Andatech
®
S O B E R P O I N T 3
Wall Mounted Breathalyser
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AlcoSense SOBERPOINT 3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Andatech AlcoSense SOBERPOINT 3

  • Page 1 Andatech ® S O B E R P O I N T 3 Wall Mounted Breathalyser USER’S MANUAL...
  • Page 2 We hope you enjoy owning your Andatech Soberpoint 3 breathalyser. If ® you have any questions regarding the unit or want to speak with us further, please visit andatech.com.au or call 1300 800 200 (between 9am and 5:30pm Monday to Friday). Components Coin Slot / Button...
  • Page 3: Specifications

    Specifications Indication of BAC 0.000 to 0.250 %BAC Warm up time Within 30 seconds Response time Within 6 seconds at 0.100 %BAC Accuracy ±0.005 %BAC at 0.100 %BAC Ambient conditions Operation: 5 °C to 40 °C Storage: 5 °C to 50 °C Sensor Replaceable fuel cell sensor Display...
  • Page 4 Setting Up Connect power cable 1. Open up the back of the machine. 2. Connect the power cable to power inlet located at the bottom right (see diagram) of the circuit board. 3. Plug in the power cable to a power source and switch it on.
  • Page 5 Operating Instructions The following instructions will be displayed on the LCD screen. 1. KNOW YOUR LIMIT. CHECK YOUR ALCOHOL LEVEL. WAIT 10 MINUTES AFTER LAST DRINK BEFORE TESTING. PUSH BUTTON OR INSERT COIN(S), AND TAKE A STRAW. WARMING UP, PLEASE WAIT ... 3.
  • Page 6: Wifi Setup

    2. Android phone or tablet connection Setup Software for Android Phone 1. On your android device, navigate to resources.andatech.com.au/software/soberlive-setup-app.apk 2. Download and install the setup software to your android device. Soberpoint Component Location 1. Wifi Status LED 2. Mode Control Switches a.
  • Page 7 Setting Wi-Fi Settings 1. Put the Soberpoint in “Setup Mode” a. Ensure the Soberpoint is unplugged and powered down b. Adjust the “Mode Control Switches” to the setup mode position (see component location section) c. Power on the Soberpoint unit d.
  • Page 8 5. Verify operation a. Take a breath test with the Soberpoint b. On your computer, log in to your account at my.andatech.com.au c. In the same browser, go to hub.andatech.com.au/ui/soberlive d. Click “View Data” next to the Soberpoint you have set up e.
  • Page 9: Maintenance

    Maintenance The product software is easy to maintain and can be changed without any special skills. It will automatically check and adjust the accuracy rate of measurement. SW1. Total Count SW2. Set the coin number SW3. Testing mode 1. To check the total amount of tests, press SW1 and the display window will show the test.
  • Page 10: Replacing Sensors

    Replacing Sensors Replace the sensor only with those provided by the manufacturer. Please refer to the following diagram and instructions for sensor replacement: A. Verify existing settings To Enter Set Up Mode Low Pass Level Exit 0.010 %BAC Buzzer High Pass Level 0.050 %BAC Enter menu and document current settings a.
  • Page 11 2. Open the rear door of the SoberPoint and unscrew the four screws holding the sensor board in place 3. Pull out the sensor board above the arrow direction 4. Plug out the connector and exchange the new sensor board 5.
  • Page 12: Warning Display

    Warning Display 1. Flow error If you stop blowing or you do not breathe strongly enough “Flow Error” will be displayed on LCD. Please wait and try again and the machine will return to the waiting mode. 2. Sensor error A.
  • Page 13: Troubleshooting

    Troubleshooting 1. The machine is plugged in, but there is no power a. Ensure you are using the correct power adapter for your region and that the power adapter is functioning. b. Make sure that the line attached to the power adapter is connected correctly to the power socket on the bottom of the machine.
  • Page 14 Disclaimers • This product must be used strictly in accordance with the instructions in this manual. • This product is intended to provide the user with an indication of alcohol on the breath. However, neither the manufacturer nor the supplier gives any warranty (express or implied) that the product can give any indication of blood alcohol level.
  • Page 15 The liability for proper functioning of the instrument is irrevocably transferred to the owner or operator in the event the instrument is serviced or repaired by personnel not employed or authorised by Andatech. In such an event, the warranty will be void.
  • Page 16: Warranty Details

    Service during the Warranty Period To claim for warranty, contact us on 1300 800 200 or send and email to support@andatech.com.au to get an RA# (Return Authorisation Number). Ensure that the RA# is clearly stated on the outside of the packaging and that the product is properly packaged so that no damage occurs to the product during transit.
  • Page 17 Extent of Warranty This warranty is limited to defects in workmanship or parts. All defective products or parts will be repaired or replaced. This warranty does not cover manuals and packaging. Normal Wear and Tear This warranty does not cover normal wear and tear to the product or parts.
  • Page 18: Warranty

    Visit my.andatech.com.au to register your warranty online and receive calibration reminders. CALIBRATION AND SERVICE Andatech recommends the Andatech® Soberpoint 3 to be calibrated every 6 months to maintain its accuracy to Australian Standards AS3547 requirements. To register your product warranty, receive calibration reminders and book in a calibration, please go to my.andatech.com.au or contact:...
  • Page 19 Set and “forget” year. It’s the easiest way to get your Save costs breathalyser calibrated every 6 months, Priority calibration and saves you the hassle of booking it in each time. Go to andatech.com.au/breathalyser-management or call 1300 800 200 for more information.
  • Page 20 1300 800 200 (AU) | +613 8899 6900 (International) andatech@andatech.com.au www.andatech.com.au V2.3. Updated Feb 2020.
