nvent ERICO Plus Quick Start Manual

Troubleshooting Guide
Indicator lights are flashing:
The PlusCU uses an internal charging mechanism that sends an electric
current to the Cadweld Plus cup. If the trigger on the control unit is pulled
before the internal charging mechanism resets, the lights will flash. Wait 5
seconds and try again.
If the error message persists, contact your nVent ERICO representative.
PlusCU does not respond when trigger is pulled:
If the unit does not respond, check battery status to determine if new batteries are needed.
Cadweld Plus cup does not ignite:
Disconnect the PlusCU lead from the PlusCU then re-examine your mold, weldmetal cup,
ignition strip, and other Cadweld equipment to verify proper setup.
If this issue persists, contact your nVent ERICO representative.
PlusCU does not function properly at temperatures below 0° F [-18°C]:
Alkaline batteries are not intended for extreme cold temperatures. nVent ERICO
recommends the use of lithium-ion batteries at temperatures below 0° F [-18°C].
WARNING:
1. nVent products shall be installed and used only as indicated in nVent product instruction sheets and training materials. Instruction sheets are available at
www.nVent.com and from your nVent customer service representative.
2. nVent products must never be used for a purpose other than the purpose for which they were designed or in a manner that exceeds specified load ratings.
3. All instructions must be completely followed to ensure proper and safe installation and performance.
4. Improper installation, misuse, misapplication or other failure to completely follow nVent's instructions and warnings may cause product malfunction, property
damage, serious bodily injury and/or death, and void your warranty.
SAFETY INSTRUCTIONS:
All governing codes and regulations and those required by the job site must be observed.
Always use appropriate safety equipment such as eye protection, hard hat, and gloves as appropriate to the application.
nVent, nVent CADDY, nVent ERICO Cadweld, nVent ERICO Critec, nVent ERICO, nVent ERIFLEX, and nVent LENTON are owned by
nVent or its global affiliates. All other trademarks arethe property of their respective owners. nVent reserves the right to change
specifications without prior notice.
