Summary of Contents for VIRTUFIT Ultimate Pro 2
- Page 1 Ultimate Pro 2 Ergometer Rowing Machine User manual...
- Page 2 INDEX SAFETY INSTRUCTIONS CHECKLIST NOTES 7-13 ASSEMBLY INSTRUCTIONS EXPLODED DRAWING 15-17 PARTS LIST VirtuFit Ultimate Pro 2 Ergometer Rowing Machine...
-
Page 3: Safety Instructions
Additional terms and conditions are listed in the back of this manual or enclosed owner’s manual. Colors and specifications subject to change without notice. VirtuFit Ultimate Pro 2 Ergometer Rowing Machine... -
Page 4: Checklist
CHECKLIST TOOLKIT NUMBER DESCRIPTION Main frame Aluminum rails Front stabilizer Rear stabilizer Pedals Seat Console Console cover VirtuFit Ultimate Pro 2 Ergometer Rowing Machine... - Page 5 Bolt M10 x 16 mm Washer M10 x 1.5t Bolt M6 x 50 mm Bolt M8 x 25 mm Bolt M8 x 16 mm Washer M8x1.5t Pull pin Screw M4 x 10 mm Spring washer VirtuFit Ultimate Pro 2 Ergometer Rowing Machine...
-
Page 6: Notes
PLEASE BE CAUTIOUS: As some components may be sharp and can cause harm if not handled correctly. Always use safety measurements when assembling any piece of equipment or machinery. VirtuFit Ultimate Pro 2 Ergometer Rowing Machine... -
Page 7: Assembly Instructions
Once this is done, the pre- screwed holes for Forward Base Leg (C) will be visible. To bolt in Forward Base Leg (C) into Forward Base (A), place directly on top of pre-screwed holes. Secure with 2 (J1) Bolt(s) and (J2) Washer(s). VirtuFit Ultimate Pro 2 Ergometer Rowing Machine... - Page 8 (2)Once wires are connected CAREFULLY secure Console Tube (G) to the stem of Base Leg (A). Please be careful of exposed wire ends. The wires should recede back into stem once connected in order to prevent damage or dislocation. VirtuFit Ultimate Pro 2 Ergometer Rowing Machine...
- Page 9 To install Rear Base Leg (D), face Base Railing (B) face down so that the receiving device for the seat cushion is on the floor. Place Rear Base Leg (D) above the pre-screwed holes of the Base Rail (B). Once placed secure with 2 (J1) Bolt(s) and (J2) washer(s). VirtuFit Ultimate Pro 2 Ergometer Rowing Machine...
- Page 10 Pre-screwed holes on the base railing would cover up the pre screwed holes on the Forward Base leg where the foot pedals are to be installed. So make sure you do not skip step 5. VirtuFit Ultimate Pro 2 Ergometer Rowing Machine...
- Page 11 Secure Forward Base (A) to Base Railing (B) with 4 Bolts (J6) and 4 Washers (J7). • NOTE: Please be sure to tighten and secure ALL BOLTS AND WASHERS IN THEIR PLACE TO ENSURE A SOLID AND SECURE foundation to the rower. VirtuFit Ultimate Pro 2 Ergometer Rowing Machine...
- Page 12 Rower storage • To fold the VirtuFit Ultimate Pro 2 Ergometer Rowing Machine, simply pull the PULL PIN (J8) while holding the Rail Handle (B21) located between Forward Base (A) and Base Railing (B). Gently set Forward Base (A) down to ground by controlling Rail Handle (B21) gently downwards. This will cause Forward Base (A) to drop down and will allow you to raise Base Railing (B) until it clicks securely into a folded position.
- Page 13 ASSEMBLY INSTRUCTIONS Damper level Foot height adjuster Push down to adjust the position of the heel support VirtuFit Ultimate Pro 2 Ergometer Rowing Machine...
-
Page 14: Exploded Drawing
EXPLODED DRAWING VirtuFit Ultimate Pro 2 Ergometer Rowing Machine... -
Page 15: Parts List
Axial of pulley (back) Φ12.7*76 mm Washer Φ22*Φ44.2*3T Elastic rope bracket A12-1 Rubber Cover 6001 Chain bracket A12-2 Rubber Cover 6903 Pulley socket Chain pulley A13-1 Bearing BR-6001ZZDKFL Hexagon head screw M6*10 mm A13-2 Bearing BR-6903ZZDKFL VirtuFit Ultimate Pro 2 Ergometer Rowing Machine... - Page 16 Left pedal rest cover Washer M8*2.0T*Φ16 Right pedal rest cover Lower acorn Nut M8 Tapping screw M4*8 mm Seat carriage roller Set piece Bearing PR-608ZZ(BMC) Set base Even head socket screw M8*20 mm VirtuFit Ultimate Pro 2 Ergometer Rowing Machine...
- Page 17 Cap head socket screw M6*50 mm Tapping screw M4*12 mm Cap head socket screw M8*35 mm Cap head socket screw M8*16 mm Washer M8*Φ16*1.5T Pull pin Ball head view M4*10 mm Spring washers Pedal stable bracket VirtuFit Ultimate Pro 2 Ergometer Rowing Machine...
- Page 18 For questions or missing parts please contact your dealer.
