rowing Machine... -
Page 5: Checklist
CHECKLIST TOOLKIT When you open the carton, and you will find the below parts in the carton: NUMBER DESCRIPTION Main Frame Rear Plastic Stabilizer Main Rail Saddle Pedal Front Stabilizer VirtuFit Row 600i Rowing Machine... - Page 6 CHECKLIST TOOLKIT NUMBER DESCRIPTION SHAPE Axe Ø 13*126 Axe Ø 13*66 Bolt M8*38 Bolt M8*15 Bolt M8*25 Washer ID8.2 Cushion 23*23*19 Allen key 6S Plum Bolt Knob M8*35 Plum Bolt Knob M8*20 VirtuFit Row 600i Rowing Machine...
-
Page 7: Checklist
CHECKLIST TOOLKIT NUMBER DESCRIPTION SHAPE Connecting plate 140*33*4 Open spanner Bolt M6*10 Decorative covers 16 + 17 Console support Bolt M8*130 Nylon locknut Allen key 5S VirtuFit Row 600i Rowing Machine... -
Page 8: Assembly Instructions
Socket screws: The rowing machine contains socket screws, make sure that the allen key is firmly in the bolt before you apply force to the key. In this way you prevent the head of the socket head screw from being rotated. STEP 1 S6 2 PCS VirtuFit Row 600i Rowing Machine... - Page 9 A M8x38 2 PCS STEP 2 S6 1 PCS • Upright the main frame onto the style foam to prevent from scratch on the plastic cover while mounting the front stabiliser to the main frame. VirtuFit Row 600i Rowing Machine...
- Page 10 E 23x23x19 2 PCS Ø 13x66 1 PCS ASSEMBLY INSTRUCTIONS STEP 3 S6 2 PCS VirtuFit Row 600i Rowing Machine...
- Page 11 Carry on the Main Rail (36) moving to the Main Frame (1). Linked the sensor wire taps (51) and (54) firstly. • Lighten the knob (I) and knob (J) with the washer (B), bolt (O) and the Nylon locknut (Q) orderly. VirtuFit Row 600i Rowing Machine...
- Page 12 ASSEMBLY INSTRUCTIONS STEP 5 VirtuFit Row 600i Rowing Machine...
-
Page 13: Assembly Instructions
The rowing machine is fully installed and can be used. The console (display) is adjustable in angle. You can train in the right position at all times and have a good view of the display. VirtuFit Row 600i Rowing Machine... -
Page 14: Folding Instructions
UNFOLDING Pull the Knob(J) as the direction of arrow, at the same time, unfold the Rail to the ground. Then screw the Knob (I) with the washer (W) and tighten the Knob (J) at last. VirtuFit Row 600i Rowing Machine... -
Page 15: Maintenance
NOTE: You should begin your “Exercise Period” at the resistance level and speed to suit your needs. Remember to start out slow and easy, and work your way up to the fitness level you desire. VirtuFit Row 600i Rowing Machine... -
Page 16: Maintenance
CHANGING THE BATTERIES 1. If you see an improper display on the monitor, please replace the batteries to have a good result. 2. Please use 2pcs of 1.5v AA batteries as a power supply. (See step 5). VirtuFit Row 600i Rowing Machine... -
Page 17: Trouble Shooting
If this still does not work, you can move the sensor slightly. Rowing machine beeps Check that all bolts and nuts are tightened securely. Spray silicone spray if necessary. Also check the wheels under the seat. VirtuFit Row 600i Rowing Machine... -
Page 18: Control Panel
By holding down the reset button for 3 seconds you can clear the settings. With RESET this button you can reset the value to zero. MODE Press the MODE button to select a desired function. Set the values for: “TIME” , “DISTANCE” and “CALORIES”. VirtuFit Row 600i Rowing Machine... -
Page 19: Control Panel
Counts the number of rowing strokes per minute. COUNT Counts the rowing strokes from start to finish. DISTANCE The distance traveled during the exercise is displayed. PULSE Heart rate during your exercise 40 ~ 240 BPM. (PUL) VirtuFit Row 600i Rowing Machine... - Page 20 Connect the rowing machine with the app via Start training. your details. Bluetooth. Click “connect device” and select the device from the list. Make sure the console is on. STEP 2 STEP 3 STEP 4 VirtuFit Row 600i Rowing Machine...
-
Page 21: Exploded Drawing
EXPLODED DRAWING VirtuFit Row 600i Rowing Machine... -
Page 22: Parts List
Magnetic flywheel Plastic pad Bolt M8*30 Bolt M8*55 Wheel Sleeve Sleeve Plastic wheel Magnet Nut M8 Screw M3*10 Bolt M8*35 Bolt M6*12 Pulley Saddle Support frame End cap Saddle Grip 47R Right plastic Cover (right) VirtuFit Row 600i Rowing Machine... -
Page 23: Parts List
PARTS LIST DESCRIPTION 47L Left plastic Cover (left) Screw M4*20 Screw M4*12 Sensor fasten plate Sensor Srew M5*10 Steain relief bushing Sensor wire of computer Pedal Front stabilizer Sleeve Computer Nut M8 Tension Rope Strip Bolt VirtuFit Row 600i Rowing Machine... -
Page 24: Training Instructions
The purpose of cooling down is to return the body to its normal or near normal, resting state at the end of each exercise session. A proper cool-down slowly lowers your heart rate and allows blood to return to the heart. VirtuFit Row 600i Rowing Machine... - Page 25 For questions or missing parts please contact your dealer.
