D-Link AC1200 User Manual page 115

DIR-842V2 AC1200 Wi-Fi Gigabit Router
Configuring via Web-based Interface
User Manual
If needed, you can add your own address resource records. To do this, click the ADD button ( )
in the Hosts section (available if the Router or WISP Repeater mode was selected in the Setup
Wizard).
Figure 103. Configuring the local interface. The IPv4 tab. The window for adding a DNS record.
In the IP address field, specify a host from the internal or external network. You can choose a
device connected to the router's LAN at the moment. To do this, select the relevant IPv4 address
from the drop-down list (the field will be filled in automatically). In the Name field, specify the
domain name to which the specified IPv4 address will correspond. Click the SAVE button.
To edit an existing record, in the Hosts section, select the relevant line in the table. In the opened
window, change the needed parameters and click the SAVE button.
To remove a record, in the Hosts section, select the checkbox located to the left of the relevant line
in the table and click the DELETE button ( ).
After completing the work with records, click the APPLY button.
Page 115
