QUICK REFERENCE GUIDE - USE

Maxi Sky 2 PLUS

Transfer from seated to supine position

Place the sling around the

patient. For sling with head

support extend to top of

patient's head.

The sling must encircle the patient's buttocks

to provide better support and to achieve a

proper installation

Pull each leg strap under the thigh

so that it emerges on the inside of

the thigh.

Raise the patient.

001-31310-EN Rev 0 • 05/2020 • Page 1/4

Loop sling

Place attachment loop on

Place spreader bars at 45° and, close enough to attach

the hook.

shoulder loops then the leg loops.

Make sure that the safety

Raise foot-end of spreader bar first using the Recline

latch is closed.

button to create tension on the leg loops.

Move the patient.

Lower until no tension. Detach the

leg loops, then shoulder loops.
