QUICK REFERENCE GUIDE
Enterprise 5000X (E5X)
This Quick Reference Guide (QRG) is intended to assist the user in understanding the basic functions of this medical bed.
The QRG does not replace the safety warnings, cautions and other important information provided in the Instructions for
Use (IFU) supplied with the equipment; copies of the IFU are available on request from Arjo.
and understood the IFU before using this medical bed.
product safely.
Place the mattress platform in the low height position when the patient is unattended.
Product overview
Head board
Head end split side rail
Foot end split side rail
Attendant Control Panel (ACP)
Foot board
Bed stripper (linen shelf)
Technical Data
Safe Working Load (SWL):
Maximum patient weight:
Recommended patient height:
Product weight (without mattress):
Operating temperature:
Standard mattress size:
Liquid ingress protection:
Bed extension locking handle
Accessory socket
Brake pedal / bar
Roller buffer
Mattress extension catch bar
CPR release handle
815-516EN_2 · 06/2019
Drainage bag rail
Castor
Lifting pole socket
250kg (550lbs)
185kg (407 lbs)
146 to 190cm (57 to 74 ins.)
144kg (317 lbs)
5°C to 40°C (41°F to 104°F)
202 x 88 x 18 cm (79.5 x 34.6 x 7 ins)
IPX4
