- Page 1 Ultimate Pro 2i Ergometer Rowing Machine User manual...
- Page 2 SAFETY INSTRUCTIONS 5 - 6 CHECKLIST CHECKLIST NOTES NOTES 8 - 14 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS 15 - 22 CONSOLE CONSOLE APPS APPS EXPLODED DRAWING EXPLODED DRAWING 25 - 27 PARTS LIST PARTS LIST VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
-
Page 3: Safety Instructions
– Before using the device, check that the nuts and bolts are securely tightened. – The safety of the device can only be maintained if it is regularly examined for damage and/or wear and tear. VirtuFit Ultimate Pro 2i Ergometer Rowing Machine... - Page 4 – Maintenance assembly and repair work not carried out by an official dealer. – In the event of improper use, neglect and / or poor maintenance. – Failure to maintain the device in accordance with the manufacturer’s instructions (see the enclosed manual). VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
- Page 5 CHECKLIST TOOLKIT NUMBER DESCRIPTION Main frame Aluminum rails Front stabilizer Rear stabilizer Pedals Seat Console Console cover VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
- Page 6 Bolt M10 x 16 mm Washer M10 x 1.5t Bolt M6 x 50 mm Bolt M8 x 25 mm Bolt M8 x 16 mm Washer M8x1.5t Pull pin Screw M4 x 10 mm Spring washer VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
- Page 7 PLEASE BE CAUTIOUS: As some components may be sharp and can cause harm if not handled correctly. Always use safety measurements when assembling any piece of equipment or machinery. VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
- Page 8 Once this is done, the pre- screwed holes for Forward Base Leg (C) will be visible. To bolt in Forward Base Leg (C) into Forward Base (A), place directly on top of pre-screwed holes. Secure with 2 (J1) Bolt(s) and (J2) Washer(s). VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
- Page 9 (2)Once wires are connected CAREFULLY secure Console Tube (G) to the stem of Base Leg (A). Please be careful of exposed wire ends. The wires should recede back into stem once connected in order to prevent damage or dislocation. VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
- Page 10 To install Rear Base Leg (D), face Base Railing (B) face down so that the receiving device for the seat cushion is on the fl oor. Place Rear Base Leg (D) above the pre-screwed holes of the Base Rail (B). Once placed secure with 2 (J1) Bolt(s) and (J2) washer(s). VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
- Page 11 Pre-screwed holes on the base railing would cover up the pre screwed holes on the Forward Base leg where the foot pedals are to be installed. So make sure you do not skip step 5. VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
- Page 12 Secure Forward Base (A) to Base Railing (B) with 4 Bolts (J6) and 4 Washers (J7). • NOTE: Please be sure to tighten and secure ALL BOLTS AND WASHERS IN THEIR PLACE TO ENSURE A SOLID AND SECURE foundation to the rower. VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
- Page 13 Rower storage • To fold the VirtuFit Ultimate Pro 2i Ergometer Rowing Machine, simply pull the PULL PIN (J8) while holding the Rail Handle (B21) located between Forward Base (A) and Base Railing (B). Gently set Forward Base (A) down to ground by controlling Rail Handle (B21) gently downwards. This will cause Forward Base (A) to drop down and will allow you to raise Base Railing (B) until it clicks securely into a folded position.
- Page 14 ASSEMBLY INSTRUCTIONS Damper level Foot height adjuster Push down to adjust the position of the heel support VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
- Page 15 PRE-BUILT PROGRAMS Toggle through the menu using the up/down arrows to select from the various pre-built programs: Quick Start, Competition Racing, Interval/Tabdata, Target Time, Target Calories, Target Strokes or Target Distance VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
-
Page 16: Quick Start
4. If you stop rowing, the time shown on the lower right window of the monitor will pause. When you start rowing again, it will continue operating from where you left off. 5. Press the STOP button to pause the monitor. VirtuFit Ultimate Pro 2i Ergometer Rowing Machine... -
Page 17: Quick - Program
Once your target race distance is set, the program defaults to a 2:15 TIME / 500M setting. 4. You can use the “UP / DOWN” button to change the “TIME / 500M” settings. Press the ENTER key when finished. VirtuFit Ultimate Pro 2i Ergometer Rowing Machine... -
Page 18: Interval - Program
5. Once your number of intervals is set, the program will default to 1:00 of work time. 6. You can use the “UP / DOWN” button to change the amount of work time. Press the ENTER key when you are finished. VirtuFit Ultimate Pro 2i Ergometer Rowing Machine... - Page 19 5. Once your number of intervals is set, the program will default to 1:00 of work time. 6. You can use the “UP / DOWN” button to change the amount of work time. Press the ENTER key when you are finished. VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
-
Page 20: Time - Program
7. Press the STOP button to pause the monitor. 5. DISTANCE- PROGRAM 1. In the start menu, use the “UP / DOWN” key to select DISTANCE, and then press the ENTER key to choose the program. VirtuFit Ultimate Pro 2i Ergometer Rowing Machine... -
Page 21: Custom Program
You can change any of the defaults with the directions below. At any time, press START or begin rowing to begin the program with the default settings or mix of your changes and default setting. VirtuFit Ultimate Pro 2i Ergometer Rowing Machine... - Page 22 13. If you stop rowing, the time shown on the lower right window of monitor will pause. When you start rowing again, it will continue operating from where you left off. 14. Press the STOP button to pause the monitor. VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
- Page 23 3. Scan the QR code on the right to go to the user manual of the app. The manual describes step by step how the app should be connected to the device, how the app works and what the options are. KINOMAP APP STORE GOOGLE PLAY USER MANUAL KINOMAP KINOMAP KINOMAP VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
-
Page 24: Exploded Drawing
EXPLODED DRAWING VirtuFit Ultimate Pro 2i Ergometer Rowing Machine... -
Page 25: Parts List
Axial of pulley (back) Φ12.7*76 mm Washer Φ22*Φ44.2*3T Elastic rope bracket A12-1 Rubber Cover 6001 Chain bracket A12-2 Rubber Cover 6903 Pulley socket A13-1 Bearing BR-6001ZZDKFL Chain pulley Hexagon head screw M6*10 mm A13-2 Bearing BR-6903ZZDKFL VirtuFit Ultimate Pro 2i Ergometer Rowing Machine... - Page 26 Left pedal rest cover Washer M8*2.0T*Φ16 Right pedal rest cover Lower acorn Nut M8 Tapping screw M4*8 mm Seat carriage roller Set piece Bearing PR-608ZZ(BMC) Set base Even head socket screw M8*20 mm VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
- Page 27 Cap head socket screw M6*50 mm Tapping screw M4*12 mm Cap head socket screw M8*35 mm Cap head socket screw M8*16 mm Washer M8*Φ16*1.5T Pull pin Ball head view M4*10 mm Spring washers Pedal stable bracket VirtuFit Ultimate Pro 2i Ergometer Rowing Machine...
- Page 28 For questions or missing parts please contact your dealer.
