Assembly instructions
Soccer goal „Quick-Net-Rail"
Completely welded
As this goal is completely welded only the net needs to be mounted at the goal (see point 2).

1. Scope of delivery

Please check the following content before assembly.
1x Completely welded goal
1x Accessories:
- 4 x plastic cap Ø 28mm
- 1 x assembly instruction
The net is not part of the delivery.

2. Assembly of the net

a) At first fix net at crossbar, uprights, ground bar and ground tube.
Press cord of the net into the C shaped holes of the net rail (see
photo).
Do not pull the net over the net hoops from the outside. Take care
that it is freely suspended between the hoops.
b) Now the tensioning cord can be tightened between the ring nuts which are provided at the net hoops.

3. Ground fixing

The ground bars/ground tube are equipped with boreholes of 25 mm which serve to fix the special anchoring systems for the
goal. Different systems are available (see Sport-Thieme accessories). The anchoring system is not part of the delivery. The use of
the goal without corresponding anchoring system is at your own risk. If you do not use any anchoring system close the boreholes
with the supplied caps for safety reasons. Use a mallet if necessary.

4. Maintenance, safety and storage instructions

This goal is constructed only for soccer matches and not for other purposes. Check all screwed
fastenings before use and repeat it from time to time.
It has to protected against overturning at any time. Do not climb net or goal frame. It is not
allowed to fix additional parts or extensions at the goal frame which may impair the safety of the
goal (according to DIN EN 748).
To avoid damage and misuse goals have to be stored secured and in an upright position when not in use.
Only use water for cleaning the surfaces. Do not use alcohol or any aggressive chemicals!
D-38367 Grasleben · Germany
sport-thieme.com · info @sport-thieme.com
Phone: +49 53 57 181 543 · Fax: +49 53 57 181 921
Art.-Nr.: 242 0934
