Alarm Lock ET-PDLN Instructions & Template page 2

ET-PDLN
Networx Trilogy Panic Exit Device Trim
®
ETDLN
SERIES
ETPDLN
SERIES
Precision
Model 1100
Rim Exit Device
To Change Cylinder
IMPORTANT:
When replacing cylinder
be sure to use the
proper Cylinder Adapter
and Tailpiece.
Alarm Lock Systems, Inc.
A division of the NAPCO Security Technologies, Inc.
345 Bayview Avenue, Amityville, NY 11701
Tel: (631) 789-4871 Fax: (631) 789-3383
www.alarmlock.com
Publicly traded on NASDAQ Symbol: NSSC
INSTRUCTIONS & TEMPLATE
1
3
1. Existing Installation: Remove Exit device from door.
3. Before positioning the Exterior assembly on door,
feed the ribbon cable and the green ground wire
(with ring connector) through the 3/4" wire hole.
Note: The
spindle
hole must
be no less
Four #8 x 3/4" Four #8 x 3/4"
Four #8 x 3/4"
than 1"
flat head
flat head flat head
diameter
combination combination combination
screws screws screws
2
4
2. Existing Installation: Position Alarm Lock template on
horizontal & vertical lines of existing spindle hole. 4. Replace Exit Device, insert and fasten with 4 new mounting
New Installation: Locate and mark horizontal and vertical screws (do not over-tighten). Before mounting the Battery
lines indicated in Exit Device Instructions/Template. Line up Box Mounting Plate, carefully pull wires from door through
Alarm Lock template with horizontal and vertical lines and center of Plate. Do not pinch or cut wires. Position the Plate
a minimum of 1/4" below Exit Device. Fasten the Battery
tape onto door.
Existing and New Installations: Mark all hole centers on Box Mounting Plate with four #8 x 3/4" flat head combination
each side of door. Drill all holes from both sides of door to screws, using one of the screws to secure the green ground
avoid splintering. wire ring connector to the Plate.
A
B
A. Remove Cover plate. Rotate the
spindle either direction to expose
and remove cylinder screws.
B. Remove old cylinder and insert new cylinder.
Battery Pack
Battery
Box Cover
Hook and Hook and Hook and
loop loop loop
fastener fastener fastener
5 5 5
Battery Box
Mounting Plate
5. Connect the Battery Pack (batteries may be shrink wrapped
as shown or may be inside a housing) and place inside of
Battery Box Mounting Plate. Secure the Battery Pack inside
the Battery Box Cover with the hook and loop fastener
(provided). Position the Cover and fasten with four #6-32 x
5/16" screws.
Four
mounting
screws
(provided)
1/4" min.
Secure Ring
Connector to
Plate
6
6. Replace and fasten exit device & battery box covers.
Check lock for proper operation
before closing door.
TailPiece
C C
C. Note: The tailpiece must be in the
horizontal position as shown in the
image above.
Precision
Model 1100
HOLES
1.532"
DRILL BOTH
E
NSURE THIS
BOX IS
½
INCH
X
½
INCH
RECOMMENDED
HORIZONTAL
LINE OF
EXIT DEVICE
SPINDLE
1"
1.850"
DRILL BOTH
TWO HOLES
INTERIOR ONLY
For EXIT DEVICE
INSTALLATION
Drill 3/32" hole
1¼" deep for
#10 flat head
sheet metal
screws.
4.84"
TWO
THRU-
BOLT
1.375"
HOLES
5/16"
DRILL BOTH
SIDES
WIRES
HOLE
3/4"
DRILL BOTH
SIDES
TWO
THRU-
BOLT
5/16"
SIDES
5.170"
HOLE
MINIMUM
SIDES
3.75"
© 2010 Alarm Lock
Systems, Inc.
WI
1858-P11 05/10
