IT
11.9
SCHEMA CALDAIA
3 GRUPPI
DATI PROGETTO DIRETTIVA PED 97/23/CE
PROJECT DATA FOR DIRECTIVE PED 97/23/CE
DONNÉES PROJET DIRECTIVE PED 97/23/CE
VOLUME / VOLUMES / VOLUMES
TS
P.V.S.
PT
FLUIDO / FLUID / FLUIDE
Elemento Q.tà Numero Parte
Element Q.tà Part Number
Élément Q.tà Numéro Partie
1 3 00000056
2 1 11740001
3 1 07300707
4 1 05000656
5 1 05000037
6 1 09500015
7 1 02290034
8 1 14100102
9 1 01000638
10 1 98031202
11 1 09000005
EN
11.9
BOILER DIAGRAM
3 GROUPS
6,8 l
139°C
3,0 Bar
4,0 Bar
H O
2
Descrizione
Description
Description
Dado / Nut / Écrou
Tubo / Pipe / Tube
Prigioniero / Prisoner / Prisonnier
Copriresistenza cilindrico
Cylindrical heating element cover
Couverture de résistance cylindrique
Ghiera filettata / Threaded ring nut / Bague filetée
Termoprotettore 184°C
Thermoprotector 184°C
Thermoprotecteur 184°C
Guarnizione OR / OR Gasket / Joint OR
Resistenza 3600W / Heating element 3600W / Résistance 3600W
Isolante caldaia
Boiler insulation
Isolation de la chaudière
Caldaia / Boiler / Chaudiere
Sonda livello / Level probe / Sonde de niveau
FR
11.9
SCHÉMA CHAUDIÈRE
3 GROUPES
10
11
1
2
3
4
9
8
7
6
5
Materiale
Material
Matériau
INOX 304
Teflon
OT57
NYLON
NYLON
Elettrico / Electrical / Electrique
VITON
INOX 304
Isolante alte prestazioni
High performance insulation
Isolation haute performance
INOX 304
Ottone, inox, nylon
Brass, inox, nylon
Laiton, inox, nylon
