Comeup DV-6s Quick Start Manual

Introduction

Feature

Line pull:
Synthetic rope:
Brake:
Clutch:
Control:

Unpacking

W inch assembly.................................................................... 1
． ． ． ．
C ontrol box ........................................................................... 1
． ． ． ．
R emote control..................................................................... 1
． ． ． ．
S ynthetic rope with clevis hook................................................. 1
． ． ． ．
H awse fairlead...................................................................... 1
． ． ． ．
1 .8 m ( 6' ) 6 gauge battery leads.............................................. 1
． ． ． ．
Read this manual carefully
Carefully read and understand this manual before operating the winch.
Careless winch operation may result in personal injury, danger to others and
or damage to property

Installation

Before using the winch ensure all electrical components
are in good condition and all connections are sound.
Winch and hawse fairlead mounting
． ． ． ．
I t is important that the winch is mounted on a flat and
hard surface or mounting channel to ensure the motor,
drum and gearbox housing align correctly.
． ． ． ．
H awse fairlead does not mount to winch directly.
． ． ． ．
T he synthetic rope shall be wound in an under-wound
orientation only.
． ． ． ．
F our (4) M10 x 1.50 pitch 10.9 grade high tensile steel bolts must be used in
order to sustain the loads imposed on the winch mounting.
2,722 kg / 6,000 lb wire rope first layer
8 mm × 24.4 m synthetic rope SK75
Full Load Holding Proprietary Cone Brake
Lift and turn T Bar to activate free spool
Handheld pendant switch
Self-Recovery Winch
Model:
PN: 854752 12V DC
DV-6s
854754 12V DC
