9.10 CONTACT OUTPUTS

9.10CONTACT OUTPUTS
The default configuration of outputs and LEDs is as follows:
TERMINALS
B5-B6 Alarm
A5-A6 Trip
B7-A7 Out1
B8-A7 Out2
B9-A7 Out3
B10-A7 Out4
LEDs
READY
TRIP
THERMAL (49)
OVERCURRENT (50/51)
UNBALANCE (46)
PICKUP
Outputs and LEDs can be checked during the following tests:
